c. Measure the primary coil resistance.
L LLL L LLL L L LLL L
2. Check:
• Secondary coil resistance
Out of specification → Replace.
Secondary coil resistance
8.50–11.50 kΩ
M MMM M MMM M M MMM M
a. Connect the pocket tester (Ω × 1k) to the ig-
nition coil as shown.
Pocket tester
90890-03112
Analog pocket tester
YU-03112-C
• Negative tester probe →
red/black "1"
• Positive tester probe →
spark plug terminal "2"
b. Measure the secondary coil resistance.
L LLL L LLL L L LLL L
EAS28930

CHECKING THE IGNITION SPARK GAP

1. Check:
• Ignition spark gap
Out of specification → Perform the ignition
system troubleshooting, starting with step 5.
Refer to "TROUBLESHOOTING" on page
8-4.
L LLL L L LLL L L LLL L
M MMM M M MMM M M MMM M
L LLL L L LLL L L LLL L
ELECTRICAL COMPONENTS
TIP
If the ignition spark gap is within specification,
the ignition system circuit is operating normally.
M MMM M MMM M
a. Remove the ignition coil from the spark plug.
b. Connect the ignition checker "1" as shown.
LLL
MMM
2. Ignition coil
c. Turn the main switch to "ON" and engine stop
switch to "
d. Measure the ignition spark gap "a".
e. Crank the engine by pushing the start switch
" " and gradually increase the spark gap un-
til a misfire occurs.
L LLL L LLL L
EAS28120
CHECKING THE CRANKSHAFT POSITION
SENSOR
1. Disconnect:
• Crankshaft position sensor coupler
(from the wire harness)
2. Check:
• Crankshaft position sensor resistance
Out of specification → Replace the crank-
LLL
shaft position sensor.
M MMM M MMM M
a. Connect the pocket tester (Ω × 100) to the
crankshaft position sensor coupler as shown.
8-148
Minimum ignition spark gap
6.0 mm (0.24 in)
M MMM M M MMM M M MMM M
Ignition checker
90890-06754
Oppama pet-4000 spark checker
YM-34487
".
L LLL L L LLL L L LLL L
Crankshaft position sensor resis-
tance
336–504 Ω at 20 °C (68 °F)
M MMM M M MMM M M MMM M
