OWNER'S MANUAL
MOTORCYCLE
XTZ07AS (Ténéré 700)
Read this manual carefully
before operating this vehicle.
BRL-28199-70
For your safety - pre-operation checks
1
2
3
4
5
6
7
8
9
10
11
12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TENERE 700 2025 and is the answer not in the manual?

Questions and answers

Related Manuals for Yamaha TENERE 700 2025

Summary of Contents for Yamaha TENERE 700 2025

  • Page 1: Table Of Contents

    Read this manual carefully before operating this vehicle. Location of important labels OWNER’S MANUAL Safety information Description Smartphone Connectivity System Instrument and control functions For your safety – pre-operation checks Operation and important riding points Periodic maintenance and adjustment Motorcycle care and storage MOTORCYCLE Specifications XTZ07AS (Ténéré...
  • Page 2 EAU46094   Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold.
  • Page 3 EAUA6900   Use of trade marks The Bluetooth ® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. Google Maps™ is a trademark of Google LLC.
  • Page 4 Yamaha has met these standards without reducing the performance or economy of operation of the motorcycle. To maintain these high standards, it is important that you and your Yamaha dealer pay close attention to the recommended maintenance schedules and operating instructions contained within this manual.

  • Page 5: Important Manual Information

    Important manual information EAU10134   Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury haz- ards. Obey all safety messages that follow this symbol to avoid possible injury or death.
  • Page 6 Important manual information EAU10202   XTZ07AS OWNER’S MANUAL ©2025 by Yamaha Motor Co., Ltd. 1st edition, November 2024 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd. is expressly prohibited. Printed in Japan.
  • Page 7 Front fender........5-35 Cleaning the spark arrester..... 8-16 RSS standard(s) ......4-2 USB Type-C jack ......5-35 Valve clearance ......8-17 Initial Setup (Yamaha Motorcycle Sidestand ........5-36 Tires ..........8-17 Connect app) ........ 4-3 Ignition circuit cut-off system..5-37 Spoke wheels .........
  • Page 8 8-26 Reporting safety defects ....11-5 Checking and lubricating the Maintenance record ....... 11-6 brake and shift pedals ....8-27 YAMAHA MOTOR CANADA LTD. Checking and lubricating the MOTORCYCLE WARRANTY brake and clutch levers ....8-27 GUIDE......... 11-8 Checking and lubricating the Index ..........

  • Page 9: Location Of Important Labels

    Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label is available from your Yamaha dealer. 2,3,4,5,6...
  • Page 10 Location of important labels ATTENTION WARNING Eviter de nettoyer le pare-brise avec une solution Improper loading can cause loss of control. alcaline ou acide ainsi qu’avec de l’essence ou Read owner’s manual for proper loading. un diluant. Utiliser un détergent neutre. 4B5-2815K-10 3JJ-28446-A2 STORAGE ORDER...

  • Page 11: Load Limit

    Location of important labels LOAD LIMIT CHARGE LIMITE 1.5 kg {3 lbs} 1,5 kg (3 lb) 3SA-24877-A1 3SA-24877-B2 WARNING AVERTISSEMENT BEFORE YOU OPERATE THIS VEHICLE, READ LIRE LE MANUEL DU PROPRIETAIRE AINSI QUE TOUTES THE OWNER’S MANUAL AND ALL LABELS. LES ETIQUETTES AVANT D’UTILISER CE VEHICULE.
  • Page 12 Location of important labels INFORMATION SUR LES PNEUS La pression des pneus à froid doit normalement être réglée comme suit. AVANT : 220 kPa, {2.20 kgf/cm }, 32 psi ARRIERE : 250 kPa, {2.50 kgf/cm }, 36 psi BAU-21668-10 CAN ICES-002 / NMB-002 8KM-82377-12...

  • Page 13: Safety Information

    Safety information EAU1031C Never operate a motorcycle with- be very effective in reducing the   out proper training or instruction. chance of this type of accident. Therefore: Take a training course. Beginners Be a Responsible Owner should receive training from a cer- •...
  • Page 14 Safety information • Know your skills and limits. ests during operation to main- Never wear loose-fitting clothes, Staying within your limits may tain control of the motorcycle. otherwise they could catch on the help you to avoid an accident. • The passenger should always control levers, footrests, or wheels •...
  • Page 15 Yamaha accessories, which are availa- motorcycle to minimize imbalance tion of the motorcycle is changed. To ble only from a Yamaha dealer, have or instability. avoid the possibility of an accident, use been designed, tested, and approved...
  • Page 16 Yamaha, even if sold and clearance, limit suspension travel, ries are not recommended. installed by a Yamaha dealer. steering travel or control opera- Use caution when adding electri- tion, or obscure lights or reflectors.
  • Page 17 Safety information Remove all loose items from the motorcycle. Check that the fuel cock (if equip- ped) is in the “OFF” position and that there are no fuel leaks. Point the front wheel straight ahead on the trailer or in the truck bed, and choke it in a rail to pre- vent movement.

