Docomo SH-05A Instruction Manual page 342

Using as a microSD reader/writer
<USB mode setting>
The following shows the mode for connecting the FOMA terminal to a PC
with the FOMA USB Cable with Charge Function 02 (sold separately). When
using as a microSD reader/writer, set to [microSD mode] and connect.
Communication mode Mode for packet transmission, 64K data
communication and sending and receiving data
(OBEX™ communication) (nP. 416).
microSD mode Mode for reading/writing the data saved on
microSD Card.
MTP mode Mode for transferring music data to microSD Card
using Windows Media Player 11. For details on
saving methods nP. 246
While the Communication mode is activated, USB mode setting cannot
be changed.
1
Insert the FOMA terminal side connector of the FOMA
USB Cable with Charge Function 02 into the external
connector terminal on the FOMA terminal (1).
2
Insert the PC side connector of the FOMA USB Cable
with Charge Function 02 into the USB connector of
the PC (2).
Open the external
connector
terminal cover
340
1
2
Orient the
FOMA USB Cable with
printed side
Charge Function 02
upwards
(sold separately)
3
In stand-by, press t/select the stock icon [D]
(USB mode setting)/t.
: When USB mode setting is set to [microSD mode]/[MTP mode], the
stock icon does not appear and the PC is connected in the microSD
mode/MTP mode.
4
Select [microSD mode]/[Yes].
Returning to the Communication mode
Press a key other than the side key/[Yes].
• The USB mode setting is retained even if the FOMA USB Cable with
Charge Function 02 is disconnected.
Setting mode to use
■
Set the mode for connecting the FOMA USB Cable with Charge Function 02
in advance.
1
In the Custom menu, select
[USB mode setting].
: Alternatively, select [Settings]/[General settings]/[USB mode
setting].
2
Select the mode/t.
: When the operation is performed while connecting to a PC, the
switching confirmation screen appears if [microSD mode]/[MTP
mode] is selected.
The following devices are required to use the FOMA terminal as a
microSD reader/writer.
Item
Cable FOMA USB Cable with Charge Function 02
PC A PC with a USB port (Universal Serial Bus
Specification Rev. 1.1/2.0-compliant) is usable with
the FOMA USB Cable with Charge Function 02
Compatible OS Windows 2000, Windows XP, Windows Vista (all
Japanese versions)
If the screen stating that new hardware is searched appears on the PC,
click [キャンセル].
[LifeKit]/[microSD]/
Explanation
