SERVICE MANUAL NUMBER 22
7. Pivot the alternator. Adjust belt deflection to be 5 mm (3/16 in.) measured at midpoint
between the pulleys on the longest belt span.
8. Torque tensioning and mounting bolts 28 Nm (21 lb-ft).
Typical
9. Install the seawater pump inlet and outlet hoses.
10. Open the seacock, if equipped. If boat is not equipped with a seacock, remove the plug
and connect the seawater inlet hose.
90-860074--1 FEBRUARY 2002
a -
Deflection: 5 mm (3/16 in.)
b -
Tensioning Bolt
c -
Mounting Bolt
a
73521
MAINTENANCE
b
c
74301
Page 1B-59
