JMA-5212-4/6
JMA-5212-4/6
JMA-5222-7/9
JMA-5222-7/9
JMA-5212-4HS/6HS
JMA-5212-4HS/6HS
MARINE RADAR
MARINE RADAR
EQUIPMENT
EQUIPMENT
INSTRUCTION
INSTRUCTION
MANUAL
MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JMA-5212-4/6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for JRC JMA-5212-4/6

Summary of Contents for JRC JMA-5212-4/6

  • Page 1 JMA-5212-4/6 JMA-5212-4/6 JMA-5222-7/9 JMA-5222-7/9 JMA-5212-4HS/6HS JMA-5212-4HS/6HS MARINE RADAR MARINE RADAR EQUIPMENT EQUIPMENT INSTRUCTION INSTRUCTION MANUAL MANUAL...
  • Page 3 PRECAUTIONS BEFORE OPERATION Cautions for high voltage High voltages from hundreds volts to tens of thousands volts are to be applied to the electronic equipment such radio and radar devices. You do not face any danger during normal operation, but sufficient cares are required for maintenance, inspection and adjustment of their internal components.
  • Page 4 FIRST-AID TREATMENTS First-aid treatments As far as the victim of electric shock is not in dangerous condition, do not move him and practice artificial respiration on him immediately. Once started, it should be continued rhythmically. (1) Do not touch the victim confusedly as a result of the accident, but the rescuer may also get an electric shock.
  • Page 5 When pulse is beating but breathing has stopped (Mouth-to-mouth respiration) Fig. 1 (1) Tilt the victim’s head back as far as this face looks back. (A pillow may be inserted his neck.) (2) Push his jaw upward to open his throat wide (to spread his airway). (3) Pinch the victim’s nostrils and take a deep breath, block his mouth completely with yours and blow into his mouth strongly.
  • Page 6 When both pulse and breathing have stopped Perform the (Cardiac massage) Fig. 2 and (Mouth-to-mouth respiration) Fig. 1 When no pulse has come not to be felt, his pupils are open and no heartbeat is heard, cardiac arrest is supposed to have occurred and artificial respiration must be performed. (1) Place your both hands, one hand on the other, on the lower one third area of his breastbone and compress his breast with your elbows applying your weight on his breast so that it is dented about 2cm (Repeat compressing his breast 50 times or so a minutes).

  • Page 7: Preface

    PREFACE Thank you very much for purchasing the JRC marine radar equipment, JMA-5200M2 series. This equipment is a marine radar equipment designed to obtain safe operation of marine ships. This equipment consists of a radar signal transmitter-receiver unit, a LCD display unit and a scanner unit as its main units.

  • Page 8: Before Operation

    Before Operation Pictorial Indication Various pictorial indications are included in this manual and are shown on these equipment so that you can operate them safety and correctly and prevent any danger to you and/or to other persons and any damage to your property during operation.

  • Page 9: Precautions

    PRECAUTIONS DANGER Never conduct inspection or repair work of equipment components. Inspection or repair work by uncertified personnel may result in fire hazard or electrocution. For inspection and repair work of equipment components, consult with our branch office, branch shop, sales office, or our distributor in your district. When conducting maintenance, make sure to turn the main power off.
  • Page 10 WARNING Never directly touch the internal components of the antenna, receiver/transceiver, or indicator. Direct contact with these high-voltage components may cause electrocution. For maintenance, inspection, or adjustment of equipment components, consult with our branch office, branch shop, sales office, or our distributor in your district.
  • Page 11 WARNING Do not change MBS Level/Area unless absolutely necessary. Incorrect adjustment will result in deletion of nearby target images and thus collisions may occur resulting in death or serious injuries. When cleaning the display screen, do not wipe it too strongly with a dry cloth.
  • Page 12 CAUTION A malfunction may occur if the power in the ship is instantaneously interrupted during operation of the radar. In this case, the power should be turned on again. Always use the automatic tuning mode. Use the manual tuning mode only when the automatic tuning mode does not provide the best tuning state due to deterioration of magnetron for example.
  • Page 13 CAUTION When using the [AUTO RAIN] function, never set the suppression level too high canceling out all image noises from the rain or snow at close range. Detection of not only echoes from the rain or snow but also targets such as other ships or dangerous objects will become inhibited.
  • Page 14 CAUTION Use the target tracking function (TT) only as a navigation aid. The final navigation decision must always be made by the operator him/herself. Making the final navigation decision based only on the target tracking function (TT) information may cause accidents. The target tracking function (TT) information such as vector, target numerical data, and alarms may contain some errors.
  • Page 15 CAUTION When a small value is set as a hysteresis condition, a tracked target near an AIS target is identified as the AIS target and may thus disappear from the display. For example, when a pilot vessel equipped with the AIS function (a small target which is not a tracked target) goes near a cargo vessel which is a tracked target without the AIS function, the tracked target symbol for the...
  • Page 16 CAUTION Do not change the quantization level settings unless absolutely necessary. If set at an inappropriate value, the acquisition or tracking function of the target tracking function (TT) deteriorates, and this may lead to accidents. Any adjustments must be made by specialized service personnel.

  • Page 17: The Mounting Point Of The Warning Label

    The Mounting Point of the Warning Label Warning Label NCD-4380 Radar Process Unit Warning Label Front face Back face NWZ-164 LCD Monitor - xi -...
  • Page 18 Warning Label NKE-2103-6/6HS Scanner Unit Warning Label NKE-2254-7/9/6HS Scanner Unit - xii -...
  • Page 19 - xiii -...

  • Page 20: Equipment Appearance

    EQUIPMENT APPEARANCE Scanner Unit Type NKE-2103-4 (4 feet) Scanner Unit Type NKE-2103-6 (6 feet) Scanner Unit Type NKE-2254-7 (7 feet) Scanner Unit Type NKE-2254-9 (9 feet) - xiv -...
  • Page 21 NDC-1460 Processor Unit (Desktop Type) NWZ-164 Display Unit (Desktop Type) NCE-7699A Operation Unit (Desktop Type) NCD-4380 Display Unit (Desktop Type) - xv -...

  • Page 22: Table Of Contents

    CONTENTS PREFACE........................i BEFORE OPERATION ...................ii PRECAUTIONS..................... iii THE MOUNTING POINT OF THE WARNING LABEL........... xi EQUIPMENT APPEARANCE ................xiv GLOSSARY ......................xxv 1. GENERAL AND EQUIPMENT COMPOSITION FUNCTIONS ................... 1-1 1.1.1 FUNCTION OF THIS SYSTEM............1-1 FEATURES ..................... 1-2 CONFIGURATION .................. 1-4 EXTERIOR DRAWINGS .................
  • Page 23 2.3.6 Software Buttons for Area 6 (Other Ship Information Area) (Right Side of the Radar Display) ..2-16 2.3.7 Software Buttons for Area 7 (Panel Display Area) (Right Side of the Radar Display) ....2-18 2.3.8 Software Buttons for Area 7 (Panel Display Area) (Right Side of the Radar Display) ....
  • Page 24 3.4.10 Hide Ship’s Heading Line (HL OFF)..........3-23 3.4.11 Hide Graphics Information on Radar Display (Graphic Display)..3-24 GENERAL OPERATIONS..............3-25 3.5.1 Move Cross Cursor Mark by Trackball ..........3-25 3.5.2 Use EBLs (Electronic Bearing Lines) [EBL1/2] ......... 3-26 3.5.3 Set EBL Operation (EBL1 /2 Setting) ..........3-29 3.5.4 Display Variable Range Markers [VRM1/VRM2] .......
  • Page 25 3.8.4 Set Navigation Information (User Map Setting) ......... 3-93 3.8.5 Set and Display Geodetic System ........... 3-100 APPLIED OPERATIONS..............3-102 3.9.1 Set Radar Signal Processing (Process Setting) ......3-102 3.9.2 Set Radar Trails (RADAR Trails Setting) ......... 3-105 3.9.3 Set Cursor (Cursor Setting)............. 3-110 3.9.4 Set Screen(Screen Setting).............
  • Page 26 TT OPERATION..................5-18 5.2.1 Acquiring Target [ACQ] ..............5-19 5.2.2 Canceling Unwanted Targets ............5-22 5.2.3 Tracking Target Data Display [TGT DATA] ........5-23 5.2.4 Displaying Target ID No. (Target Number Display)......5-25 5.2.5 Input of target information (TT Individual Setting) ......5-26 5.2.6 Reference Target (Reference)............
  • Page 27 FALSE ECHOES ...................6-10 DISPLAY OF RADAR TRANSPONDER (SART)........6-13 7. SETTINGS FOR SYSTEM OPERATION SETTINGS AT INSTALLATION ............... 7-1 7.1.1 How to open the Adjust Menu ............. 7-2 7.1.2 Tuning Adjustment................7-3 7.1.3 Bearing Adjustment ................7-6 7.1.4 Range Adjustment ................7-7 7.1.5 Antenna Height Setting (Antenna Hight) ..........
  • Page 28 REPLACEMENT OF MAJOR PARTS ........... 8-23 8.4.1 Parts Required for Periodic Replacement......... 8-25 8.4.2 Replacement of magnetron............... 8-25 8.4.3 Motor Replacement................8-31 8.4.4 Replacement of Diode Limiter (A303) (JMA-5212-4/6, 5222-7/9) ..8-37 8.4.5 Replacement of Backup Battery ............. 8-38 9. TROUBLESHOOTING AND AFTER-SALES SERVICE FAULT FINDING ..................
  • Page 29 DISPOSAL OF USED BATTERIES ............10-2 10.3 DISPOSAL OF USED MAGNETRON ........... 10-3 10.4 ABOUT THE CHINA ROHS..............10-4 11. SPECIFICATIONS 11.1 JMA-5212-4/6 TYPE RADAR ..............11-1 11.2 JMA-5222-7/9 TYPE RADAR ..............11-2 11.3 SCANNER (NKE-2103-4/6)..............11-3 11.4 SCANNER (NKE-2254-7/9)..............11-4 11.5...
  • Page 30 FIGURE 1 JMA-5212-4/6, JMA-5222-7/9 BLOCK DIAGRAM FIGURE 2 JMA-5212-4/6 INTER-CONNECTION DIAGRAM FIGURE 3 JMA-5222-7/9 INTER-CONNECTION DIAGRAM FIGURE 4 PRIMARY POWER SUPPLY DIAGRAM, TYPE JMA-5212-4/6, JMA-5222-7/9 FIGURE 5 PROCESSOR UNIT, NDC-1460 INTER-CONNECTION DIAGRAM FIGURE 6 KEY-BOARD UNIT, NCE-7699A INTER-CONNECTION DIAGRAM FIGURE 7...

  • Page 31: Glossary

    GLOSSARY This section describes the main terms used for this equipment and general related maritime terms. Acquisition/Activation zone A zone set up by the operator in which the system should automatically acquire radar targets and activate reported AIS targets when entering the zone.
  • Page 32 CORREL CORRELation The distance to the Closest Point of Approach and Time to the Closest CPA/TCPA Point of Approach. Limits are set by the operator and are related to own ship. Course Through Water The direction of the ship's movement through the water DRIFT The current velocity for manual correction or the current speed on the horizontal axis of the 2-axis log is displayed.
  • Page 33 InterSWitch Lost AIS target A target symbol representing the last valid position of an AIS target before the reception of its data was lost, or its last dead-reckoned position. Lost tracked target One for which target information is no longer available due to poor, lost or obscured signals.
  • Page 34 Radar cross-section Radar cross-section of a target determines the power density returned to the radar for a particular power density incident on the target Range Rings A set of concentric circles labeled by distance from CCRP. Reference target A symbol indicating that the associated tracked stationary target is used as a speed reference for the ground stabilization Relative course The direction of motion of a target relative to own ship motion...
  • Page 35 Speed Over the Ground The speed of the ship relative to the earth, measured on board of the ship. Short Pulse STAB STABilization Speed Through Water The speed of the ship relative to the water surface. TCPA Time to Closest Point of Approach to own ship Test target Radar target of known characteristics used for test requirement True Motion...
  • Page 36 Variable Range Marker An adjustable range ring used to measure the distance to a target. Waypoint A geographical location on a route indicating a event. - xxx -...
  • Page 37 GENERAL AND EQUIPMENT COMPOSITION SCREEN DISPLAY AND OPERATION PANEL BASIC OPERATION MEASUREMENT OF RANGE AND BEARING OPERATION OF TT AND AIS TRUE AND FALSE ECHOES ON DISPLAY SETTINGS FOR SYSTEM OPERATION MAINTENANCE AND INSPECTION TROUBLESHOOTING AND AFTER-SALES SERVICE DISPOSAL SPECIFICATION #22'0&+: APPENDIX - xxxi -...
  • Page 38 - xxxii -...

  • Page 39: General And Equipment Composition

    SECTION 1 GENERAL AND EQUIPMENT COMPOSITION FUNCTIONS ..........1-1 1.1.1 FUNCTION OF THIS SYSTEM....1-1 FEATURES ........... 1-2 CONFIGURATION ........1-4 EXTERIOR DRAWINGS....... 1-5 GENERAL SYSTEM DIAGRAMS ....1-14...

  • Page 40: Functions

    FUNCTIONS This equipment is a high-performance radar equipment consisting of a scanner unit, a transmitter-receiver unit and a high resolution color LCD display unit. 1.1.1 Function of This System The JMA-5200M2 series is a color radar system designed to comply with the international standards of the IMO.

  • Page 41: Features

    1.2 FEATURES FEATURES Realization of Easy-to-see Screen with High Resolution The 15-inch color LCD with high resolution of 1024 u 768 pixels can display radar images of 180 mm or more in diameter. Even short-range targets can also be displayed as high-resolution images. Target Detection by Latest Signal Processing Technology The system employs the latest digital signal processing technology to eliminate undesired clutter from the radar video signals that are obtained from the receiver with a wide dynamic range, thus improving the target...
  • Page 42 Improved Day/Night Mode Two types of background colors are available in each Day/Dusk/Night mode (total 4 background colors). Each background color can be reproduced to be suited for the user’s operating environment by simple key operation. The radar echoes and a variety of graphics can also be represented in different colors, ensuring easy-to-see displays.

  • Page 43: Configuration

    1.3 CONFIGURATION CONFIGURATION Scanners and Transmitted Output Powers TRANSMITTED RATE OF SCANNER TYPE BAND CATEGORY OUTPUT POWER ROTATION 4 FT SLOT JMA-5212-4 10 KW 27rpm CAT 3 ANTENNA 6 FT SLOT JMA-5212-6 10 KW 27rpm CAT 3 ANTENNA 7 FT SLOT JMA-5222-7 25 KW 24rpm...

  • Page 44: 1.4 Exterior Drawings

    EXTERIOR DRAWINGS Fig. 1.1 Exterior Drawing of Scanner Unit, Type NKE-2103-4 Fig. 1.2 Exterior Drawing of Scanner Unit, Type NKE-2103-6 Fig. 1.3 Exterior Drawing of Scanner Unit, Type NKE-2254-7 Fig. 1.4 Exterior Drawing of Scanner Unit, Type NKE-2254-9 Fig. 1.5 Exterior Drawing of Monitor Unit, Type NWZ-164 Fig.
  • Page 45 1.4 EXTERIOR DRAWINGS Fig. 1.1 Exterior Drawing of Scanner Unit, Type NKE-2103-4...
  • Page 46 Fig. 1.2 Exterior Drawing of Scanner Unit, Type NKE-2103-6...