  • Page 18: Description

    Description EAU10411 Left view 1. Spring preload adjuster (page 5-29) 9. Compression damping force adjuster (page 5-29) 2. Rebound damping force adjuster (page 5-29) 3. Coolant reservoir (page 8-13) 4. Seat lock (page 5-28) 5. Shift pedal (page 5-23) 6. Engine oil level check window (page 8-9) 7.

  • Page 19: Right View

    Description EAU10421 Right view 1. Main fuse (page 8-32) 2. Fuse box (page 8-32) 3. Battery (page 8-30) 4. Fuel tank cap (page 5-25) 5. Brake pedal (page 5-24) 6. Rear brake fluid reservoir (page 8-22) 7. Spring preload adjuster (page 5-32)

  • Page 20: Controls And Instruments

    Description EAU10431 Controls and instruments 1. Clutch lever (page 5-22) 9. Throttle grip (page 8-26) 2. Left handlebar switches (page 5-2) 10.Main switch/steering lock (page 5-1) 3. “ABS” button (page 5-4) 4. Display (page 5-6) 5. USB Type-C jack (page 5-35) 6.

  • Page 21: Smartphone Connectivity System

    (CCU) and the Yamaha Motorcycle and/or display properly. Connect app on your phone. The following may interfere with Turn by Turn GPS navigation...

  • Page 22: Industry Canada License Exempt

    (2) this device must accept any interfer- cle Connect app and therefore dif- ence, including interference that may fer from the contents of this Yamaha Motorcycle Connect is a free cause undesired operation of this de- manual. app which is needed to complete the vice.

  • Page 23: Initial Setup (Yamaha Motorcycle Connect App)

    2. CCU QR Code first phone within reach will be 4. When pairing is complete, the connected. smartphone battery level indicator “ ” and the Yamaha Motorcycle Initial setup: Turn by Turn naviga- Connect app indicator “ ” will tion come on.
  • Page 24 Motorcycle Connect app is ob- tained via Google Maps. Use of Google Maps is subject to your agreement to the Google Maps terms of use. Yamaha shall not be liable for any damages resulting from the use of Google. The Yamaha Motorcycle Connect...

  • Page 25: Instrument And Control Functions

    Instrument and control functions EAU10462 The headlight will stay on until the To lock the steering Main switch/steering lock key is turned to “OFF”, even if the engine stalls. EAU10664 All electrical systems are off. The key can be removed. EWA10062 LOCK WARNING...

  • Page 26: Handlebar Switches

    Instrument and control functions To unlock the steering EAU6605B Right Handlebar switches Left 1. Push. 1. Stop/Run/Start switch “ ” 2. Turn. 2. “MODE” button 1. Dimmer/Pass switch “ ” Push the key in and turn it to “OFF”. 2. Joystick “ ”...
  • Page 27 Instrument and control functions EAUA6020 turn signal light will flash continuously Dimmer/Pass switch “ ” until all of the following conditions oc- cur: The vehicle travels approx. 150 m (490 ft). More than 15 seconds has el- lapsed. The vehicle speed is more than 5 km/h (3 mi/h).
  • Page 28 Instrument and control functions 7-2 for starting instructions prior to EAUA5110 EAUA5122 Joystick “ ” and home button “ABS” button starting the engine. “ ” This button deactivates/activates the Set this switch to “ ” to stop the en- anti-lock brake system (ABS). gine in case of an emergency, such as when the vehicle overturns.

  • Page 29: Indicator Lights And Warning Lights

    Use extra caution to avoid pos- Indicator lights and warning sible wheel lock during emer- lights gency braking. Have a Yamaha dealer check the vehicle as soon as possible. EAUA6030 ABS OFF indicator light “ ” This indicator light comes on when the...

  • Page 30: Display

    Instrument and control functions EAUM5280 Display Explorer Street km/h km/h 20155 20115 20.5 1. Information display 6. Fuel meter 2. Tachometer 7. Speedometer 3. Indicator icons 8. Coolant temperature meter 4. Clock 9. ABS mode indicator 5. Transmission gear display...

