EAS23330

SWINGARM

Removing the swingarm
3
2
1
3.8 Nm (0.38 m
6 Nm (0.6 m kgf, 4.3 ft
•
10 Nm (1.0 m kgf, 7.2 ft
•
Order
Rear wheel
Rear shock absorber assembly
Final drive assembly
Footrest plate
Muffler
1 Rubber boot cover
2 Pivot shaft end plate
3 Pivot shaft nut
4 Pivot shaft
5 Swingarm
LT
kgf, 2.8 ft Ibf)
• •
Ibf)
•
Ibf)
•
Job/Parts to remove
LT
LS
Q'ty
Refer to "REAR WHEEL" on page 4-29.
Refer to "REAR SHOCK ABSORBER AS-
SEMBLY" on page 4-96.
Refer to "SHAFT DRIVE" on page 4-104.
Refer to "REAR BRAKE" on page 4-52.
Refer to "ENGINE REMOVAL" on page 5-3.
1
1
1
1
1
4-100
SWINGARM
120 Nm (12 m kgf, 87 ft
• •
4
LS
LS
Remarks
lbf)
5