  • Page 47: 1.4 Exterior Drawings

    1.4 EXTERIOR DRAWINGS Fig. 1.3 Exterior Drawing of Scanner Unit, Type NKE-2254-7...
  • Page 48 Fig. 1.4 Exterior Drawing of Scanner Unit, Type NKE-2254-9...
  • Page 49 1.4 EXTERIOR DRAWINGS Fig. 1.5 Exterior Drawing of Monitor Unit, Type NWZ-164 1 10...
  • Page 50 Fig. 1.6 Exterior Drawing of Processor Unit, Type NDC-1460 1 11...
  • Page 51 1.4 EXTERIOR DRAWINGS Fig. 1.7 Exterior Drawing of Keyboard Unit, Type NCE-7699A 1 12...
  • Page 52 Fig. 1.8 Exterior Drawing of NSK Unit, Type NCT-4106A 1 13...

  • Page 53: General System Diagrams

    1.5 GENERAL SYSTEM DIAGRAMS GENERAL SYSTEM DIAGRAMS Fig. 1.9 General System Diagram of Radar, Type JMA-5212-4/6 Fig. 1.10 General System Diagram of Radar, Type JMA-5222-7/9 1 14...
  • Page 54 Fig. 1.9 General System Diagram of Radar, Type JMA-5212-4/6 Note: Install the radar cable as far as from the cables of other radio equipment in order to prevent other radio equipment from interfering with the radar operations. In particular, do not install the antenna cable parallel to the cables of other radio equipment.
  • Page 55 1.5 GENERAL SYSTEM DIAGRAMS Fig. 1.10 General System Diagram of Radar, Type JMA-5222-7/9 Note: Install the radar cable as far as from the cables of other radio equipment in order to prevent other radio equipment from interfering with the radar operations. In particular, do not install the antenna cable parallel to the cables of other radio equipment.
  • Page 56 1 17...

  • Page 57: Screen Display And Operation Panel

    SECTION 2 SCREEN DISPLAY AND OPERATION PANEL Example of Display....................2-1 Names and Functions of Control Panel KEYs............2-2 Functions of Software Buttons ................2-7 2.3.1 Software Buttons for Area 1 (Top-Left Corner of the Radar Display) ... 2-8 2.3.2 Software Buttons for Area 2 (Bottom-Left Corner of the Radar Display) ... 2-10 2.3.3 Software Buttons for Area 3 (Top-Right Corner of the Radar Display)..

  • Page 58: Example Of Display

    EXAMPLE OF DISPLAY...

  • Page 59: Names And Functions Of Control Panel Keys

    2.2 NAMES AND FUNCTIONS OF CONTROL PANEL KEYS NAMES AND FUNCTIONS OF CONTROL PANEL KEYS The following page describe name of buttons.
  • Page 60 Trackball Use this trackball to move the cursor mark to an arbitrary point. The trackball can be used for setting in each mode. For example, use it to specify the center of a floating EBL or the off-center position. oFor setting cursor, see section 3.9.3. [EBL] (Electric Bearing Line) Control Rotates the bearing of an EBL.
  • Page 61 2.2 NAMES AND FUNCTIONS OF CONTROL PANEL KEYS [TX/PRF] (Transmit/Transmitting Repetition Frequency) Key PREHEAT at the upper left of the radar display changes to STANDBY about three minutes after the power is turned on. Then, press this key to start transmission. To fine-tune the transmitting repetition frequency, press the key during transmission.
  • Page 62 [FUNC] (Function Call) Key Calls predefined signal processing setting when pressed. The selection changes in the following sequence each time the key is pressed: Function Off o Function 1 o Function 2 o Function 3 o Function 4 o Function Off Holding down the key for two seconds or more displays the function setting menu.
  • Page 63 2.2 NAMES AND FUNCTIONS OF CONTROL PANEL KEYS [RR/HL] [8] (Fixed Range Marker/Heading Line Off/8) Key The ship’s HL (heading line) is erased while this key is held down. The fixed range marker display switches back and forth between display and non-display each time the key is pressed.

  • Page 64: Functions Of Software Buttons

    FUNCTIONS OF SOFTWARE BUTTONS This radar provides the software buttons on the display which can be used to set several important functions directly and swiftly from the display without opening the corresponding menu. The names of buttons are described on the following pages. By positioning the arrow cursor to a button in the figure above and then clicking the left button of the trackball, the setting can be changed as shown below.

  • Page 65: 2.2 Functions Of Software Buttons

    2.2 FUNCTIONS OF SOFTWARE BUTTONS 2.3.1 Software Buttons for Area 1 (Top-Left Corner of the Radar Display) 000.0 Compass Rings 1NM RM(R) H UP Off Center Transmit X-BAND Master Range scale switching Transmission / standby switching increase observation range scale At expiration of the pre-heat time after the power (maximum 96NM), click + and to reduce the is turned on, Preheat changes to...
  • Page 66 Azimuth display mode switching Stabilization mode display The azimuth display is switched whenever this Sea : Stabilization with respect to the water button is clicked. GND : Stabilization with respect to the ground H Up (Head Up) Ÿ N Up (North Up) Ÿ C Up (Course Up) Ÿ...

  • Page 67: Software Buttons For Area 2 (Bottom-Left Corner Of The Radar Display)

    2.3 FUNCTIONS OF SOFTWARE BUTTONS 2.3.2 Software Buttons for Area 2 (Bottom-Left Corner of the Radar Display) IR Low ENH Level1 PROC Off FUNC Off Gain Rain TUNE Multi TGT Num Auto Double zoom switching Function (FUNC) mode switching Use this function to enlarge to double the size the The function mode is switched whenever this display screen of the position specified by the button is clicked.
  • Page 68 Multi-dial mode switching Multi-dial mode The function that is registered in the multi-dial is The currently selected multi-dial mode described switched whenever the button is clicked. is displayed. Ÿ Ÿ Ÿ Vector Trails TGT No. Course Ÿ Track Ÿ Mark Ÿ Ÿ...

  • Page 69: Software Buttons For Area 3 (Top-Right Corner Of The Radar Display)

    2.3 FUNCTIONS OF SOFTWARE BUTTONS 2.3.3 Software Buttons for Area 3 (Top-Right Corner of the Radar Display) Cursor True 089.6 35 33.037' 5.37 NM 140 01.597'E EBL1 045.0 3.00 VRM1 135.0 EBL2 T VRM2 6.00 CCRP1 and Cursor mode switching EBL1 / 2 and VRM1 / The mode of the function that uses the cursor is 2 adjustment...
  • Page 70 EBL1 / EBL2 starting point Parallel index line setting mode switching This function sets the parallel index line display to On / Off and acquires the operation right. The EBL starting point is set to CCRP or any If this button is clicked, the operation right is position on the radar screen whenever this button acquired and the menu is opened.

  • Page 71: Software Buttons For Area 4 (Bottom-Right Corner Of The Radar Display)

    2.3 FUNCTIONS OF SOFTWARE BUTTONS 2.3.4 Software Buttons for Area 4 (Bottom-Right Corner of the Radar Display) TRK 30 sec Shift Data Ring Mark color switching CPA ring display On / Off The color of the mark is switched whenever this The CPA ring display is switched to On / Off button is clicked.

  • Page 72: Software Buttons For Area 5 (Own Ship Information Area) (Right Side Of The Radar Display)

    2.3.5 Software Buttons for Area 5 (Own Ship Information Area) (Right Side of the Radar Display) Speed sensor switching Positioning system (example: GPS, The speed sensor is switched whenever the button DGPS) is clicked. Displays the type of the position fixing equipment MAN (Manual) Ÿ...

  • Page 73: Software Buttons For Area 6 (Other Ship Information Area) (Right Side Of The Radar Display)

    2.3 FUNCTIONS OF SOFTWARE BUTTONS 2.3.6 Software Buttons for Area 6 (Other Ship Information Area) (Right Side of the Radar Display) Vector 9 min Limit 1 min PAST POSN R 0.1 Association Filter Range Trails R 10min 09:52 Target vector display true / relative Past position display interval switching switching...
  • Page 74 Radar trails display true / relative Radar trails display time switching switching The radar trails display time is switched whenever the button is clicked. Radar trails are switched to (true motion If the time does not reach the radar trails time that trail) / R (relative motion trail) whenever this was set, the remaining time is displayed on the button is clicked.

  • Page 75: Software Buttons For Area 7 (Panel Display Area) (Right Side Of The Radar Display)

    2.3 FUNCTIONS OF SOFTWARE BUTTONS 2.3.7 Software Buttons for Area 7 (Panel Display Area) (Right Side of the Radar Display) AIS ID DEST POSN EPFS RAIM POSN Accuracy AIS ID Range TCPA /min AIS ID Name Call SIGN MMSI IMO Number NAV Status AIS ID AtoN Real/Virtual...

  • Page 76: Software Buttons For Area 7 (Panel Display Area) (Right Side Of The Radar Display)

    2.3.8 Software Buttons for Area 7 (Panel Display Area) (Right Side of the Radar Display) TT ID Range Cource Speed TCPA Tracked target information Information of the selected tracked target can be shown in numerical values. Two ships can be selected as tracked targets. 2 19...

  • Page 77: Software Buttons For Area 8 (Operation And Message Area) (Right Side Of The Radar Display)

    2.3 FUNCTIONS OF SOFTWARE BUTTONS 2.3.9 Software Buttons for Area 8 (Operation and Message Area) (Right Side of the Radar Display) < > Brilliance Panel Day1 < > Menu Close RADAR Plot Test No Alarm Exit button Tracked target / AIS target Click this button to exit the menu screen.
  • Page 78 2 21...

  • Page 79: Basic Operation

    SECTION 3 BASIC OPERATION FLOW OPERATION ..................3-1 3.5.13 Use Video Process (Process)............3-57 3.1.1 Power ON and Start the System ............3-2 3.5.14 Zoom ....................3-58 3.1.2 Observe and Adjust Video ..............3-3 3.5.15 Use Marker [MOB] ................3-59 3.1.3 Acquire and Measure Data..............

  • Page 80: Flow Operation

    FLOW OPERATION Attention z Do not put anything on the operation panel. If you put anything hot on it, it may be deformed. z Do not give any impact to the operation panel, trackball, or controls. Otherwise, any failure or damage may result. POWER ON AND START THE SYSTEM OBSERVE AND...

  • Page 81: Power On And Start The System

    3.1 FLOW OPERATION 3.1.1 Power ON and Start the System Caution A malfunction may occur if the power in the ship is instantaneously interrupted during operation of the radar. In this case, the power should be turned on again. Attention z Wait for about 2 seconds before turning on the power again.

  • Page 82: Observe And Adjust Video

    Procedure Check that the ship’s mains are turned on. Press [STBY] key. The system is turned on, and the preheating time is displayed. PREHEAT is indicated at the upper left of the radar display. Wait until the preheating time is over. When the preheating time is over, the preheating time screen disappears, and PREHEAT at the upper left of the radar display changes to STANDBY .

  • Page 83: Acquire And Measure Data

    3.1 FLOW OPERATION 3.1.3 Acquire and Measure Data For details on data acquisition and measurement, refer to Section 3.4 “BASIC OPERATIONS” and Section 4 “MEASUREMENT OF RANGE AND BEARING.” 3.1.4 Display and Measure with Reference to CCRP The radar video, range, bearing, Target Tracking and AIS data display etc... are displayed with reference to CCRP (Consistent Common Reference Point).

  • Page 84: End The Operation And Stop The System

    3.1.5 End the Operation and Stop the System Exit Press [STBY] key. The radar will stop transmission and the antenna will stop rotating. TRANSMIT at the upper left of the radar display changes to STANDBY . Maintain the standby state if radar observation is restarted in a relatively short time. Only pressing the [TX/PRF] key starts observation.

  • Page 85: Menu Composition

    3.2 MENU COMPOSITION MENU COMPOSITION The Menu system of this radar equipment consists of the main menu and the submenus up to the lower 2 levels. You can jump to each menu by pressing the menu button at the lower right of the radar display or the switch on the operation panel.

  • Page 86: Basic Menu Operation

    3.2.2 Basic Menu Operation To open the menu: Press [RADAR MENU] key. To close the menu: Press [RADAR MENU] key. Alternatively, hold down [0] key until the menu closes. * Software button located at the operation/message area in Section 2.3.9 also available to switch between ON and OFF.
  • Page 87 3.2 MENU COMPOSITION Menu Operation with the Trackball The menu items are software buttons that can be operated with the trackball. An item can be selected by pointing the trackball cursor to the item and pressing [ENT] key, instead of using the numeric key. Example of menu display The selected item is displayed by pressing the corresponding numeric...

  • Page 88: Preparation

    PREPARATION 3.3.1 Adjust Display Brilliance [BRILL] Procedure Obtain the best-to-see display with optimum brilliance by turning the [BRILL] control at the lower right of the display unit. Turning the [BRILL] control clockwise increases the brilliance of the entire display. Conversely, turning the [BRILL] control counterclockwise decreases the brilliance of the entire display.

  • Page 89: Adjust Operation Panel Brilliance [Panel]

    3.3 PREPARATION 3.3.3 Adjust Operation Panel Brilliance [PANEL] Brilliance of the operational panel can be adjusted in accordance with the ambient illuminance conditions. Procedure Press [PANEL] key to adjust the brilliance of the operation panel light. Brilliance increases as the [PANEL] key is pressed. When it reaches the highest level, it returns to the lowest level.

  • Page 90: Adjust Brilliance Of Information On Radar Display (Brilliance Setting)

    3.3.5 Adjust Brilliance of Information on Radar Display (Brilliance Setting) Brilliance can be adjusted for each item of information on the radar display by operating the menu. RADAR Video Adjusts the brilliance of radar echoes. RADAR Trails Adjusts the brilliance of radar trails. TT/AIS Adjusts the brilliance of TT symbols and AIS symbols.

  • Page 91: Adjust Sound Volume (Buzzer Volume)

    3.3 PREPARATION 3.3.6 Adjust Sound Volume (Buzzer Volume) When an alarm goes off, the operation panel of the equipment produces a sound to notify users of state changes. Adjust the sound volume as follows: Procedure Press [RADAR MENU] key twice. Press [8] key.

  • Page 92: Set Display Color

    3.3.8 Set Display Color For each day/night mode, set the colors of the background outside the bearing scale, the background inside the bearing scale, characters, radar echoes, and radar trails. Color Adjustment by Menu Operation Day/Night Registers the switching of a day/night mode. Own Ship Adjust the colors of the ship's heading marker, own ship symbol, and a vector of the own ship.
  • Page 93 3.3 PREPARATION Setting Colors of Items Set the display color of each item. Procedure While the Display Color Setting Menu is open, select the item number for color setting, pressing the numeric keys [3] to [9]. The color selection screen will appear. 2.