  • Page 31: Main Display Screen

    The fuel meter indicates the amount of display segments flash repeatedly, bility in various lighting conditions. fuel in the fuel tank. The display seg- have a Yamaha dealer inspect the However, due to the nature of this ments of the meter disappear from “F” vehicle.

  • Page 32: Indicator Icons

    ABS mode indicator does not come on, or if it remains on, This indicator shows the currently se- have a Yamaha dealer check the vehi- lected ABS mode. There are 3 ABS cle. modes which can be changed with the “MODE”...
  • Page 33 The TCS can be turned ON/OFF with disappear when the vehicle power is then go off. Otherwise, have a Yamaha the “MODE” button and the MODE dis- turned ON/OFF or when the “Received dealer check the vehicle.
  • Page 34 Instrument and control functions Permission to access notifications activated separately in the menu Information display must be granted to the Yamaha system. (See page 5-21.) The information display is a section of Motorcycle Connect app on your For more information on the quick the main screen which contains various smartphone.
  • Page 35 Instrument and control functions To reset information display items: short press “ ” to confirm and the next “L/100km” or “MPG” in the menu sys- If a displayed item can be reset, short digit will flash. Repeat this until the third tem.
  • Page 36 Instrument and control functions MODE display If the vehicle coolant temperature The vehicle must be stopped to make is below 39 °C (103 °F) the coolant changes to the traction control set- temperature display will read “Low tings. Temp” SPORT If the vehicle coolant temperature ABS mode is above 117 °C (243 °F) the cool-...
  • Page 37 Instrument and control functions “Phone” (highest) • Bluetooth connection is unsta- EWA21100 WARNING “Turn by Turn” ble. Always ride on paved roads with the “Music” • Too many other devices con- ABS turned on. Turn the ABS off only “Weather” (lowest) nected to the smartphone at once.
  • Page 38 The phone indicator “ ” will ap- Navigation must be set using the pear. Yamaha Motorcycle Connect app. When a phone call is active, select the 45.6 EWA21420 red phone icon to end the call.
  • Page 39 Maps. Use of Google Maps is tomatically, the track information subject to your agreement to the Goo- may not display, or the next/previ- gle Maps terms of use. Yamaha shall ous track and volume adjustment Partly cloudy not be liable for any damages resulting may not function.
  • Page 40 Instrument and control functions Windy No data Clear night Storm Light rain Partly cloudy night Moderate wintry mix Heavy rain Mostly cloudy night Foggy Light snow Scattered showers night Smog Heavy snow Scattered storm night Hail Light wintry mix Scattered showers Heavy wintry mix Scattered storm Cloudy...

  • Page 41: Menu System

    Instrument and control functions EAUA5147 Menu system operation: Menu system Control the grip warmers. Operate the joystick left-right-up- “Grip Warmer” (See page 5-19.) The first layer of the menu system is a (if equipped) down to highlight and adjust menu pop-up that appears on the bottom of items.
  • Page 42 Instrument and control functions “ Phone” “Received Call” “ Message” If a call was accepted, the icon shall be represented by a phone handset with a If a smartphone is not connected to the If a smartphone is not connected to the green arrow.
  • Page 43 5-14.) and/or applications, notifications may be disabled or messages dis- played on the side menu may differ If navigation is not set in the Yamaha from the contents on the connect- Motorcycle Connect app or if a smart- ed smartphone.
  • Page 44 Instrument and control functions “ Settings” “Maintenance” The settings menu is divided into the This module allows you to record dis- The grip warmer settings can only be following modules: tance traveled between engine oil accessed while the vehicle is stopped. changes “Oil”, and two other mainte- Set maintenance tripme- “Maintenance”...
  • Page 45 Instrument and control functions “Unit” “Brightness” This module allows you to set the 12- hour clock. The hours and minutes are This module allows you to change the This module allows you to adjust the set individually. measurement units. Each of the three screen brightness between 3 different items contain a sub-menu where the levels.

  • Page 46: Clutch Lever

    Instrument and control functions Setting 1: Can quick shift only while ac- including maintenance tripmeters), and EAU12823 Clutch lever celerating (“QS ”) or decelerating all measurement units. (“QS ”). Setting 2: Can quick shift while acceler- ating or decelerating. “OFF” turns the respective upshift or downshift function off, and the clutch lever must then be used when shifting in that direction.

  • Page 47: Shift Pedal

    Instrument and control functions EAU12876 EAUA6040   Shift pedal Quick shifter (if equipped) Downshifting conditions QS allows for clutch lever-less, elec- Vehicle speed of at least 20 km/h tronically-assisted shifting. When the (12 mi/h) sensor on the shift rod detects the ap- Engine speed of at least 2000 propriate motion in the shift pedal, en- r/min...

