EAS27260

TROUBLESHOOTING

Any of the following fail to light: headlight, high beam indicator light, taillight, license plate light or meter
light.
TIP
• Before troubleshooting, remove the following part(s):
1. Right side cowling
2. Right side panel
1. Check the each bulbs and bulb
sockets condition.
Refer to "CHECKING THE BULBS
AND BULB SOCKETS" on page
8-140.
OK ↓
2. Check the fuses.
(Main, headlight, ignition and tail-
light)
Refer to "CHECKING THE FUS-
ES" on page 8-141.
OK ↓
3. Check the battery.
Refer to "CHECKING AND
CHARGING THE BATTERY" on
page 8-142.
OK ↓
4. Check the main switch.
Refer to "CHECKING THE
SWITCHES" on page 8-137.
OK ↓
5. Check the dimmer switch.
Refer to "CHECKING THE
SWITCHES" on page 8-137.
OK ↓
6. Check the pass switch.
Refer to "CHECKING THE
SWITCHES" on page 8-137.
OK ↓
7. Check the headlight relay.
Refer to "CHECKING THE RE-
LAYS" on page 8-145.
OK ↓
NG →
Replace the bulb(s) and bulb socket(s).
NG →
Replace the fuse(s).
NG →
• Clean the battery terminals.
• Recharge or replace the battery.
NG →
Replace the main switch/immobilizer unit.
NG →
The dimmer switch is faulty. Replace the
left handlebar switch.
NG →
The pass switch is faulty. Replace the left
handlebar switch.
NG →
Replace the headlight relay.
8-19
LIGHTING SYSTEM