  • Page 94: Basic Operations

    BASIC OPERATIONS 3.4.1 Start Transmission [TX/PRF] Procedure Press [TX/PRF] key. The radar will start transmission and the antenna will start rotating. The indication STANDBY at the upper left of the radar display changes to TRANSMIT . Note: The radar does not start transmission if you press [TX/PRF] key while PREHEAT is indicated.

  • Page 95: Tune

    3.4 BASIC OPERATIONS 3.4.4 Tune Caution Always use the automatic tuning mode. Use the manual tuning mode only when the automatic tuning mode does not provide the best tuning state due to deterioration of magnetron for example. There are automatic tuning mode and manual tuning mode. In the automatic tuning mode, transmission and receiving frequencies are tuned and adjusted automatically.

  • Page 96: Control Sensitivity [Gain/Pl]

    3.4.5 Control Sensitivity [GAIN/PL] Caution If sensitivity is set too high, unnecessary signals such as noises in the receiver and false echoes increase to lower target visibility. At the same time, if sensitivity is set too low, detection of targets such as ships and dangerous objects may be hindered.

  • Page 97: Suppress Sea Clutter [Auto-Sea]

    3.4 BASIC OPERATIONS 3.4.6 Suppress Sea Clutter [AUTO-SEA] Caution When using the [AUTO SEA] function, never set the suppression level too high canceling out all image noises from the sea surface at close range. Detection of not only echoes from waves but also targets such as other ships or dangerous objects will become inhibited.
  • Page 98 Cancellation Press the [AUTO-SEA] control. AUTO SEA is deselected, SEA AUTO at the lower left of the radar display changes to SEA MAN , and AUTO SEA is cancelled. * Software button located at the bottom left corner of the radar display described in Section 2.3.2 is also available to switch AUTO/MANUAL.

  • Page 99: Suppress Rain/Snow Clutter [Auto-Rain]

    3.4 BASIC OPERATIONS 3.4.7 Suppress Rain/Snow Clutter [AUTO-RAIN] Caution When using the [AUTO RAIN] function, never set the suppression level too high canceling out all image noises from the rain or snow at the close range. Detection of not only echoes from the rain or snow but also targets such as other ships or dangerous objects will become inhibited.
  • Page 100 Cancellation Press the [AUTO-RAIN] control. AUTO RAIN is deselected, RAIN AUTO at the lower left of the radar display changes to RAIN MAN , and AUTO RAIN is cancelled. * Software button located at the bottom left corner of the radar display described in Section 2.3.2 is also available to switch AUTO/MANUAL.

  • Page 101: Reject Radar Interference [Ir]

    3.4 BASIC OPERATIONS 3.4.8 Reject Radar Interference [IR] Use this function to eliminate interference waves from other radars. Attention z When viewing a radar beacon or SART signal, select IR OFF (Interference Rejector OFF) because IR processing suppresses the video. Procedure Press [RADAR MENU] key twice.

  • Page 102: Hide/Display Range Rings (Rings)

    3.4.9 Hide/Display Range Rings (RINGS) Procedure Press [RR/HL] key. The range rings display switches back and forth between display and non-display each time [RR/HL] key is pressed. The scale unit is shown on the Range rings display On / Off button (software button located at the top left corner of the radar display described in Section 2.3.1).

  • Page 103: Hide Graphics Information On Radar Display (Graphic Display)

    3.4 BASIC OPERATIONS 3.4.11 Hide Graphics Information on Radar Display (Graphic Display) Procedure Press [RADAR MENU] key. The Main Menu will appear. Press [8] key. The setting of Graphic Display will be changed to ON . Graphics information other than VRMs, EBLs, HL, cross cursor mark, and range rings on the radar display is temporarily hidden.

  • Page 104: General Operations

    GENERAL OPERATIONS 3.5.1 Move Cross Cursor Mark by Trackball The cross cursor mark is used for position designation and other purposes in various operating procedures. The cross cursor mark + moves in coupling with the trackball. If the trackball is rotated up and down or right and left, the cross cursor mark follows the move of the trackball.

  • Page 105: Use Ebls (Electronic Bearing Lines) [Ebl1/2]

    3.5 GENERAL OPERATIONS 3.5.2 Use EBLs (Electronic Bearing Lines) [EBL1/2] EBLs (Electronic Bearing Lines) are indispensable to the measurement of bearings. Operators must be familiar with the operation of EBLs beforehand. EBL1 Operation If EBL2 is selected or EBL1 is not displayed, press [EBL1] key to select EBL1 before starting operation. (The currently selected EBL is shown in reverse video at the lower right of the radar display.) Procedure Press [EBL1] key.
  • Page 106 EBL Bearing Display The bearing values of EBL1 and EBL2 currently displayed on the PPI are indicated at the upper right of the radar display. The currently operable EBL1 or EBL2 is shown in reverse video beside the bearing value. Starting Point of EBL The starting point of the currently operating EBL can be switched from the center of the radar display (Floating Off) to any floating position.
  • Page 107 3.5 GENERAL OPERATIONS [II] Moving the starting point of EBL1 to the own ship’s position while EBL1 is operating: Procedure Press the [EBL] control twice. The letter on the right hand side of the EBL value at the top right corner of the screen disappears.

  • Page 108: Set Ebl Operation (Ebl1 /2 Setting)

    3.5.3 Set EBL Operation (EBL1 /2 Setting) [I] Setting the bearing display mode of EBL1 (EBL1 Bearing REF) Determine whether to display EBLs (Electronic Bearing Lines) in true bearing mode or relative bearing mode. Procedure Press [RADAR MENU] key. Press [3] key Press [1] key.
  • Page 109 3.5 GENERAL OPERATIONS [III] Setting the mode to move the starting point of EBL1 (EBL1 Floating) When this function is set to L/L FIX and the starting point of an EBL is moved to a position, the starting point can be fixed at the latitude and longitude of that position. The function is effective when the bearing from a certain point is repeatedly measured.
  • Page 110 [V] Setting the EBL1 bearing fix mode (EBL1 Bearing FIX) While this function is set to ANGLE , an EBL is fixed to the preset bearing. For example, if the true bearing 020q is preset, the EBL is fixed to the true bearing 020q even when the own ship turns. While the function is set to SCREEN , the EBL is fixed on the radar display.

  • Page 111: Display Variable Range Markers [Vrm1/Vrm2]

    3.5 GENERAL OPERATIONS 3.5.4 Display Variable Range Markers [VRM1/VRM2] This function is to display and select variable range markers (VRMs). Two VRMs are available: VRM1 is represented as a broken line, and VRM2 as a dotted line. When EBL1 is displayed, VRM1 marker appears on the EBL1.
  • Page 112 VRM2 Operation If VRM1 is selected or VRM2 is not displayed, press [VRM2] key to select VRM2 before starting operation. (The currently selected VRM is shown in reverse video at the upper right of the radar display.) Procedure Press [VRM2] key. VRM2 at the upper right of the radar display will be shown in reverse video, and VRM2 becomes operable.
  • Page 113 3.5 GENERAL OPERATIONS VRM2 range unit Procedure Press [RADAR MENU] key. Press [3] key. The Marker Setting Menu will appear. Press [4] key. The VRM2 Range Unit Setting Menu will appear. Select the item you want to set, pressing the numeric keys [1] to [3]. The selected item will be set.

  • Page 114: Display Parallel Cursors (Parallel Cursor)

    3.5.5 Display Parallel Cursors (Parallel Cursor) Parallel cursors can be displayed. Procedure Hold down [VRM] control. Jog Dial Button Mode opens. Select 3 PC Menu in the Right Jog Dial menu, and set the parallel index lines as the right jog dial mode. After setting the parallel index lines as the right jog dial mode, press the [VRM] control.
  • Page 115 3.5 GENERAL OPERATIONS Operation of Parallel Cursors Parallel cursors rotate in the same direction as you turn the [EBL] control. The intervals of parallel cursors narrow when you turn the [VRM] control counterclockwise ( ), and widen when you turn the [VRM] control clockwise ( ). Display of Parallel Cursors When [RADAR MENU] key is pressed, the parallel cursor menu closes and the parallel cursors are fixed.
  • Page 116 Setting of Parallel Cursors (Parallel Cursor) [I] Parallel Cursor Range Link (Range Scale Link) When a range is switched, parallel cursors links to a radar range scale and displayed. Procedure Press [RADAR MENU] key. Press [3] key. Press [5] key. Press [2] key.
  • Page 117 3.5 GENERAL OPERATIONS [II] Parallel Cursor Bearing (Reference Bearing) Parallel cursor bearing mode can be switched. Procedure Press [RADAR MENU] key. Press [3] key. Press [5] key. Press [2] key. The Parallel Cursor Menu will appear. Press [2] key. The Reference Bearing mode is switched between true bearing and relative bearing each time you press [2] key.
  • Page 118 [III] Parallel Cursor Start Point Display Mode (Floating) If this function is set to L/L FIX, and the start point of parallel cursor moves, the start point of the parallel cursor can be fixed to the latitude/longitude of the start point. If the function is set to SCREEN FIX, the start point of parallel cursor is fixed within the radar display, and the start point is fixed to the same place on the display even after the own ship moves.
  • Page 119 3.5 GENERAL OPERATIONS [IV] Parallel Cursor Bearing Fix Mode (Bearing Mode) If this function is set to ANGLE , the parallel cursor also rotates in accordance with the bearing while the own ship is turning. If the function is set to SCREEN FIX , the parallel cursors are fixed within the radar display even while the own ship is turning.
  • Page 120 [V] Individual Display of Parallel Cursor (PI Individual) Individual parallel cursors can be switched between ON and OFF. Procedure Press [RADAR MENU] key. Press [3] key. Press [5] key. Press [2] key. The Parallel Cursor Menu will appear. Press [5] key. DIPS For Individual Line Setting Menu will appear.

  • Page 121: Display Parallel Index Lines (Parallel Index Line)

    3.5 GENERAL OPERATIONS 3.5.6 Display Parallel Index Lines (Parallel Index Line) Parallel index lines can be displayed. Up to 4 parallel index lines can be set. For each line, angle, distance to own ship, and length can be specified. Changing the angle of parallel index lines Procedure Hold down [VRM] control.
  • Page 122 Changing the interval (distance from own ship) and length of parallel index lines Procedure Press the [VRM] control. Turn the mode on using the jog dial. Press the jog dial to turn the mode on. Turn the mode on from the menu screen. Turn the mode on by following the steps below: Press the [Radar Menu] key.
  • Page 123 3.5 GENERAL OPERATIONS Setting of Parallel Index Lines (Parallel Index Line) [I] Parallel Index Line Range Link (Range Scale Link) When a range is switched, parallel index lines links to a radar range scale and displayed. Procedure Press [RADAR MENU] key. Press [3] key.
  • Page 124 [II] Parallel Index Line Bearing (Reference Bearing) Parallel index line bearing mode can be switched. Procedure Press [RADAR MENU] key. Press [3] key. Press [5] key. Press [3] key. The Parallel Index Line Menu will appear. Press [2] key. The Reference Bearing mode is switched between true bearing and relative bearing each time you press [2] key.
  • Page 125 3.5 GENERAL OPERATIONS [III] Parallel Index Line Start Point Display Mode (PI Floating) If this function is set to L/L FIX, and the start point of parallel index line moves, the start point of the parallel index line can be fixed to the latitude/longitude of the start point. If the function is set to SCREEN FIX, the start point of parallel index line is fixed within the radar display, and the start point is fixed to the same place on the display even after the own ship moves.
  • Page 126 [IV] Parallel Index Line Bearing Fix Mode (PI Bearing Mode) If this function is set to ANGLE , the parallel index line also rotates in accordance with the bearing while the own ship is turning. If the function is set to SCREEN FIX , the parallel index lines are fixed within the radar display even while the own ship is turning.
  • Page 127 3.5 GENERAL OPERATIONS [V] Individual Display of Parallel Index Line (PI Individual) Individual parallel index lines can be switched between ON and OFF. Procedure Press [RADAR MENU] key. Press [3] key. Press [5] key. Press [3] key. The Parallel Index Line Menu will appear. Press [5] key.

  • Page 128: Switch Bearing Display Mode [Azi Mode]

    3.5.7 Switch Bearing Display Mode [AZI MODE] Select the azimuth for the radar video to be displayed of the display. The bearing display mode is switched in the sequence of [NORTH UP] (true bearing), [HEAD UP] (relative bearing), and [COURSE UP] (course-up bearing) each time [AZI MODE] key is pressed. The indication at the upper left of the radar display changes in sequence of HUP o NUP o CUP .

  • Page 129: Switch True/Relative Motion Display Mode [Tm/Rm]

    3.5 GENERAL OPERATIONS 3.5.8 Switch True/Relative Motion Display Mode [TM/RM] Note: If the CCRP is outside the display area due to resetting of the own ship position in true motions, the CCRP becomes the antenna location. Switching Relative Motion (RM) Mode to True Motion (TM) Mode Procedure Press [TM/RM] key.

  • Page 130: Move Own Ship's Display Position [Off Cent]

    3.5.9 Move Own Ship’s Display Position [OFF CENT] The own ship’s position can be moved from the display center to any position within 66% of the display radius. This function is convenient for observing a wide coverage in any direction. Note: This function is not available on the 96 NM range.

  • Page 131: Display Radar Trails (Other Ships' Trails) [Trails]

    3.5 GENERAL OPERATIONS 3.5.10 Display Radar Trails (Other Ships’ Trails) [TRAILS] Other ships’ movements and speeds can be monitored from the lengths and directions of their trails, serving for collision avoidance. The trail length varies according to setting. The setting is described on the next page. Changing the trail length Procedure Trail length setting in SHORT mode:...
  • Page 132 SHORT mode: 15 sec, 30 sec, 1 min, 3 min, 6 min, 10 min, 15 min, and CONT MID mode: 30 sec, 1 min, 3 min, 6 min, 10 min, 15 min, 30 min, and CONT LONG mode: 1 min, 3 min, 6 min, 10 min, 15 min, 30 min, 60 min, and CONT SUPER LONG mode: 30 min, 1 hr, 2 hr, 3 hr, 4 hr, 5 hr, 6 hr, 7 hr, 8 hr, 9 hr, 10 hr, 11 hr, 12 hr and CONT A trail length can also be changed by using the multi-function control.
  • Page 133 3.5 GENERAL OPERATIONS Trails modes provided with this system vary depending on the motion mode. With true motion (TM) mode: Only the true motion trails mode is available. With relative motion (RM) mode: The relative motion trails mode or true motion trails mode is selectable.

  • Page 134: Switch Pulse Length (Gain/Pl)

    3.5.11 Switch Pulse Length (GAIN/PL) Procedure Press the [GAIN / PL] dial. Values of the transmitter pulse length are switched. MP1 Ÿ MP2 Ÿ LP1 Ÿ LP2 Ÿ MP1 Example Effects of transmitter pulse length With SP selected: The transmitter pulse becomes shorter, and the range resolution improves. The effect of suppressing sea clutter returns and rain / snow clutter returns heightens.

