Yamaha XT1200Z(Z) 2010 Service Manual page 373

Disassembling the oil pump
10 Nm (1.0 m
(6)
6
E
1
Order
1 Oil strainer (oil pump)
2 Pin
3 Spring
4 Relief valve
5 Oil pump inner rotor 1
6 Oil pump outer rotor 1
7 Pin
8 Oil pump housing cover
9 Pin
10 Pin
11 Oil pump driven gear
12 Washer
kgf, 7.2 ft Ibf)
• •
8
E
5
Job/Parts to remove
11
12
9
9
10 Nm (1.0 m
Q'ty
1
2
1
1
1
1
1
1
2
1
1
1
5-78
OIL PUMP