  • Page 48: Brake Lever

    Instrument and control functions EAU26827 EAU12944 EAU90663 Brake lever Brake pedal The brake lever is located on the right The anti-lock brake system (ABS) acts side of the handlebar. To apply the front on the front and rear brakes independ- brake, pull the lever toward the throttle ently.

  • Page 49: Fuel Tank Cap

    Instrument and control functions The ABS performs a self-check EAUM1795 Fuel tank cap when you first start off. During this time a clicking noise from the hy- draulic unit may be audible, and if the brake lever or brake pedal is applied a vibration can be felt, but this is not a malfunction.

  • Page 50: Fuel

    Instrument and control functions EAU13222 Fuel The fuel tank cap cannot be installed Make sure there is sufficient gasoline in unless the key is in the lock. In addition, the tank. the key cannot be removed if the cap is EWA10882 not properly installed and locked.

  • Page 51: Fuel Tank Breather Hose And Overflow Hose

    ECA11401 EAU86100 NOTICE   Your Yamaha engine was designed to Use only unleaded gasoline. The use use regular unleaded gasoline. Confirm of leaded gasoline will cause severe the pump octane number [(R+M)/2 damage to internal engine parts,...

  • Page 52: Catalytic Converter

    Instrument and control functions Make sure that the end of each EAU13435 EAU32981 Catalytic converter Seat hose is not blocked, and clean if The exhaust system contains catalytic necessary. To remove the seat converter(s) to reduce harmful exhaust Make sure that each hose is posi- emissions.

  • Page 53: Adjusting The Headlight Beams

    ECA10102 If headlights require adjustment, con- 2. Push the rear of the seat down to NOTICE sult a Yamaha dealer. lock it in place. To avoid damaging the mechanism, 3. Remove the key. do not attempt to turn beyond the maximum or minimum settings.
  • Page 54 Instrument and control functions Spring preload setting: Rebound damping setting: Minimum (soft): Minimum (soft): Distance A = 19.0 mm (0.75 in) 23 click(s) in direction (b) Standard: Standard: Distance A = 19.0 mm (0.75 in) 18 click(s) in direction (b) Maximum (hard): Maximum (hard): Distance A = 4.0 mm (0.16 in)
  • Page 55 Instrument and control functions effective and may damage the suspension. 1. Rubber cap 1. Compression damping force adjuster 2. Turn the adjuster in direction (a) to Compression damping setting: increase the compression damp- Minimum (soft): ing force. Turn the adjuster in di- 19 click(s) in direction (b) Standard: rection...

  • Page 56: Front Fork Bleeding

    Instrument and control functions EAU14796 EAUM4121 Front fork bleeding Adjusting the shock absorber assembly When riding in extremely rough condi- tions, the air temperature and pressure This shock absorber assembly is in the front fork will rise and harden the equipped with a spring preload adjust- suspension.
  • Page 57 Instrument and control functions effective and may damage the Rebound damping setting: suspension. Unit for adjustment: Click Minimum (soft): Rebound damping force Standard: Turn the adjuster in direction (a) to in- crease the rebound damping force. Maximum (hard): Turn the adjuster in direction (b) to de- crease the rebound damping force.
  • Page 58 Take the shock stops, and then count the clicks in di- When turning the damping force absorber assembly to a Yamaha rection (b). adjuster in direction (b), it may click beyond the stated specifications, dealer for any service.

  • Page 59: Luggage Strap Holders

    Instrument and control functions EAU84680 EAUM4130 EAUA1832 Luggage strap holders Front fender USB Type-C jack To suit the riding conditions, the front This model is equipped with a 5 V (3 A) fender height can be adjusted. USB Type-C jack. The USB Type-C jack can be used when the main switch To adjust the front fender height is on.

  • Page 60: Sidestand

    Yamaha’s ignition circuit cut-off sys- tem has been designed to assist the operator in fulfilling the responsibili- ty of raising the sidestand before starting off. Therefore, check this system regularly and have a Yamaha 5-36...

  • Page 61: Ignition Circuit Cut-Off System

    Instrument and control functions EAUA1271 Ignition circuit cut-off system This system prevents in-gear engine starts unless the clutch lever is pulled and the sidestand is up. Also, it will stop the running engine should the side- stand be lowered while the transmis- sion is in gear.
  • Page 62 The neutral switch may not be working. 6. Move the sidestand up. The motorcycle should not be ridden until 7. Pull the clutch lever. checked by a Yamaha dealer. 8. Shift transmission into gear. 9. Move the sidestand down. Does the engine stall? The sidestand switch may not be working.