  • Page 135: Expand Targets (Target Enhance)

    3.5 GENERAL OPERATIONS 3.5.12 Expand Targets (Target Enhance) The dimension of video display is enlarged to enhance a target. Procedure Press [RADAR MENU] key twice. The Radar Menu will appear. Press [3] key. The Target Enhance Selection Menu will appear. Select the mode number to be set, pressing the numeric keys [1] to [4].

  • Page 136: Use Video Process (Process)

    3.5.13 Use Video Process (Process) This function reduces unnecessary noise to highlight targets. Attention z When viewing a radar beacon, SART signal, or fast moving target on the radar display, select PROC Off (video processing off). z If video processing mode is set to CORREL , it may be difficult to detect high speed target.

  • Page 137: Zoom

    3.5 GENERAL OPERATIONS 3.5.14 Zoom This function doubles the size of radar video near a specified position. Note: If the range is 0.125 NM , this function is not available. If the true motion mode is selected, this function is not available. Procedure Press [RADAR MENU] key twice.

  • Page 138: Use Marker [Mob]

    3.5.15 Use Marker [MOB] The marker function displays a dotted line from the marker input position to the own ship’s position, and indicates the range, bearing, and required time from the own ship to the marker. Procedure Press [MOB] key. A marker will be displayed at the own ship’s position on the radar display at the moment when [MOB] key is pressed.

  • Page 139: Marking [Mark]

    3.5 GENERAL OPERATIONS 3.5.16 Marking [MARK] A maximum of 20 marks can be indicated at arbitrary positions on the radar display. A mark created on the radar display holds the latitude and longitude. [I] Creating Marks Procedure Press [MARK] key. [ ] will appear in the CURSOR field at the upper right of the radar display.

  • Page 140: Operate Ebl Maneuver Function (Ebl Maneuver)

    3.5.17 Operate EBL Maneuver Function (EBL Maneuver) [I] Initial Setting (Reach,Turn Mode, Turn Set) Procedure Press [RADAR MENU] key. Press [3] key. Press [7] key. The EBL Maneuver Setting Menu will appear. Press [2] key. The CODE INPUT Menu will appear. Enter the Reach value and select ENT.
  • Page 141 3.5 GENERAL OPERATIONS [II] Creating Maneuver Curve (EBL Maneuver) Procedure Press [1] key while the EBL Maneuver menu is open. EBL Maneuver will be set to ON. A supplemental line, a maneuver curve, and WOL will appear on the radar display. Set the starting point of the supplemental line using the trackball, and set the bearing of the supplemental line using the [EBL] control.

  • Page 142: Operate Multi-Function Control [Multi]

    3.5.18 Operate Multi-Function Control [MULTI] The multi-function control [MULTI] is provided to change the settings of parameters such as the length of radar trails. Turn the control to select a parameter. Radar operation is simplified by using the control. [I] Initial Setting (Multi Dial Setting) Set parameters that can be operated with the multi-function control.
  • Page 143 3.5 GENERAL OPERATIONS [II] Using Multi-function Control Procedure Press the [MULTI] control to select the parameter whose setting is to be changed. Parameters will be selected sequentially each time the [MULTI] control is pressed. The currently selected parameter is indicated at the lower left of the radar display. For example, if three parameter 1-3 are initially set to ON , they are selected in the following sequence each time the [MULTI] control is pressed: MULTI (VECTOR)

  • Page 144: Operate User Key Switches [User Key 1/2]

    3.5.19 Operate User Key Switches [User Key 1/2] Users can freely make settings with [USER KEY1] key and [USER KEY2] key. By using the switches, users can open a frequently used menu by only single operation, or assign special functions, which are not on the standard operation panel, to the user key switches. [I] Initial Setting (User Key Setting) Set functions that can be performed with the user key switches.
  • Page 145 3.5 GENERAL OPERATIONS [II] Using User Key Switches (Directly displaying a specified menu) Preset the menu that is to be displayed with the user key switch. Setting the menu that is to be displayed with User Key 1: Procedure Perform the general menu open procedure to open the menu that is to be directly displayed with User Key 1.

  • Page 146: Automatic Acquisition

    3.5.20 Automatic Acquisition Note: If the number of targets being tracked has reached the allowable maximum and other targets (not being tracked) go into the acquisition/activation zone, automatically acquired targets are canceled in ascending order of danger. Turning On / Off the automatic acquisition and AIS activation (AZ Menu) Procedure Press the [TT Menu] key.
  • Page 147 3.5 GENERAL OPERATIONS Creating the automatic acquisition and AIS activation Zone Procedure Press the [TT Menu] key. TT Menu opens. Press the [5] key. Press the [1] key. Acquisition / activation zone setting menu (AZ) opens. Press the [3] or [4] key. The range setting of the acquisition / activation zone 1 (AZ1) or acquisition / activation zone 2 (AZ2) will be started.
  • Page 148 Setting the [AZ] key allocation (Set AZ Key) A generally used acquisition / activation zone can be turned on / off by simply pressing the [AZ] key. Procedure Press the [TT Menu] key. TT Menu opens. Press the [5] key. Press the [3] key.

  • Page 149: Radar Alarm (Radar Alarm)

    3.5 GENERAL OPERATIONS 3.5.21 Radar Alarm (Radar Alarm) With a fan-shaped range made, the radar alarm can give an alarm to ships that enter or depart from the range. [I] Display Sector Alarm (Sector Alarm 1, 2) Display a created Sector Alarm. Procedure Press [TT MENU] key.
  • Page 150 [II] Set Radar Alarm Mode (Radar Alarm Mode) For alarm issuing conditions for the radar alarm, set either entry or departure. Procedure Press [TT MENU] key. The TT Menu will appear. Press [5] key. Press [2] key. The Radar Alarm Menu will appear. Press [5] key.
  • Page 151 3.5 GENERAL OPERATIONS [III] Set Radar Alarm Detection Level (Sensitivity Level) Detection levels can be set to issue alarms from the radar alarm. Procedure Press [TT MENU] key. The TT Menu will appear. Press [5] key. Press [2] key. The Radar Alarm Menu will appear. Press [6] key.
  • Page 152 [IV] Make Sector Alarm (Make Sector Alarm) Sector alarms that can be made are divided into the two types. Procedure Press [TT MENU] key. The TT Menu will appear. Press [5] key. Press [2] key. The Radar Alarm Menu will appear. Press [3] key.
  • Page 153 3.5 GENERAL OPERATIONS Setting RADAR Alarm Key Assignment (Set AZ Key) This section explains how to set a RADAR alarm that is to be assigned to the [AZ] key. The setting enables the operator to select ON/OFF for a generally used RADAR alarm by simply operating the [AZ] key on the control panel.

  • Page 154: Use Own Ship's Track Data (Own Track)

    USE OWN SHIP'S TRACK DATA (OWN TRACK) The own ship's track function saves and displays own ship's track. If navigation equipment is connected, this radar system records latitude / longitude data sent from the navigation equipment and displays own ship's track. Note: Even when own ship's track interval switching (software button located at the bottom right corner of the radar display described in Section 2.3.4) is set to...
  • Page 155 3.6 DISPLAY OWN SHIP'S TRACK (OWN TRACK) 2 Select Own ship tracks by the color. (Display Own Track Color) Procedure Press [RADAR MENU] key. Press [9] key. Press [1] key. The Own Track Setting Menu will appear. Press [2] key. The track color list is displayed.

  • Page 156: Set Own Ship's Track Data Storage Interval (Own Track Interval)

    3.6.2 Set Own Ship’s Track Data Storage Interval (Own Track Interval) There are 10 preset time intervals and 8 preset range intervals that can be selected for storing own ship’s track data. Procedure Press [RADAR MENU] key. Press [9] key. Press [1] key.

  • Page 157: Cancel Storing Of Own Ship's Track Data (Own Track Memory)

    3.6 DISPLAY OWN SHIP'S TRACK (OWN TRACK) 3.6.3 Cancel Storing of Own Ship’s Track Data (Own Track Memory) This function cancels the storing of own ship’s track data. Procedure Press [RADAR MENU] key. Press [9] key. Press [1] key. The Own Track Setting Menu will appear. Press [4] key.

  • Page 158: Clear Own Ship's Track Data (Clear Own Track)

    3.6.4 Clear Own Ship’s Track Data (Clear Own Track) This function clears own ship’s track data from memory. Procedure Press [RADAR MENU] key. Press [9] key. Press [1] key. The Own Track Setting Menu will appear. Press [3] key. The Own Track color list will appear. Select the track color to be cleared, pressing the numeric key.

  • Page 159: Display Charts

    3.7 DISPLAY CHARTS DISPLAY CHARTS 3.7.1 Insert/Remove a Card Insert or remove the JRC coastline ROM card, ERC card, C-MAP card and memory card according to the procedures below. Note: Keep a card horizontal when inserting it into a card slot. An inclined card causes a failure. Do not simultaneously insert a JRC coastline ROM card, an ERC card and C-MAP card into the card slot.
  • Page 160 Insert the card in the direction indicated by the arrow. Insert the card until the card slot's eject button protrudes and complete the installation of a card. Eject a card from processor unit Procedure Push the eject button corresponding to the desired card slot. remove a card from processor unit 3 81...

  • Page 161: Display Coastline Rom Card Produced By Jrc

    JRC’s Coastline ROM card is in the other slot. Doing so causes display trouble. CDD-612JKA Coastline ROM Card Area: Kanto and Tokai Districts (1) Kanto Japan Radio Co., Ltd. Upper: Card slot 2 Lower: Card slot 1 Top surface Insert into card slot 1 or 2.

  • Page 162: Display Erc Card

    3.7.3 Display ERC Card z Insert the ERC card (provided by Japan Hydrographic Association) with the top surface upward into card slot 1 (lower) or 2 (upper) as shown in the figure below. Press [MAP] key, and the coastlines will be displayed automatically.

  • Page 163: Fill Charts (Fill Land Area)

    3.7 DISPLAY CHARTS 3.7.4 Fill Charts (Fill Land Area) This function fills the chart when JRC/ERC card is in use. Procedure Press [RADAR MENU] key. Press [9] key. Press [5] key. The Map Setting Menu will appear. Press [1] key. The setting of Fill Land Area will be switched between ON and OFF.

  • Page 164: Display Navigation Information (Nav Information Display)

    DISPLAY NAVIGATION INFORMATION (NAV INFORMATION DISPLAY) Navigation information such as waypoint marks, and a maximum of 256 points of NAV lines, coastlines, depth contours, and NAV marks can be displayed, created, read, saved, corrected, and deleted. (This function is available only when navigation equipment is connected with the system.) Note: Navigation information is available between latitudes of 85ºN and 85ºS.

  • Page 165: Display Navigation Information (Nav Display Setting)

    3.8 DISPLAY NAVIGATION INFORMATION (NEW INFORMATION DISPLAY) 3.8.2 Display Navigation Information (NAV Display Setting) The navigation information below can be displayed (ON) or hidden (OFF) individually. c Line 1 [Line 1] d Line 2 [Line 2] ---- e Line 3 [Line 3] f Mark 1 [Mark 1] g Mark 2 [Mark 2] h Mark 3 [Mark 3]...

  • Page 166: Create/Edit Navigation Information (Edit User Map)

    3.8.3 Create/Edit Navigation Information (Edit User Map) Procedure Press [RADAR MENU] key. Press [6] key. Press [3] key. Press [6] key. The Edit User Map Menu will appear. The Edit User Map enables the operations of the functions below. Clear Map Object: Clears all or an item of navigation information.
  • Page 167 3.8 DISPLAY NAVIGATION INFORMATION (NEW INFORMATION DISPLAY) 1 Clearing all or an item of navigation information (Clear Map Object) Procedure Press [1] key while the Edit User MAP Menu is open. The Clear Map Object Menu will appear. Select the type of navigation information to be cleared, pressing the corresponding numeric key.
  • Page 168 2 Making navigation information (Make Map Object) Procedure Press [2] key while the Edit User MAP Menu is open. The Make Map Object Menu will appear. MAKE will appear in the CURSOR mode field at software button located at the bottom right corner of the radar display described in Section 2.3.4.
  • Page 169 3.8 DISPLAY NAVIGATION INFORMATION (NEW INFORMATION DISPLAY) 3 Correcting a continuous line or moving a mark (Correct) Procedure Press [3] key while the Edit User Map Menu is open. The navigation information correction mode will be activated. Correct will appear in the CURSOR mode field at software button located at the bottom right corner of the radar display...
  • Page 170 4 Deleting a continuous line or mark (Delete) Procedure Press [4] key while the Edit User Map Menu is open. The navigation information deletion mode will be activated. Delete will appear in the CURSOR mode field at software button located at the top right corner of the radar display described in Section 2.3.3.
  • Page 171 3.8 DISPLAY NAVIGATION INFORMATION (NEW INFORMATION DISPLAY) 5 Inserting a vertex into a line (Insert) Procedure Press [5] key while the Edit User MAP Menu is open. The navigation information insertion mode will be activated. Insert will appear in the CURSOR mode field at software button located at the top right corner of the radar display described in...

  • Page 172: Set Navigation Information (User Map Setting)

    3.8.4 Set Navigation Information (User Map Setting) Procedure Press [RADAR MENU] key. Press [6] key. Press [3] key. The User Map Setting Menu will appear. Select operation for navigation information, pressing the corresponding numeric key. The selected operation will be performed. Load: Loads navigation information.
  • Page 173 3.8 DISPLAY NAVIGATION INFORMATION (NEW INFORMATION DISPLAY) [I] Entering the own ship’s position in manual mode (Own Ship Position) Use this function to edit the navigation information of any positions other than the own ship’s position. Procedure Press [1] key while the User Map Setting Menu is open.
  • Page 174 [II] Loading navigation information (Load User Map) Procedure Press [2] key while the User Map Setting Menu is open. The Load User Map Menu will appear. Press [2] key. The list of navigation information files saved in the system will appear. * Each time you press [1] key, the Device item is switched between INTERNAL and CARD2.
  • Page 175 3.8 DISPLAY NAVIGATION INFORMATION (NEW INFORMATION DISPLAY) [III] Initializing Navigation Information (Unload) Procedure Press [3] key while the User Map Setting Menu is open. Display the window to select whether or not the information is to be initialized. Press [1] key. The navigation information is initialized.
  • Page 176 [IV] Saving navigation information (Save User Map) This function is available only when navigation equipment is connected with the system or the own ship’s position is entered in manual mode. Procedure Press [4] key while the User Map Setting Menu is open. Press [2] key.
  • Page 177 3.8 DISPLAY NAVIGATION INFORMATION (NEW INFORMATION DISPLAY) [V] Erasing navigation information from memory (Erase User Map) Procedure Press [5] key while the User Map Setting Menu is open. Press [2] key. The Erase User Map Menu will appear. * Each time you press [1] key, the Device item is switched between INTERNAL and CARD2.
  • Page 178 [VI] Shifting the display position of navigation information to a correct position (Shift) If the display position of navigation information is incorrect, it can be shifted to the correct position in manual mode. Procedure Press [7] key while the User Map Setting Menu is open.