  • Page 63: For Your Safety - Pre-Operation Checks

    • If necessary, add recommended coolant to specified level. 8-13 • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary.
  • Page 64 For your safety – pre-operation checks ITEM CHECKS PAGE • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Rear brake • Replace if necessary. 8-21, 8-22 • Check fluid level in reservoir.
  • Page 65 For your safety – pre-operation checks ITEM CHECKS PAGE • Check operation of ignition circuit cut-off system. Sidestand switch 5-36 • If system is not working correctly, have Yamaha dealer check vehicle.

  • Page 66: Operation And Important Riding Points

    0 and 1600 km (1000 mi). For 1600 km (1000 mi) and beyond understand, ask your Yamaha dealer. this reason, you should read the follow- The vehicle can now be operated nor- ing material carefully.

  • Page 67: Starting The Engine

    This model is equipped with: the transmission is in the neutral a lean angle sensor. This sensor Yamaha dealer check the vehicle. position or stops the engine in case of a vehi- 3. Shift the transmission into the neu- the transmission is in gear, the cle turnover.

  • Page 68: Shifting

    Operation and important riding points EAU16675 3. Open the throttle gradually, and at ECA10262 Shifting NOTICE the same time, release the clutch When shifting, press the shift lever slowly. pedal firmly until you feel the 4. At the recommended shift points shown in the following table, close gear shift is complete.

  • Page 69: Parking

    Operation and important riding points 3. When the engine is about to stall or EAU64150 EAU17214 Parking Recommended shift points runs roughly, pull the clutch lever The recommended shift points during When parking, stop the engine, and in, use the brakes to slow the mo- acceleration and deceleration are then remove the key from the main torcycle, and continue to down-...

  • Page 70: Periodic Maintenance And Adjustment

    – possibly leading to pending on the weather, terrain, geo- is certified (if applicable). Yamaha deal- death. See page 2-2 for more in- graphical location, and individual use, ers are trained and equipped to per-...

  • Page 71: Tool Kit

    Tool kit If you do not have the tools or experi- ence required for a particular job, have your Yamaha dealer perform it for you. 1. Tool kit 2. Storage pouch The tool kit is in the location shown. Al-...

  • Page 72: Periodic Maintenance Chart For The Emission Control System

    From 37000 km (24000 mi) or 36 months, repeat the maintenance intervals starting from 13000 km (8000 mi) or 12 months. Items marked with an asterisk require special tools, data and technical skills, have a Yamaha dealer perform the service. EAU17612...

  • Page 73: General Maintenance And Lubrication Chart

    (16000 mi) (20000 mi) 1 month 6 months 12 months 18 months 24 months 30 months • Perform dynamic inspection using Diagnostic system Yamaha diagnostic tool. Ö Ö Ö Ö Ö Ö check • Check the error codes. 2  ...
  • Page 74 Periodic maintenance and adjustment INITIAL ODOMETER READINGS 1000 km 7000 km 13000 km 19000 km 25000 km 31000 km ITEM ROUTINE (600 mi) (4000 mi) (8000 mi) (12000 mi) (16000 mi) (20000 mi) 1 month 6 months 12 months 18 months 24 months 30 months •...
  • Page 75 Every 3 years Front and rear brake 28 * Ö Ö Ö Ö Ö Ö • Check operation. switches • Apply Yamaha cable lubricant or 29 * Control cables Ö Ö Ö Ö Ö Ö other suitable cable lubricant thor- oughly.
  • Page 76 Periodic maintenance and adjustment INITIAL ODOMETER READINGS 1000 km 7000 km 13000 km 19000 km 25000 km 31000 km ITEM ROUTINE (600 mi) (4000 mi) (8000 mi) (12000 mi) (16000 mi) (20000 mi) 1 month 6 months 12 months 18 months 24 months 30 months Lights, signals and...

  • Page 77: Removing And Installing The Engine Guard

    Do not attempt to diagnose such problems yourself. Instead, have a Yamaha dealer check the vehicle. 1. Engine guard If a spark plug shows signs of electrode 2. Bolt and washer erosion and excessive carbon or other deposits, it should be replaced.

  • Page 78: Engine Oil And Oil Filter Cartridge

    Periodic maintenance and adjustment Before installing a spark plug, the spark EAUA5452 Engine oil and oil filter plug gap should be measured with a If a torque wrench is not available when cartridge wire thickness gauge and, if necessary, installing a spark plug, a good estimate The engine oil level should be checked adjusted to specification.
  • Page 79 Periodic maintenance and adjustment 1. Engine oil filler cap 1. Engine oil filler cap 1. Engine oil drain bolt 2. Engine oil level check window 2. O-ring 2. Gasket 3. Maximum level mark To change the engine oil (and re- 4.
  • Page 80 Oil quantity: An oil filter wrench is available at a Oil change: 2.30 L (2.43 US qt, 2.02 Imp.qt) Yamaha dealer. With oil filter removal: 7. Apply a thin coat of clean engine 2.60 L (2.75 US qt, 2.29 Imp.qt) oil to the O-ring of the new oil filter cartridge.

  • Page 81: Why Yamalube

    Periodic maintenance and adjustment engine off and have a Yamaha dealer EAU85450 Why Yamalube check the vehicle. YAMALUBE oil is a Genuine YAMAHA 15. Turn the engine off, wait a few mi- Part born of the engineers’ passion and nutes for the oil level to settle for an...

  • Page 82: Coolant

    1. Coolant reservoir available, use distilled water or 2. Maximum level mark soft tap water instead. Do not If genuine Yamaha coolant is not avail- 3. Minimum level mark use hard water or salt water able, use an ethylene glycol antifreeze since it is harmful to the engine.

  • Page 83: Replacing The Air Filter Element And Cleaning The Check Hose

    Have a maintenance chart. Replace the air fil- Yamaha dealer change the coolant. ter element more frequently if you often WARNING! Never attempt to remove ride in the rain or dusty areas. In addi-...
  • Page 84 Periodic maintenance and adjustment 5. Check the air filter for damage or screw. NOTICE: Make sure that ter may enter the air filter case and the air filter element is properly cause damage to the engine. dirt and replace it if necessary. seated in the air filter case.

  • Page 85: Cleaning The Spark Arrester

    Periodic maintenance and adjustment EAUA5470 4. Tap the tailpipe lightly, and then Cleaning the spark arrester use a wire brush to remove any The spark arrester should be cleaned at carbon deposits from the spark ar- the intervals specified in the periodic rester portion of the tailpipe and in- maintenance chart.

  • Page 86: Valve Clearance

    To pre- fied tires. vent this from occurring, have your Yamaha dealer check and adjust the Tire air pressure valve clearance at regular intervals. The tire air pressure should be checked and, if necessary, adjusted before each ride.
  • Page 87 “broken in” for glass fragments in it, or if the sidewall is Never overload your vehicle. Opera- it to develop its optimal charac- cracked, have a Yamaha dealer replace tion of an overloaded vehicle could teristics. the tire immediately.

  • Page 88: Spoke Wheels

    Yamaha could lead to an accident. dealer. Do not attempt to repair or After extensive tests, only the tires list-...

  • Page 89: Adjusting The Clutch Lever Free Play

    There should be no free play at the 1. Clutch lever free play adjusting bolt brake lever end. If there is free play, 2. Clutch lever free play have a Yamaha dealer inspect the brake system. Clutch lever free play: EWA14212 5.0–10.0 mm (0.20–0.39 in)

  • Page 90: Brake Light Switches

    EAU22434 Front brake pads Yamaha dealer. 1. Brake pad wear indicator groove Each front brake pad is provided with wear indicator grooves, which allow you to check the brake pad wear with- out having to disassemble the brake.

  • Page 91: Checking The Brake Fluid Level

    Periodic maintenance and adjustment disappeared, have a Yamaha dealer re- EAU40262 Rear brake Checking the brake fluid level place the brake pads as a set. Before riding, check that the brake fluid is above the minimum level mark. EAU46292 Rear brake pads Check the brake fluid level with the top of the reservoir level.

  • Page 92: Changing The Brake Fluid

    EAU22734 Changing the brake fluid id; otherwise, the rubber seals Yamaha dealer check the cause before Have a Yamaha dealer change the may deteriorate, causing leak- further riding. brake fluid every 2 years. In addition, age.

  • Page 93: Drive Chain Slack

    EAU22762 EAU74260 Drive chain slack To adjust the drive chain slack Consult a Yamaha dealer before ad- The drive chain slack should be justing the drive chain slack. checked before each ride and adjusted 1. Loosen the axle nut and the lock- if necessary.

  • Page 94: Cleaning And Lubricating The Drive Chain

    Periodic maintenance and adjustment EAU23027 3. Alignment marks Cleaning and lubricating the 3. Tighten the axle nut, then the lock- drive chain nuts to their specified torques. The drive chain must be cleaned and lubricated at the intervals specified in Tightening torques: the periodic maintenance and lubrica- Axle nut:...