  • Page 179: Set And Display Geodetic System

    3.8 DISPLAY NAVIGATION INFORMATION (NEW INFORMATION DISPLAY) 3.8.5 Set and Display Geodetic System To create navigation information, set the geodetic system that is used with the connected navigation equipment. When navigation information is loaded, the geodetic system used when the navigation information was saved, is displayed.
  • Page 180 Geodetic System List Name Data Display WGS-84 WGS-84 WGS-72 WGS-72 Japan Japan North American 1927(U.S) North American 1927(Canada & Alaska) European 1950 (Europe) Australian geodetic 1966 (Australia) Ordance Survery of Great Britain (England) NAD-83 NAD-83 - (No Use) - (No Use) ADINDAN (Etiopia &...

  • Page 181: Applied Operations

    3.9 APPLIED OPERATIONS APPLIED OPERATIONS 3.9.1 Set Radar Signal Processing (Process Setting) This function enables the setting of detail information about radar signal processing. Procedure Press [RADAR MENU] key twice. Press [6] key. The Process Setting Menu will appear. Detail information about radar signal processing can be set by changing the settings of the menu items.
  • Page 182 [2] Video Noise Rejection x This function rejects signals that assumed as noise and clutter in radar videos. x Select OFF to display radar videos like analog signals. x Select LEVEL1 or LEVEL2 to suppress noise and clutter. x Select LEVEL1 or LEVEL2 to superimpose-display the chart.
  • Page 183 3.9 APPLIED OPERATIONS [5] 2nd Process Mode x Set the second video process mode for the outside of a specific area. x This function is enabled when RANGE FIX or AUTO is selected in [4] Process Switching. Video process modes PROC OFF Correlation Off :...

  • Page 184: Set Radar Trails (Radar Trails Setting)

    3.9.2 Set Radar Trails (RADAR Trails Setting) This function enables the setting of detail information about radar trails processing. Procedure Press [RADAR MENU] key twice. Press [7] key. Alternatively, hold down the [TRAILS] key until the menu appears. The RADAR Tails Setting Menu will appear. Detail information about radar trails processing can be set by changing the settings of the menu items.
  • Page 185 3.9 APPLIED OPERATIONS [4] Trails Reduction x Make a setting for thinning radar trails. x The effect of thinning increases in order of LEVEL1 o LEVEL2 o LEVEL3 . x Radar videos do not become obscure because of the thinning of radar trails. OFF : Disables the Trails Reduction function.
  • Page 186 Load and save of the Rdar trails. Procedure Press [RADAR MENU] key twice. Press [7] key. Alternatively, hold down the [TRAILS] key until the menu appears. Press [9] key. The RADAR Tails Setting Menu will appear. [1] Loading Trails File x Presse [1] key.
  • Page 187 3.9 APPLIED OPERATIONS [3] Erasing Trails File x Presse [3] key. The saved trail files are displayed. x Select the file to be erased. Confirmation warining is displayed. Select “Yes” for erasing. Note: Deleted files can not be restored, so Erase files carefully. Erasing the displayed trails partially.
  • Page 188 [3] Eraser Size Press [3] key. Eraser size lit is displayed. Select the size of the eraser. : 2x2 pixels : 4x4 pixels : 8x8 pixels 16x16 : 16x16 pixels 32x32 : 32x32 pixels 3 109...

  • Page 189: Set Cursor (Cursor Setting)

    3.9 APPLIED OPERATIONS 3.9.3 Set Cursor (Cursor Setting) This function enables the setting of detail information about cursor operation and display. Procedure Press [RADAR MENU] key. Press [3] key. Press [6] key. The Cursor Setting Menu will appear. Detail information about cursor operation and display can be set by changing the settings of the menu items.
  • Page 190 [2] Cursor Length x Set the length of the cross cursor mark on the radar display. SHORT : Cuts the cross cursor mark in length. LONG : Makes the cross cursor mark twice as long as when SHORT is selected. [3] Cursor Pattern x The type of the cross cursor mark displayed of the display is selected.

  • Page 191: Set Screen(Screen Setting)

    3.9 APPLIED OPERATIONS 3.9.4 Set Screen(Screen Setting) This function enables the setting of detail information about screen display. Procedure Press [RADAR MENU] key. Press [4] key. The Screen Setting Menu will appear. Detail information about screen display can be set by changing the settings of the menu items. Graph Display Press the graph button to see the registered graph.
  • Page 192 [3] Graph Settings (Graph Panel Setting) Set the functions of a graph to be associated with the graph button. The function shown in the parentheses is prioritized. Therefore, specify a graph to be displayed while the prioritized function is not active. 1.
  • Page 193 3.9 APPLIED OPERATIONS Wind/Current Graph x The wind direction and speed display function (Wind) is registered with the graph button when "Wind" is selected in the graph setting menu. x Press the Wind button to call up numerical values and a graph for the received wind direction and speed information.
  • Page 194 Depth Graph Display x The water depth display function (Depth) is registered with the graph button when "Depth" is selected in the graph setting menu. x Press the Depth button to call up numerical values and a graph for the received water depth information.
  • Page 195 3.9 APPLIED OPERATIONS Depth Range x Select the depth range on the water depth graph. 50m : Sets 50 m as the depth range. 100m : Sets 100 m as the depth range. 250m : Sets 250 m as the depth range. AUTO : Uses the depth range in the DPT sentence included in received data.
  • Page 196 Water Temperature Display (Temp Graph) x The water temperature display function (Temp) is registered with the graph button when "Temp" is selected in the graph setting menu. x Press the Temp button to call up numerical values and a graph for the received water temperature information.

  • Page 197: Screen Capture Setting

    3.9 APPLIED OPERATIONS Screen Capture Setting x This equipment can save the currently displayed images onto a memory card (CF card) while they are in bitmap format. x In order to execute this item, a memory card (optional) must be inserted in the card slot 2 (upper slot) beforehand.
  • Page 198 [II] File Erase Screen capture files can be deleted. If the CF card is full, screen capture files which are no longer necessary can be deleted by specifying the file name (date and time). Procedure Press [RADAR MENU] key. Press [4] key. Press [9] key.
  • Page 199 3.9 APPLIED OPERATIONS [III] AUTO Capture Interval This function automatically saves a screen capture file at specified time intervals. Time intervals can be specified in minutes. Note: The use of the automatic capture function applies a high load to the CPU. As a result, processing is always slow, so use the automatic capture function only when needed.
  • Page 200 [IV] AUTO File Erase When a CF card is full with screen capture files saved, this function automatically erases files, starting with the oldest one. Procedure Press [RADAR MENU] key. Press [4] key. Press [9] key. Press [1] key. The Screen Capture Setting menu will appear. Press [4] key.

  • Page 201: Set Scanner (Txrx Setting)

    3.9 APPLIED OPERATIONS 3.9.5 Set Scanner (TXRX Setting) This function enables the setting of detail information about a scanner Procedure Press [RADAR MENU] key. Press [5] key. The TXRX Setting Menu will appear. Detail information about antenna operation can be set by changing the settings of the menu items.
  • Page 202 [5] Band Select x Select band of antenna. This item is effective only when the antenna in connection supports two frequencies. X-Band : Selects the X-band side from the two frequencies. S-Band : Selects the S-band side from the two frequencies. X/S-band : Supports the two frequencies.

  • Page 203: Set Chart Display (Map Setting)

    3.9 APPLIED OPERATIONS 3.9.6 Set Chart Display (Map Setting) This function enables the setting of detail information about chart display. Setting JRC/ERC Chart Display (JRC/ERC Setting) Procedure Press [RADAR MENU] key. Press [9] key. Press [5] key. Or, hold down the [Map] key. Sea chart menu (Map Setting) opens.
  • Page 204 [5] Bright of Sea x Select the brilliance of sea display. x There are four selection items: OFF , LOW , MEDIUM , and HIGH . Note: This function is available on the plotter mode only. [6] Color of Name x Select the color of a location name.
  • Page 205 3.9 APPLIED OPERATIONS [3] Bright of L/L Line x Select the brilliance of latitude/longitude line display. x There are four selection items: OFF , LOW , MEDIUM , and HIGH . [4] ERC Display Request x Display of the information within ERC can be switched between ON and OFF . x There are two selection items: ON , and OFF .
  • Page 206 [4] Other Line x Determine whether to display other lines. x There are two selection items: ON and OFF . : Other lines are displayed. : Other lines are not displayed. [7] Copy JRC Chart to CF By copying multiple JRC coastline ROM cards onto a compact flash memory card, this function selectively displays any two charts among the copied charts.
  • Page 207 3.9 APPLIED OPERATIONS [8] Fishing Area Display If a fishery card is used but the fishery is not displayed, this setting gives priority to the fishery card. : Select this item if the fishery card is inserted in the card slot but the fishery is not displayed. The fishery is displayed by giving priority to the fishery card over other cards.
  • Page 208 Set C-MAP Display Procedure Press [RADAR MENU] key. Press [9] key. Press [5] key. Or, hold down the [Map] key. The MAP Setting Menu will appear. Press [2] key. The C-MAP Setting Menu will appear. [1] Grid Display x Sets whether or not latitudinal longitudinal lines are displayed with C-MAP. x Each time you press [1] key, the grid display item is switched between ON and OFF.
  • Page 209 3.9 APPLIED OPERATIONS [5] Light Sectors Level x Sets levels when light sectors are displayed with C-MAP. x Press [5] key to display a list of levels. x Selects one from level settings A to H. [6] Chart Boundaries x Sets whether or not the Chart Boundaries are displayed. x Each time you press [6] key, the function is switched between ON and OFF.
  • Page 210 [1] Land Marks x Sets whether or not the Land Marks are displayed. x Each time you press [8] key, the Land Marks is switched between ON and OFF. x ON: Displayed OFF: Not displayed [2] Rivers and Lakes x Sets whether or not the Inland waters are displayed. x Each time you press [8] key, the Rivers and Lakes is switched between ON and OFF.
  • Page 211 3.9 APPLIED OPERATIONS Correcting Chart Position (Map Display Setting) Caution When the chart position is corrected, the display will be shifted away from the actual position. With this in mind, navigate your ship with attention to the surroundings. Otherwise, this may cause accidents. Procedure Press [RADAR MENU] key.
  • Page 212 Cancellation of Shift Coast Line 1 Press [1] key while the MAP Display Setting Menu is open. DELETE (no correction) will be indicated for Shift Coast Line 1. At this time, MAP SHIFT will disappear from software button located at the bottom right corner of the radar display described in Section 2.3.4.
  • Page 213 3.9 APPLIED OPERATIONS [3] LAT/LON Correction This method corrects a chart position by changing the values of latitude and longitude that are sent by the navigation equipment. Only our service engineers are to use this correction method because the contents of data such as trails data to be saved are changed when the method is used.
  • Page 214 [4] MAP Center Position This method corrects a chart position by entering the values of latitude and longitude at own ship’s position in manual mode. If latitude and longitude data sent by the navigation equipment has been entered, the data has priority over the manually entered values.

  • Page 215: Set Loran C (Loran C Correction)

    3.9 APPLIED OPERATIONS 3.9.7 Set LORAN C (LORAN C Correction) Note: Plotter option (NDB-44) is necessary to enable LORAN C time difference display. Setting LORAN C Procedure Press [RADAR MENU] key. Press [9] key. Press [5] key. Press [5] key. Press [5] key.

  • Page 216: Use Function Switch [Func]

    3.10 USE FUNCTION SWITCH [FUNC] “Radar Function Setting” is provided for always obtaining the best radar video by storing complex radar signal processing settings in the optimum status by use, and calling the setting in accordance with the conditions for using the function.

  • Page 217: Function Setting Menu Items

    3.10 USE FUNCTION SWITCH 3.10.2 Function Setting Menu Items The function setting menu has the items below. Page 1 1. Mode Name of the mode to be used 2. IR Radar interference rejection OFF/LOW/MEDIUM/HIGH 3. Process Video process OFF/ 4. Target Enhance Target expansion OFF/ LEVEL1/LEVEL2/LEVEL3 5.

  • Page 218: Overview Of Function Operations

    3.10.3 Overview of Function Operations The following outlines the operation of each function selected from the function setting menu: Procedure Press the [FUNC] key for 2 seconds. The User Function Setting menu will appear. Specify the number for the function for which the settings are to be changed. The following are the operation overviews of each function setting item.
  • Page 219 3.10 USE FUNCTION SWITCH [Page 1] [5] Auto SEA/RAIN (Auto STC/FTC) x Detects unwanted waves such as rain/snow clutter and sea clutter and automatically suppresses them. x When the sea state or weather changes, this function automatically performs suppression processing in accordance with the situation.
  • Page 220 [Page 5] [1] Gain Offset x Corrects sensitivity while the function mode is called. x Since the displayed noise level varies depending on the combination of the video process mode and the interference rejection level, sensitivity needs fine adjustment for always obtaining the highest level. x The sensitivity correction function saves the correction value set by the sensitivity control in each function mode, so it can obtain the highest sensitivity without the sensitivity control being operated when the function mode is changed.
  • Page 221 3.10 USE FUNCTION SWITCH [Page 5] [8] Set Mode Default x Sets the initial value of a selected function setting mode. Select this item to change the current function mode to the initial value. [Page 5] [9] Initialize x Sets the function settings to the factory-set values. Select this item to change all the function settings to the factory-set values.

  • Page 222: Overview Of Stored Function Setting Data

    3.10.4 Overview of Stored Function Setting Data The overview of stored function setting data is as follows: x Factory-set data: Stored data that general operation cannot change x Default data: Standard data of each function mode that users can change x Data that can be called: Stored data that can be called by pressing the [FUNC] key Function Setting Function Setting...

  • Page 223: Personal Information (Pin Setting)

    3.10 USE FUNCTION SWITCH 3.10.5 Personal Information (PIN Setting) The operation status of the radar is recorded. If the system is operated by more than one operator, the operators can register operation status as suitable for them and call the status. Operation status for up to five operations can be registered, and a name can be assigned to each status.
  • Page 224 [II] Saving Operation Status (Save PIN Data) Procedure Press [RADAR MENU] key twice. Press [8] key. The Radar Sub Menu will appear. Press [1] key. The PIN Setting Menu will appear. Press [2] key. The Save PIN Data Menu will appear. Select the number corresponding to the place where you want to save status, pressing the numeric keys [1] to...
  • Page 225 3.10 USE FUNCTION SWITCH [III] Erasing Registered Operation Status (Delete PIN Data) Procedure Press [RADAR MENU] key twice. Press [8] key. The Radar Sub Menu will appear. Press [1] key. The PIN Setting Menu will appear. Press [3] key. The Delete PIN Data Menu will appear. Select the file you want to erase, pressing the numeric keys [1] to [5].

  • Page 226: Using Card

    3.11 USING CARD This radar has two card slots. Inserting a flash memory card (option) into a card slot, you can save the following contents, saved in the processor, in the card or can read data from the card to the processor. x Trails of own ship: 7000 points maximum x Track of other ship: 20 target˜1500 points (TT or AIS option) x Mark Line: 20000 points maximum (plotter option)

  • Page 227: Save In And Transfer To Card (Mem Capa/Copy)

    3.11 USING CARD Caution in use. Never eject the CF card while files are being written to the card. Turn the power off before inserting or ejecting a CF card. 3.11.1 Save in and Transfer to Card (MEM CAPA/Copy) Procedure Press [RADAR MENU] key.
  • Page 228 x Information saved in the processor is displayed in the Memory Content. Total: Total number of data points Track: Number of data points for own ship's track (7000 points maximum) Remain: Number of remaining data points of own ship's track that can be saved Mark/Line: Number of mark and line points made with user map (20000 points maximum only when a plotter option is installed) Remain:...
  • Page 229 3.11 USING CARD [I] Copy Internal Information to Card 2 (Copy Internal o Card 2) Procedure Press [1] key while the CAPA/Copy Menu is open. The items to be saved are displayed. Select the item to be saved, using the numeric keypad on the keyboard. A file name to copy Internal information to Card 2 can be entered.
  • Page 230 [II] Read Information from Card 2 to Internal Portion(Copy Card 2 o Internal) Procedure Press [2] key while the CAPA/Copy Menu is open. Using the numeric key, select ADD mode or OVER WRITE mode. A file name to copy information from Internal portion to Card 2 can be entered. Read the file name displayed in the Card 2 window.
  • Page 231 3.11 USING CARD [III] Copy Information from Card 1 to Card 2 (Copy Card 1 o Card 2) Procedure Press [3] key while the CAPA/Copy Menu is open. A file name to copy information from Card 1 to Card 2 can be entered. Using the numeric key, enter a file name.

  • Page 232: Erase/Initialize Card Memory (Clr Mem/Init Card)

    3.11.2 Erase/Initialize Card Memory (CLR MEM/INIT Card) Erase saved information from inside the processor. [I] Erase Mark/Line (CLR Mark/Line Data) Erase saved mark/line from inside the processor. Procedure Press [RADAR MENU] key. The Main Menu will appear. Press [9] key. The Plot Menu will appear.
  • Page 233 3.11 USING CARD [III] Initialize Card 2 (Format Card 2) Initialize Card 2. Procedure Press [RADAR MENU] key. The Main Menu will appear. Press [9] key. The Plot Menu will appear. Press [7] key. The CLR MEM INIT Card Menu will appear. Press [3] key.
  • Page 234 3 155...

  • Page 235: Measurement Of Range And Bearing

    SECTION 4 MEASUREMENT OF RANGE AND BEARING MEASUREMENT USING THE CURSOR WITH THE TRACKBALL . 4-1 MEASUREMENT BY RANGE RINGS ..........4-2 MEASUREMENT BY EBLS AND VRMS..........4-3 MEASUREMENT BETWEEN TWO OPTIONAL POINTS....4-4...

  • Page 236: Measurement Using The Cursor With The Trackball

    MEASUREMENT USING THE CURSOR WITH THE TRACKBALL Procedure Check the target echoes on the radar display. Move the cursor mark to a target by the trackball. The CURSOR on the radar display indicates the bearing and range of the target. The range is a distance from own ship’s position.

  • Page 237: Measurement By Range Rings

    4.2 MEASUREMENT BY RANGE RINGS MEASUREMENT BY RANGE RINGS Procedure Press [RR/HL] key. Display and non-display of the scale of the range rings is switched every time the [RR/HL] key is pressed. Also, the scale unit is shown on the Range rings display On / Off button (Software button located at the top left corner of the radar display described in Section 2.3.1).

  • Page 238: Measurement By Ebls And Vrms

    MEASUREMENT BY EBLS AND VRMS Procedure Press [EBL1] key to select EBL1 display and operation. EBL1 indication at the upper right of the radar display will be selected and the EBL1 will appear as a broken-line on the PPI display. Turn the [EBL] control to put EBL1 on a target.

  • Page 239: Measurement Between Two Optional Points

    4.4 MEASUREMENT BETWEEN TWO OPTIONAL POINTS MEASUREMENT BETWEEN TWO OPTIONAL POINTS Procedure Press [EBL2] key to select EBL2 display and operation. EBL2 indication at the upper right of the radar display will be selected and the EBL2 will appear as a dotted-line on the PPI display. Place the cursor over the button of EBL2 at the top right corner of the radar screen, and...
  • Page 240 Figure 4.3 It is also possible to use EBL1 instead of EBL2 in measuring the bearing and range between two optional points. In this case, read EBL2 as EBL1 and VRM2 as VRM1 in the procedure above, point the cursor to C of EBL2 in step 2, and then press [ENT] key.

  • Page 241: Operation Of Tt And Ais

    SECTION 5 OPERATION OF TT AND AIS PREPARATION ............5-2 5.3.5 Deactivating AIS Targets (Deactivate AIS)..5-42 5.1.1 Collision Avoidance ..........5-3 5.3.6 Displaying Numeric Data of AIS Targets 5.1.2 Definitions of Symbols ........5-6 (TGT DATA) ............5-43 5.1.3 TT Data Display............5-11 5.3.7 Displaying Target ID No.

  • Page 242: Usage Of Target Tracking Function

    USAGE OF TARGET TRACKING FUNCTION Attention z There are the following limitations on use of the target acquisition and target tracking functions. Resolution between adjacent targets and swapping during automatic target tracking Depending on the particular distance and echo size, resolution between adjacent targets during automatic target tracking usually ranges somewhere between 0.03 to 0.05 NM.

  • Page 243: Preparation

    5.1 PREPARATION PREPARATION This section explains the features of the target tracking and AIS functions, and the initial setting for using each function. Before the target tracking function or AIS function can be used, the corresponding optional device must be installed.

  • Page 244: Collision Avoidance

    5.1.1 Collision Avoidance Problems of Collision Avoidance in Navigation Marine collision avoidance is one of the problems that have been recognized from of old. Now, it will be described briefly who the collision avoidance is positioned among the navigational aid problems. The navigation pattern of all mobile craft constitutes a system with some closed loops regardless of the media through which the mobile craft travels, whether air, water, the boundary between air and water, or space.

  • Page 245: Basic Concept Of Collision Avoidance

    5.1 PREPARATION Basic Concept of Collision Avoidance There are two aspects in collision avoidance: collision prediction and avoidance. Collision prediction is to predict that two or more vessels will happen to occupy the same point at the same time, while collision avoidance is to maneuver vessels not to occupy the same point at the same time.

  • Page 246: Relative Vector And True Vector

    Relative Vector and True Vector From two points of view, collision prediction and avoidance, it is necessary to obtain the relative vector of other ship for prediction and the true vector of other ship for collision avoidance in order to grasp other ship’s aspect. The relationship between the relative vector and true vector is shown in Fig.

  • Page 247: Definitions Of Symbols

    5.1 PREPARATION 5.1.2 Definitions of Symbols Types and Definitions of Target Tracking Symbols Vector/Symbol Definition Remarks This symbol is displayed until the vector is displayed after Initial acquisition target target acquisition. The alarm sounds. Target acquired in The alarm message (New Target) turns red and blinks. automatic acquisition zone The symbol is red colored.
  • Page 248 Types and Definitions of AIS Target Symbols Vector/Symbol Definition Remarks This symbol is displayed when received data is valid. Sleeping target The direction of the triangle’s vertex indicates the target’s bow or course. The heading direction is displayed with a solid line, and the course vector is displayed with a dotted line.
  • Page 249 5.1 PREPARATION The vector of an AIS target is to be displayed with a vector over ground or over water, depending on the speed sensor setting and current offset setting. The type of the currently displayed vector can be confirmed by viewing the setting of the stable mode.
  • Page 250 TT symbol display setting (TT Symbol Display) Turn on or off (ON / OFF) the TT symbol display. This function can be used only when the AIS display function (optional) is on. This function cannot be used when the AIS display function (The TT display function cannot be deactivated if only TT is used without using the AIS function).
  • Page 251 5.1 PREPARATION Setting AIS Symbol Display Function (AIS Symbol Display) Switch ON or OFF to set the AIS symbol display function. Procedure Press [TT MENU] key. Press [2] key. The AIS Setting menu will appear. Press [2] key. The AIS Symbol Display is switched between ON and OFF.

  • Page 252: Tt Data Display

    5.1.3 TT Data Display (Refer to Example of Display in Section 2.1 “EXAMPLE OF DISPLAY.”) Display of Vectors Attention z When a target or own ship changes a course, or when a target is acquired, its vector may not reach a given level of accuracy until three minutes or more has passed after such course change or target acquisition.
  • Page 253 5.1 PREPARATION Relative Vector Mode In displaying the relative vector of a target, press the [VECT R/T] key to select the Relative Vector mode. The relative vector does not represent the true motion of the target, but its relative relation with own ship. This means that a target with its relative vector directed to own ship (passing through the CPA LIMIT ring) will be a dangerous target.

  • Page 254: Cursor Modes (Cursor)

    5.1.4 Cursor Modes (Cursor) Types and Functions of Cursor Modes The types of cursor modes are listed in the table below. To use the function of a cursor mode, move the cursor onto the PPI object and press the [ENT] key. Mode Function ACQ TT...

  • Page 255: Setting Collision Decision Criteria (Cpa/Tcpa Limit)

    5.1 PREPARATION 5.1.5 Setting Collision Decision Criteria (CPA/TCPA Limit) For details on each operation, see 3.4 BASIC OPERATION and 4 MEASUREMENT OF RANGE AND BEARING. Attention z Set the optimum values of collision decision conditions, depending upon vessel type, water area, weather and oceanographic conditions.

  • Page 256: Setting Cpa Ring (Cpa Ring)

    5.1.6 Setting CPA Ring (CPA Ring) Procedure Press [TT MENU] key. Press [3]. The TT Setting menu will appear. Press [7]. The setting of CPA Ring will change between ON and OFF. ON: Displays the CPA ring. OFF: Hides the CPA ring. While the CPA ring is displayed, CPA RING is shown at the lower right of the radar display.

  • Page 257: Setting Vectors (Vector Time)

    5.1 PREPARATION 5.1.7 Setting Vectors (Vector Time) Vector time can be set in minutes in the range 1 to 60 min. A true vector mode or relative vector mode can be selected. Setting vector time on the display Procedure Move the cursor to the target vector time setting (Software button located at the other ship's information area in Section 2.3.6), and press the [ENT] key.

  • Page 258: Setting The Gps Antenna Location

    5.1.8 Setting the GPS antenna location Set the GPS antenna location. Set offset ranges in longitudinal direction and latitudinal direction from the own ship's reference position. For the setting procedure, refer to Section 7.1.6 “Setting of CCRP/Antenna/GPS Antenna Position (CCRP Setting).”...

  • Page 259: Tt Operation

    5.2 TT OPERATION TT OPERATION This section explains how to use the target tracking (TT) functions. Each function is available only when the target tracking (TT) option is installed. The functions automatically track a target, and store/display vectors as the course and speed. They calculate CPA and TCPA, and issue an alarm.

  • Page 260: Acquiring Target [Acq]

    5.2.1 Acquiring Target [ACQ] Target acquisition can be performed on two modes, AUTO and MANUAL, and both modes can be used at the same time. Automatic Acquisition [AUTO] Attention z If untracked targets intrude into automatic acquisition/activate zone in the conditions that maximum number of targets is under tracking, the targets acquired automatically will be cancelled in the order of lower levels of danger.
  • Page 261 5.2 TT OPERATION Setting Automatic Acquisition Key Assignment (Set AZ Key) This section explains how to set automatic acquisition/activate zone that is to be assigned to the [AZ] key. The setting enables the operator to select ON/OFF for a generally used automatic acquisition/activate zone by simply operating the [AZ] key on the control panel.
  • Page 262 Manual Acquisition [MANUAL] Attention z If more targets are acquired manually in the condition that the maximum number of targets are under tracking, the targets under tracking will be cancelled in the order of lower level of danger in order to track the manually acquired targets. Procedure Move the cross cursor mark onto the target to be acquired, and press the [ACQ] key.

  • Page 263: Canceling Unwanted Targets

    5.2 TT OPERATION 5.2.2 Canceling Unwanted Targets Unwanted targets can be canceled one by one in the following cases: x Tracking is no longer necessary for targets with which vectors/symbols are displayed after being acquired and tracked. x The number of vectors on the radar display needs to be reduced for easy observation. When targets are to be re-acquired from the beginning, all the current vectors can also be canceled.

  • Page 264: Tracking Target Data Display [Tgt Data]

    5.2.3 Tracking Target Data Display [TGT DATA] Attention z When a target or own ship changes its course, or when a new target is acquired, its vector may not reach a given level of accuracy until three minutes or more has passed after such course change or target acquisition.
  • Page 265 5.2 TT OPERATION [I] Method of Displaying Target Data [TGT DATA] Procedure Move the cross cursor mark onto the target for which numeric data is to be displayed, and press the [TGT DATA] key. Or, set the cursor mode to TGT Data, place the cross cursor over the target whose numerical data is to be displayed, and press the [ENT] key.

  • Page 266: Displaying Target Id No. (Target Number Display)

    5.2.4 Displaying Target ID No. (Target Number Display) A target ID number is a value displayed beside the acquisition symbol when a target is acquired. These numbers are assigned to targets in acquisition order. The numbers 1 to 30 are automatically assigned. Each target is identified by the assigned ID number until it is lost or its acquisition is canceled.

  • Page 267: Input Of Target Information (Tt Individual Setting)

    5.2 TT OPERATION 5.2.5 Input of target information (TT Individual Setting) This radar enables name inputs and target track color changes for individual TT targets acquired. Procedure Turn OFF the cursor mode. Software button located at the top right corner of the radar display described in Section 2.3.3 is available to change the cursor mode.
  • Page 268 Name entry (Name) Procedure While the TT Target INFO screen is open, press [1] key. For the entry of a new name o 2. INPUT For the selection of a name from names that have already been entered o 1. DATA BASE. For new entry Selecting INPUT displays the screen shown below.
  • Page 269 5.2 TT OPERATION Track Color Setting (Track Color) Procedure While the TT Target INFO screen is open, press [2] key. Pressing numeric key(s), select a color number you want to set. Colors selectable with Track Color are colors that have been set within the TT Track Setting. When colors are set, individual colors can be set for the 1th to 20th.

  • Page 270: Reference Target (Reference)

    5.2.6 Reference Target (Reference) This equipment can calculate and display the speed of own ship by tracking a target whose position is fixed with respect to the ground and by setting this target as a reference target. Attention z The reference target function is to be used if the own ship's speed cannot be displayed normally due to trouble such as a speed sensor malfunction.
  • Page 271 5.2 TT OPERATION Procedure Acquire a target whose position if fixed with respect to the ground. Set the cursor mode to OFF. Place the cursor over the tracked target and press the [CLR/INFO] key. Target information menu is displayed. Press the [4] key. ON : Set this target as a reference target.