  • Page 95: Checking And Lubricating The Cables

    Yamaha dealer at the ed if necessary. If a cable is damaged intervals specified in the periodic main- or does not move smoothly, have a tenance chart.

  • Page 96: Checking And Lubricating The Brake And Clutch Levers

    Periodic maintenance and adjustment EAU44276 Shift pedal EAU23145 Checking and lubricating the Checking and lubricating the brake and shift pedals brake and clutch levers The operation of the brake and shift The operation of the brake and clutch pedals should be checked before each levers should be checked before each ride, and the pedal pivots should be lu- ride, and the lever pivots should be lu-...

  • Page 97: Checking And Lubricating The Sidestand

    The operation of the sidestand should The pivoting points of the rear suspen- Silicone grease be checked before each ride, and the sion must be lubricated by a Yamaha Clutch lever: sidestand pivot and metal-to-metal dealer at the intervals specified in the...

  • Page 98: Lubricating The Swingarm Pivots

    The swingarm pivots must be lubricat- fork does not operate smoothly, and hold it in an upright position. ed by a Yamaha dealer at the intervals have a Yamaha dealer check or re- WARNING! To avoid injury, se- specified in the periodic maintenance pair it.

  • Page 99: Checking The Steering

    If any free burns. Avoid any contact with smoothly, have a Yamaha dealer check play can be felt, have a Yamaha skin, eyes or clothing and al- the wheel bearings. dealer check or repair the steering.
  • Page 100 4. First, disconnect the negative bat- To charge the battery tery lead, and then the positive Have a Yamaha dealer charge the bat- battery lead. tery as soon as possible if it seems to have discharged. Keep in mind that the...

  • Page 101: Replacing The Fuses

    Periodic maintenance and adjustment connecting the negative lead. EAUA5511 ECA16522 Replacing the fuses NOTICE [ECA16842] The main fuse and the fuse boxes, To charge a VRLA (Valve Regulated 4. After installation, make sure that which contain the fuses for the individ- Lead Acid) battery, a special (con- the battery leads are properly con- ual circuits, are located under the seat...
  • Page 102 2. Headlight fuse Main fuse: 50.0 A 4. If the fuse immediately blows 3. ABS control unit fuse Terminal fuse 1: again, have a Yamaha dealer 4. Ignition fuse 2 5.0 A check the electrical system. 5. Signaling system fuse Headlight fuse: 6.

  • Page 103: Vehicle Lights

    Except for the license plate light bulb, If the license plate light does not come this model’s lights are all LED. on, have a Yamaha dealer check the If an LED light does not come on, check electrical circuit or replace the bulb.

  • Page 104: Troubleshooting

    The following troubleshooting charts represent quick and easy procedures for checking these vital systems your- self. However, should your motorcycle require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the motorcycle properly.

  • Page 105: Troubleshooting Chart

    Remove the spark plug and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the compression. 4. Compression The engine does not start. There is compression.

  • Page 106: Engine Overheating

    Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended cool- ant as soon as possible.

  • Page 107: Motorcycle Care And Storage

    Be sure sure to wash the underside and of many components. Washing, clean- to consult a Yamaha dealer for ad- chassis parts after riding in such ing, and polishing will also give you a vice on what products to use before areas.
  • Page 108 Motorcycle care and storage those available in coin-operated 4. Pre-soak stubborn stains like in- ter will increase salt’s corrosive car washers. properties. sects or bird droppings with a wet [ECA26301] harsh chemicals, including towel for a few minutes. 3. For windshield-equipped vehicles: strong acidic wheel cleaners, 5.
  • Page 109 Motorcycle care and storage 3. Use a chrome polish to shine nutes to help dry any remaining If necessary, clean the brake discs and pads with brake chrome, aluminum, and stainless moisture. cleaner or acetone. steel parts. Often the thermally in- 9.

  • Page 110: Storage

    Motorcycle care and storage EAU83472 1. Make all necessary repairs and b. Pour a teaspoonful of engine oil Storage perform any outstanding mainte- into the spark plug bore. Always store the vehicle in a cool, dry nance. c. Install the spark plug cap onto place.
  • Page 111 Motorcycle care and storage once a month in order to prevent the tires from becoming degraded in one spot. 9. Cover the muffler outlet with a plastic bag to prevent moisture from entering it. 10. Remove the battery and fully charge it, or attach a maintenance charger to keep the battery opti- mally charged.