  • Page 272: Tt Test Menu

    5.2.7 TT Test Menu CAUTION Target Tracking Function Test is provided to test if the target tracking function is operating normally. Thus, do not use the function except when you test the target tracking function. In particular, if this mode is used during navigation, pseudo targets appear on the radar display, which may be confused with the actual targets.
  • Page 273 5.2 TT OPERATION [I] Test Video Attention z TEST VIDEO may not appear for targets that are not acquired nor tracked, or if the [GAIN] and [SEA] controls are adjusted properly Test Video is used to check whether the video signals under target acquisition and tracking are inputted to and processed in the target processing circuit normally.
  • Page 274 [II] Target Tracking Simulator Pseudo targets can be generated in certain known positions to check whether the TT processing circuits are operating normally. Since the pseudo targets move depending on known parameters, the values for these pseudo targets can be compared with the known value if the pseudo targets are acquired and tracked, and displayed.
  • Page 275 5.2 TT OPERATION Exit Press the [STBY] key. The equipment will enter the standby state. Press [2] key while the TT Test Menu is open. Choices for the TT simulator (TT Simulator) are displayed. Press [1] key to select OFF. The TT Simulator is turned off.
  • Page 276 [III] Status The current TT status will appear. Procedure Press [TT MENU] key. The TT Menu will appear Press [6] key. The TT Test Menu will appear. Press [3] key. The Status screen will appear.. *Constant: Vector response *Video Level TD: Threshold value used for tracking *Video Level HI:...
  • Page 277 5.2 TT OPERATION [IV] Gate Display The gate displays an area monitoring a target using the TT function. This radar equipment allows the gate size to change automatically according to target distance and size. User can check the gate size using the following function.

  • Page 278: Ais Operation

    AIS OPERATION 5.3.1 Restrictions Attention There are the following limitations on use of the AIS function, system, and operation: This system can display up to a total of 130 targets. Of which, up to 30 activated targets can be displayed. There are 3 types of filters for controlling sleeping target display.

  • Page 279: Initial Setting

    5.3 AIS OPERATION 5.3.2 Initial Setting This section explains the initial setting for using the AIS function. Setting the GPS antenna location Set the GPS antenna location. Set offset ranges in longitudinal direction and latitudinal direction from the own ship's reference position. For the setting procedure, refer to Section 7.1.6 “Setting of CCRP/Antenna/GPS Antenna Position (CCRP Setting).”...
  • Page 280 Procedure Press [TT MENU] key. Press [3] key. The Target Setting Menu will appear. Press [5] key. The ten-key screen will appear. Using numeric keys, enter the CPA value you want to set, and then press [ENT] key. The entered CPA Limit value is determined. Press [6] key.

  • Page 281: Setting Ais Display Function (Ais Function)

    5.3 AIS OPERATION 5.3.3 Setting AIS Display Function (AIS Function) Switch the AIS symbol display function to ON/OFF. Attention z When the AIS display function is set to OFF, no AIS symbols are displayed. z The AIS display function itself is turned OFF. z Once the AIS display function is set to OFF, it is not automatically switched to ON even if a dangerous target exists.

  • Page 282: Activating Ais Targets (Activate Ais)

    5.3.4 Activating AIS Targets (Activate AIS) Activate an AIS target, and display the target’s vector and make a collision decision. Manual activation Activate an AIS target in manual mode to display the vector and HL. Procedure Press the CURSOR button at the upper right of the radar display several times until ACT AIS appears.

  • Page 283: Deactivating Ais Targets (Deactivate Ais)

    5.3 AIS OPERATION 5.3.5 Deactivating AIS Targets (Deactivate AIS) Deactivate an AIS target and clear the display of the vector and HL. Attention z The operation above is effective only for active targets. Procedure Press the CURSOR button at the upper right of the radar display several times until CANCEL appears.

  • Page 284: Displaying Numeric Data Of Ais Targets (Tgt Data)

    5.3.6 Displaying Numeric Data of AIS Targets (TGT DATA) Numerical data for a specified AIS target is displayed. Types of numeric data displayed Display items y Navigation information BRG (true bearing) 0.01q unit RANGE 0.01nm unit COG (course over ground) 0.1q unit SOG (speed over ground) 0.1knot unit...
  • Page 285 5.3 AIS OPERATION Displaying numeric data Procedure Press the CURSOR button at the upper right of the radar display several times until TGT DATA appears. The cursor mode is set to the numeric data display mode. Move the cross cursor mark onto the active AIS target for which numeric data is to be displayed, and press [ENT] key.
  • Page 286 AIS information panel display setting A set of AIS information to be preferentially displayed (before other sets of information) on the AIS information panel can be specified. Information type can be selected from the choices of: navigation information, ship information, and destination and location information.
  • Page 287 5.3 AIS OPERATION Lost target data display Information of the last lost AIS target can be displayed. Data can be displayed for the target that was lost most recently. Procedure Press the [TT menu] key. Press the following buttons. 2. AIS setting 4.
  • Page 288 AIS own ship information display AIS information for own ship can be displayed. Procedure Press the [TT menu] key. Press the following buttons. 2. AIS setting 5. AIS own ship information display AIS information for own ship is displayed. 5 47...

  • Page 289: Displaying Target Id No. (Target Number Display)

    5.3 AIS OPERATION 5.3.7 Displaying Target ID No. (Target Number Display) A target ID number is a value displayed beside the AIS symbol. ID numbers are assigned to AIS symbols in displayed order. ID numbers 1 to 130 are automatically assigned. Each target is identified by the assigned ID number until it is lost.

  • Page 290: Setting Ais Filter (Ais Filter Setting)

    5.3.8 Setting AIS Filter (AIS Filter Setting) About an AIS filter Once the AIS filter is set, only the AIS targets that are inside the filter area are displayed (setting can be made such that sleeping targets outside the AIS filter will not be shown). The filter is initially set in a circle having a radius of 20 [nm] from the own ship’s position.
  • Page 291 5.3 AIS OPERATION Making an AIS filter (Make AIS Filter) Procedure Press [2] key while the AIS Filter Setting menu is open. The Make AIS Filter screen will appear. [I] Setting a RANGE filter Turn the [VRM] key control to set a filter range, and press [ENT] key.
  • Page 292 Setting the AIS filter display function to ON/OFF (Filter Display) Procedure Press [3] key while the AIS Filter Setting menu is open. The setting of AIS Filter display will be switched ON or OFF. Displays the AIS filter. OFF: Hides the AIS filter. Display of Targets outside AIS Filter (Filter Mode) Procedure Press [TT MENU] key.
  • Page 293 5.3 AIS OPERATION Point Filter AIS targets which are not displayed because they are outside the AIS filter or at low priority levels can be activated by giving a higher priority to them. Procedure Press a few times the CURSOR button at the top right corner of the screen to call up ACT AIS .

  • Page 294: Conditions For Deciding Ais Target To Be Lost

    5.3.9 Conditions for Deciding AIS Target to be Lost About a lost target When the data of an AIS target cannot be received for a specified time, the target is decided to be lost and the target data is deleted. As shown in the table below, the time until target data is deleted varies depending on the class of receive data and the target status.

  • Page 295: Setting Ais Alarm (Ais Alarm Setting)

    5.3 AIS OPERATION 5.3.10 Setting AIS Alarm (AIS Alarm Setting) Conditions for setting off a lost AIS target alarm (Lost) and a dangerous target alarm (CPA/TCPA) can be set. Lost target alarm (Lost) Procedure Press the [TT menu] key. Press [2] key. Press [8] key.

  • Page 296: Target Association Assessment (Association Setting)

    TARGET ASSOCIATION ASSESSMENT (ASSOCIATION SETTING) Caution When a large value is set as an association condition, a tracked target near an AIS target is identified as the AIS target and may thus disappear from the display. For example, when a pilot vessel equipped with the AIS function (a small target which is not a tracked target) goes near a cargo vessel which is a tracked target without the AIS function, the...

  • Page 297: Priority

    5.4 TARGET ASSOCIATION ASSESSMENT (ASSOCIATION SETTING) Procedure Press the [TT menu] key. Press the following buttons. 3 Target setting 1 Association assessment setting 1 Association assessment On : Use the association assessment function. (Targets that are judged to be identical will be indicated as an association symbol.) Off : Do not use the association assessment function.

  • Page 298: Distance

    5.4.4 Distance Set a distance between targets to be identified as one target. Targets that are within the set distance will be identified as one target. Procedure Press the [TT menu] key. Press the following buttons. 3 Target setting 1 Association assessment setting 4 Distance Set a distance between a tracked target and an AIS target to be identified as one target.

  • Page 299: Speed

    5.4 TARGET ASSOCIATION ASSESSMENT (ASSOCIATION SETTING) 5.4.6 Speed Set a speed difference between targets to be identified as one target. Targets that are within the set speed range will be identified as one target. Procedure Press the [TT menu] key. Press the following buttons.

  • Page 300: Hysteresis

    5.4.7 Hysteresis Set a hysteresis level at which a tracked target and an AIS target are identified as one target by the association assessment function. Set the condition for using an association symbol when a tracked target symbol and an AIS target symbol overlap each other.

  • Page 301: Non-Hysteresis

    5.4 TARGET ASSOCIATION ASSESSMENT (ASSOCIATION SETTING) 5.4.8 Non-Hysteresis Set a non-hysteresis level at which targets that were once identified as one target by the association assessment function are identified as separate targets. Set the condition for separating an association symbol into a tracked target symbol and an AIS target symbol. Procedure Press the [TT menu] key.

  • Page 302: Ais Target To Be Assessed

    5.4.9 AIS Target to be Assessed Specify an AIS target to be assessed for association. Targets of association assessment can be either activated targets only or both activated and sleeping targets. Procedure Press the [TT menu] key. Press the following buttons. 3 Target setting 1 Association assessment setting 9 AIS target to be assessed...

  • Page 303: Alarm Display

    5.5 ALARM DISPLAY ALARM DISPLAY Alarm messages for Target Tracking (TT) and AIS functions: Error message Description TT CPA/TCPA A dangerous target is detected in target tracking. AIS CPA/TCPA A dangerous AIS target is detected. TT(New Target) A new target being tracked was acquired in the automatic acquisition area. AIS(New Target) A new AIS target was activated in the automatic acquisition area.
  • Page 304 AIS Alarm 006 general failure AIS Alarm 008 MKD connection lost AIS Alarm 025 external EPFS lost AIS Alarm 026 no sensor position in use AIS Alarm 029 no valid SOG information AIS Alarm 030 no valid COG information AIS Alarm 032 Heading lost/invalid AIS Alarm 035 no valid ROT information...
  • Page 305 5.5 ALARM DISPLAY CPA / TCPA Alarm Caution Since these alarms may include some errors depending on the target tracking conditions, the navigation officer himself should make the final decision for ship operations such as collision avoidance. Making the final navigation decision based only on the alarm may cause accidents such as collisions.
  • Page 306 Alarm for New Target Acquired in Automatic Acquisition Zone (New Target) Caution In setting an automatic acquisition zone, it is necessary to adjust the gain, sea clutter suppression and rain / snow clutter suppression to ensure that target echoes are displayed in the optimum conditions.
  • Page 307 5.5 ALARM DISPLAY Lost Target Alarm Attention z If the gain, sea clutter suppression, rain/snow clutter suppression are not adjusted adequately, the lost target alarm may be easily generated. So such adjustments should be mad carefully. When it is impossible to continue tracking any acquired and tracked target, or the data of AIS target cannot received for a specified time, the LOST alarm will be generated.

  • Page 308: Gyro Set Alarm

    System Function Alarm (TT Data) When an abnormal state of an input signal or Target Tracking unit may have a trouble, alarm is generated. When an alarm occurs against any Target Tracking function, TT (Data) will appear in the alarm indication (Software button located at the operation/message area in Section 2.3.9), but no indication is made in the Tracked Target information display (panel display area in Section 2.3.8).

  • Page 309: Track Display

    5.6 TRACK DISPLAY TRACK DISPLAY 5.6.1 Display Past Tracks (Past Position) With the past position function (Past Position), up to 6 past tracked and AIS target positions can be displayed (5 set time and distance intervals). Select one of the time intervals at which past time positions should be displayed: 0.5 minutes, 1 minute, 2 minutes, and 4 minutes.

  • Page 310: Other Ship's Tracks (Target Track Setting)

    5.6.2 Other Ship's Tracks (Target Track Setting) Make track settings for acquired tracked and AIS targets. This equipment can display tracks of up to 20 other vessels. The target track function is available between latitudes of 85°N and 85°S. * Tracks of other ships will not be recorded with the Target Track Function is deactivated. [I] Track color setting (Target Track Color) Procedure Turn OFF the cursor mode.
  • Page 311 5.6 TRACK DISPLAY [III] Other ship's track color setting (Target Track Color) The track color can be the same for all tracked targets, or different colors can be assigned to the first 20 targets. * Tracks of other ships will not be recorded with the Target Track Function is deactivated. Procedure Press the [TT menu] key.
  • Page 312 [IV] Other ship's track display setting (Target Track Display) Other ship's track display can be turned on/off. Also, track display mode can be chosen between display/non-display of all tracks and individual tracks. Procedure Press the [TT menu] key. Press the following buttons. 4 Target Track Setting 3 Target Track Display Press the [1] key.
  • Page 313 5.6 TRACK DISPLAY [V] Other ship track recording interval setting (Track Memory Interval) A time interval for recording tracks of other ships can be set. * This function can be used only when the Target Track Setting function is enabled. Procedure Press the [TT menu] key.
  • Page 314 [VI] Deletion of other ship's tracks (Clear Track) Tracks of other ships can be deleted. They can be deleted by track color or by track number. * When using the card-based track display function (Card T. TRK Display), tracks of other ships that are loaded from the card cannot be deleted.
  • Page 315 5.6 TRACK DISPLAY [VII] Loading target tracks from CARD2 (Card2 Track Display) Target tracks saved in CARD2 can be loaded. Procedure Insert a Flash memory card into the card slot. Refer to the attached instruction manual for how to insert/remove the card. Press the [TT menu] key.
  • Page 316 5 75...

  • Page 317: True And False Echoes On Display

    SECTION 6 TRUE AND FALSE ECHOES ON DISPLAY RADAR WAVE WITH THE HORIZON......... 6-2 STRENGTH OF REFLECTION FROM THE TARGET..6-4 SEA CLUTTER AND RAIN AND SNOW CLUTTER... 6-6 FALSE ECHOES ............... 6-10 DISPLAY OF RADAR TRANSPONDER (SART)....6-13...
  • Page 318 The radar operator has a role of interpreting the radar displays to provide his best aid in maneuvering the ship. For this purpose, the operator has to observe the radar displays after fully understanding the advantages and disadvantages that the radar has. For better interpretation of radar display, it is important to gain more experiences by operating the radar equipment in fair weathers and comparing the target ships watched with the naked eyes and their echoes on the radar display.

  • Page 319: Radar Wave With The Horizon

    6.1 RADAR WAVE WITH THE HORIZON RADAR WAVE WITH THE HORIZON Radar beam radiation has the nature of propagating nearly along the curved surface of the earth. The propagation varies with the property of the air layer through which the radar beam propagates. In the normal propagation, the distance (D) of the radar wave to the horizon is approximately 10% longer than the distance to the optical horizon.
  • Page 320 D (nm) Height of Target Height of Radar Scanner Detective Range Figure 6.1 When the height of own ship’s scanner is 10 m for instance, A target that can be detected at the radar range of 64 nm on the radar display is required to have a height of 660 m or more.