  • Page 112: Specifications

    Specifications Dimensions: Starting system: Radiator (including all routes): Electric starter 1.61 L (1.70 US qt, 1.42 Imp.qt) Overall length: Engine oil: Fuel: 2370 mm (93.3 in) Overall width: Recommended brand: Recommended fuel: 935 mm (36.8 in) Unleaded gasoline (E10 acceptable) Overall height: Octane number (RON): 1455 mm (57.3 in)
  • Page 113 Specifications Bulb wattage: Manufacturer/model: PIRELLI/SCORPION RALLY STR Headlight: Rear tire: Type: Brake/tail light: With tube Size: Front turn signal/position light: 150/70 R18 M/C 70V M+S Manufacturer/model: Rear turn signal light: PIRELLI/SCORPION RALLY STR Loading: Auxiliary light: Maximum load: License plate light: 186 kg (410 lb) 5.0 W (Total weight of rider, passenger, cargo and...

  • Page 114: Consumer Information

    These identification numbers are need- Vehicle identification number ed when registering the vehicle with the authorities in your area and when order- ing spare parts from a Yamaha dealer.   VEHICLE IDENTIFICATION NUMBER: 1. Engine serial number The engine serial number is stamped into the crankcase.

  • Page 115: Diagnostic Connector

    (See page 5-28.) Re- Information label cord the information on this label in the space provided. This information will be needed when ordering spare parts from a Yamaha dealer. EAU26382 Key identification number 1. Diagnostic connector 1. Vehicle Emission Control Information label...

  • Page 116: Use Of Your Vehicle Data

    (3) other data showing the status of the vehicle such as diagnostic trouble code (DTC). The collected data will be uploaded to server at Yamaha Motor Co., Ltd. by attaching a special Yamaha diagnostic tool to the vehicle, only when maintenance checks or service procedures are performed.
  • Page 117 Consumer information How to contact us? Any questions or complaints regarding the processing of your vehicle data can be submitted in writing to: Yamaha Motor Canada Ltd. Attn: Privacy Officer 480 Gordon Baker Road, Toronto, Ontario, M2H 3B4 The SOLE PURPOSE of above provided contact information is TO RESPOND DATA PROCESSING INQUIRY AND OTHER KINDS OF INQUIRIES WILL NOT BE RESPONDED.

  • Page 118: Reporting Safety Defects

    If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform Transport Canada in addition to notifying Yamaha Motor Canada Ltd, Canada. If Transport Canada receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.

  • Page 119: Maintenance Record

    Consumer information EAU26643 Maintenance record Copies of work orders and/or receipts for parts purchased and installed on your vehicle will be required to document that maintenance has been completed in accordance with the emissions warranty. The chart below is printed only as a reminder that maintenance work is required.
  • Page 120 Consumer information Maintenance Date of Servicing dealer Mileage Remarks interval service name and address 55000 km (36000 mi) or         54 months 61000 km (40000 mi) or         60 months 11-7...

  • Page 121: Yamaha Motor Canada Ltd

    In this warranty, the term ‘MOTORCYCLE’ shall refer to a new or YZ, with the exception of WR25R, WR25X, YZ65 and YZ85 change of registration is sent to YAMAHA at the time of such motorcycle manufactured by YAMAHA MOTOR COMPANY, LTD.
  • Page 122 CUSTOMER at the time of DELIVERY. fitness for a particular purpose on the part of YAMAHA, and any other obligation or liability on behalf of YAMAHA, and the above...

  • Page 123: Index

    Diagnostic connector........ 11-2 Industry Canada license exempt RSS Shifting............7-3 Dimmer/Pass switch........5-3 standard(s)..........4-2 Shock absorber assembly, adjusting..5-32 Display............5-6 Initial Setup (Yamaha Motorcycle Con- Sidestand..........5-36 Display, main screen........5-7 nect app)...........4-3 Sidestand, checking and lubricating...8-28 Drive chain slack........8-24 Initial setup: Turn by Turn navigation.....4-3 Smart features: Introduction......
  • Page 124 Turn signal switch........5-3 USB Type-C jack........5-35 Use, your vehicle data........11-3 Valve clearance......... 8-17 Vehicle Emission Control Information label............11-2 Vehicle identification number..... 11-1 Vehicle lights..........8-34 Warranty........... 11-8 Wheel bearings, checking......8-30 Wheels............8-19 Yamaha Motorcycle Connect app....4-2 Yamalube..........8-12 12-2...
  • Page 125 Yamalube – Take care of your Yamaha with legendary Yamalube oils, lubricants, and care products. They’re formulated and approved by the toughest judges we know: the Yamaha engineering teams that know your Yamaha from the inside out.
  • Page 126 PRINTED IN JAPAN 2024.12-0.6´1 CR (E)

This manual is also suitable for:

Xtz07as

Table of Contents

Save PDF