  • Page 321: Strength Of Reflection From The Target

    6.2 STRENGTH OF REFLECTION FROM THE TARGET STRENGTH OF REFLECTION FROM THE TARGET The signal intensity reflected from a target depends not only on the height and size of the target but also on its material and shape. The echo intensity from a higher and larger target is not always higher in general. In particular, the echo from a coast line is affected by the geographic conditions of the coast.
  • Page 322 Table 6.1 Relation between type and height of target and detection distance and RCS Height from Detection distance (NM) RCS (m²) Type of target sea surface X band S band X band S band Sea shore line 50,000 50,000 Sea shore line 5000 5000 Sea shore line...

  • Page 323: Sea Clutter And Rain And Snow Clutter

    6.3 SEA CLUTTER AND RAIN AND SNOW CLUTTER SEA CLUTTER AND RAIN AND SNOW CLUTTER In addition to the echo required for observing ships and land radar video image also includes unnecessary echo, such as reflection from waves on the sea surface and reflection from rain and snow. Reflection from the sea surface is called "sea clutter,"...
  • Page 324 As shown in Table 6.3, the number of SS increases as the wind speed becomes high and the waves become large. Table 6.2 reveals that detection probability decreases from V (80 %) to NV (less than 50 %) as the number of SS increases.
  • Page 325 6.3 SEA CLUTTER AND RAIN AND SNOW CLUTTER Precipitation of 16 mm/hr Pulse width 0.05 Ps Precipitation of 4 mm/hr Pulse width 0.05 Ps Precipitation of 16 mm/hr Pulse width 0.8 Ps Precipitation of 4 mm/hr Pulse width 0.8 Ps Detection distance while it is not raining (NM) Figure 6.3 Decreased target detection distance by S band radar due to precipitation Precipitation of 16 mm/hr Pulse width 0.05 Ps...
  • Page 326 [III] Coping with sea clutter and rain and snow clutter When the weather is bad and the ocean is rough, the use of an S band radar is effective because the radar is not influenced by sea clutter so much and attenuation due to rain drops is small. When an X band radar is used, reducing the pulse width will reduce the influence by spurious waves, and also the spurious wave rejection function effectively works;...

  • Page 327: False Echoes

    6.4 FALSE ECHOES FALSE ECHOES The radar observer may be embarrassed with some echoes that do not exist actually. These false echoes appear by the following causes that are well known: [I] Shadow When the radar scanner is installed near a funnel or mast, the echo of a target that exists in the direction of the funnel or mast cannot appear on the radar display because the radar beam is reflected on the funnel or mast.
  • Page 328 [IV] False Echo by Multiple Reflection When there is a large structure or ship with a high vertical surface near own ship as shown in Figure 6.7, multiple refection returns may appear on the radar display. These echoes appear in the same intervals, of which the nearest echo is the true echo of the target.
  • Page 329 6.4 FALSE ECHOES [VI] Radar Interference When another radar equipment using the same frequency band as that on own ship is near own ship, a radar interference pattern may appear on the radar display. This interference pattern consists of a number of spots which appear in various forms.

  • Page 330: Display Of Radar Transponder (Sart)

    DISPLAY OF RADAR TRANSPONDER (SART) The SART (Search and rescue Radar Transponder) is a survival device authorized by the GMDSS (Global Maritime Distress and Safety System), which is used for locating survivors in case that a distress accident occurs at sea. The SART is designed to operate in the 9 GHz frequency band. When receiving the 9 GHz radar signal (interrogating signal) transmitted from the radar equipment on a rescue ship or search aircraft, the SART transmit a series of response signals to inform the distress position to the rescue and search party.
  • Page 331 6.5 DISPLAY OF RADAR TRANSPONDER With the SART display mode set to ON, settings as shown below are made automatically. Sea clutter control: Minimum (Most counterclockwise) AUTO SEA function: Rain and Snow Clutter Control (RAIN): minimum Auto Rain and Snow Clutter function (AUTO RAIN): TUNE control: No tuning (to weaken clutter echoes) Interference rejector (IR):...
  • Page 332 6 15...

  • Page 333: Settings For System Operation

    SECTION 7 SETTINGS FOR SYSTEM OPERATION SETTINGS AT INSTALLATION........7-1 7.3.2 Sector Blank Setting (Sector Blank) ....7-31 7.1.1 How to open the Adjust Menu ......7-2 7.3.3 TNI Blank Setting (TNI Blank) ......7-33 7.1.2 Tuning Adjustment ..........7-3 7.3.4 Bearing Pulse Output Adjustment 7.1.3 Bearing Adjustment ..........

  • Page 334: Settings At Installation

    SETTINGS AT INSTALLATION This section describes the electrical adjustment procedures to be performed by service engineers during system installation. The bearing adjustment value is saved to non-volatile memory in the scanner. Other settings are saviedto non-volatile memory in the radar process unit. CAUTION Do not carry out the adjustments of the equipment except authorized service persons.

  • Page 335: How To Open The Adjust Menu

    7.1 SETTINGS AT INSTALLATION yyyy 7.1.1 How to open the Adjust Menu Procedure Continue to press [RADAR MENU] key. The Code Input Menu will appear. Input the code. Move the cursor onto the “ENT” button in the Code Input menu, and press [ENT] key.

  • Page 336: Tuning Adjustment

    7.1.2 Tuning Adjustment Adjust the tuning control for the transmitter and receiver. The turning control should be adjusted when the system is installed or when the magnetron is replaced. Procedure Set a range of 24 NM or more. Hold down [RADAR MENU] key. The CODE Input screen opens.
  • Page 337 7.1 SETTINGS AT INSTALLATION yyyy [I] Tune Indicator Adjustment Set the scale mark when the tune indicator bar reaches the maximum point. Procedure Set the range to 24 NM or more. Hold down [RADAR MENU] key. The CODE Input screen opens. Press [0] key.
  • Page 338 x With the JMA-5212 radar: For this model, perform Tune Peak Adjustment and Tune Indicator Adjustment explained below. After the above adjustment procedure, perform the adjustment procedure below. [II] Tune Peak Adjustment Adjust the tune indicator and echo peak. Procedure Set the range to 24 NM or more.

  • Page 339: Bearing Adjustment

    7.1 SETTINGS AT INSTALLATION yyyy 7.1.3 Bearing Adjustment Adjust the bearing so that bearing of the target measured with the ship’s compass matches that of the target echo on the radar display. Procedure Press AZI MODE to select the relative bearing presentation [H UP] mode.

  • Page 340: Range Adjustment

    7.1.4 Range Adjustment Adjust the range so that the range of the target on the radar video is indicated correctly. Procedure Search the radar display for a target of which range is already known. Hold down [RADAR MENU] key. The Code Input Menu will appear. Press [0] key.

  • Page 341: Antenna Height Setting (Antenna Hight)

    7.1 SETTINGS AT INSTALLATION yyyy 7.1.5 Antenna Height Setting (Antenna Hight) Set the antenna height above the sea level, but change this setting carelessly. Procedure Measure the height from the sea level to the antenna in advance. Hold down [RADAR MENU] key. The Code Input Menu will appear.

  • Page 342: Setting Of Ccrp/Antenna/Gps Antenna Position (Ccrp Setting)

    7.1.6 Setting of CCRP/Antenna/GPS Antenna Position (CCRP Setting) Set the own ship's CCRP location, radar antenna installation location, and GPS installation location. GPS : Up to 4 locations can be inputted (select one through the receiving port setting when using the GPS).
  • Page 343 7.1 SETTINGS AT INSTALLATION yyyy GPS position : If you wish to connect multiple GPS systems to a COM port and select a GPS position to be used, select it through the receiving port setting of the GPS you wish to use. Reference: Section 7.3.1.2 “Reception Port Setting (RX Port)”...

  • Page 344: Navigator Setting

    NAVIGATOR SETTING This section describes the electrical adjustment procedures to be performed by service engineers during system installation. CAUTION Do not carry out the adjustments of the equipment except authorized service persons. If wrong setting is carried out, this may cause unstable operation. Do not carry out the adjustments during navigation.
  • Page 345 7.2 NAVIGATOR SETTING yyyy [II] Inputting digital true bearing signals from a gyro system (IEC61162, NMEA0183) By following the procedure described in the INSTALLATION MANUAL, connect the gyro system to this equipment. Then, follow the steps below to make settings. In Section 7.2.1 “Ship Heading Equipment Setting (Heading Equipment),”...
  • Page 346 [V] Inputting analog speed signals from a log system through synchronization and steps By following the procedure described in the INSTALLATION MANUAL, connect the optional NSK unit (NCT-4106A) to this equipment. Then, follow the steps below to make settings. In Section 7.2.5 “Ship Speed Equipment Setting (Speed Equipment),” select 2: LOG. Refer to an applicable page for details.

  • Page 347: Ship Heading Equipment Setting (Heading Equipment)

    7.2 NAVIGATOR SETTING yyyy 7.2.1 Ship Heading Equipment Setting (Heading Equipment) Procedure Press [RADAR MENU] key. Main Menu opens. Press [7] key. NAV Equipment Setting menu opens. Press [2] key. Heading Equipment settings are displayed. From the pull-down menu, select heading equipment.

  • Page 348: Nsk Unit Setting

    7.2.2 NSK Unit Setting The NSK Unit circuit of the system is designed to be compatible with most types of gyro compasses by simply setting the switches. Step motor type: 20 to 170 VDC Synchro-motor type: Primary excitation voltage 35 to 120 VAC Before power-on operation can be performed, the switches S1 to S5 on the NSK Unit circuit (PC4201) must be set in accordance with the type of your gyro compass by performing the procedure below.
  • Page 349 7.2 NAVIGATOR SETTING yyyy Table 7-1 Setting Table (S4 DIP Switch) Table 7-2 Setting Table (S5 DIP Switch) DIRECTION SYNC TYPE PULSE PULSE 7 16...

  • Page 350: True Bearing Value Setting (Set Gyro)

    7.2.3 True Bearing Value Setting (Set GYRO) Adjust the bearing that the bearing angle of the radar is the same as that of the gyro. When the NSK unit is used to input gyro signals, in rare cases, the true bearing value indicated by the master gyro and the true bearing value indicated by this equipment do not agree with each other.

  • Page 351: Mag Compass Setting

    7.2 NAVIGATOR SETTING yyyy 7.2.4 MAG Compass Setting Set the MAG compass. Procedure Press [RADAR MENU] key twice. The Main Menu will appear. Press [7] key. NAV Equipment Setting Menu will appear. Press [5] key. MAG Compass Setting Menu will appear. Press [1] key.

  • Page 352: Ship Speed Equipment Setting (Speed Equipment)

    7.2.5 Ship Speed Equipment Setting (Speed Equipment) Procedure Press [RADAR MENU] key twice. The Main Menu will appear. Press [7] key. The NAV Equipment Setting Menu will appear. Press [3] key. Select a ship speed sensor from the pull-down menu. Types of selectable speed sensors: 1: Manual 2: Log...

  • Page 353: Manual Speed Setting (Manual Speed)

    7.2 NAVIGATOR SETTING yyyy 7.2.6 Manual Speed Setting (Manual Speed) Procedure Press [RADAR MENU] key twice. The Main Menu will appear. Press [7] key. NAV Equipment Setting Menu will appear. Press [4] key. The Code Input menu will appear. Pressing a numeric key, enter the value and select “ENT.”...

  • Page 354: Current Correction (Set/Drift) Setting

    7.2.7 Current Correction (SET/DRIFT) Setting The current set and drift will be set. Attention z The manually entered speed is effective only when “Speed Equipment” is set to “Manual” or “LOG”. Procedure Press [RADAR MENU] key twice. The Main Menu will appear. Press [7] key.
  • Page 355 7.2 NAVIGATOR SETTING yyyy <The alternative procedure for steps above> Hold down [RADAR MENU] key. The Code Input Menu will appear. Press [0] key. Move the cursor onto the “ENT” button in the Code Input menu, and press [ENT] key. The Adjust Menu will appear.

  • Page 356: Settings

    SETTINGS This section describes the electrical adjustment procedures to be performed by service engineers during system installation. CAUTION Do not carry out the adjustments of the equipment except authorized service persons. If wrong setting is carried out, this may cause unstable operation. Do not carry out the adjustments during navigation.

  • Page 357: Baud Rate Setting

    7.3 SETTINGS yyyy 7.3.1.1 Baud Rate Setting Set the baud rate of the signal to be entered into the COM port. Each ports on the menu represents following connectors. COM1(GPS) J3 GPS COM2(PC) J8 NMEA COM3(NAV1) J6 AIS/NMEA COM4(NAV2) J9 AUX COM5(NSK/COMPASS) J5 GYRO COMPASS Procedure...
  • Page 358 Exit Press [RADAR MENU] key. The Main Menu will reappear. 7 25...

  • Page 359: Reception Port Setting (Rx Port)

    7.3 SETTINGS yyyy 7.3.1.2 Reception Port Setting (RX Port) Set the number of the port via which signals are received from sensors. There are two methods for receiving signals: specifying a port for each sensor, or using the automatic recognition function without specifying ports. Procedure Hold down [RADAR MENU] key.

  • Page 360: Reception Sentence Setting (Rx Sentence)

    7.3.1.3 Reception Sentence Setting (RX Sentence) Set signal sentences to be received from sensors. Procedure Hold down [RADAR MENU] key. The Code Input Menu will appear. Press [0] key. Move the cursor onto the “ENT” button in the Code Input menu, and press [ENT] key.
  • Page 361 7.3 SETTINGS yyyy Data Set Number: 0-9. Set the number of the sentence to be used by Data Set Number. (Initial value 0) Layer A: 0-999. Set the number of the sentence to be used with layer A by Layer Number. (Initial value 3) Layer B: 0-999.

  • Page 362: Transmission Port Setting (Tx Port)

    7.3.1.4 Transmission Port Setting (TX Port) For each sentence, set a communication port through which signals are transmitted to sensors. Procedure Hold down [RADAR MENU] key. The Code Input Menu will appear. Press [0] key. Move the cursor onto the “ENT” button in the Code Input menu, and press [ENT] key.
  • Page 363 7.3 SETTINGS yyyy 6. HDT 7. THS Select which port you want to use for output. Types of ports to be used 1. OFF 2. COM1 (GPS) 3. COM2 (PC) 4. COM3 (NAV1) 5. COM4 (NAV2) Select the number of the port to be used, pressing the numeric key.

  • Page 364: Sector Blank Setting (Sector Blank)

    7.3.2 Sector Blank Setting (Sector Blank) Set a sector range, preventing displaying the radar echo only within the area. Three types of sector can be created. The sector blank function operates in the relative bearing with the bow. [I] Turning ON/OFF the Sector function (Sector 1, 2 and 3) Procedure Hold down [RADAR MENU] key.
  • Page 365 7.3 SETTINGS yyyy [II] Making Sector Function (Make Sector 1, 2, 3) Procedure Transmit the radar. Hold down [RADAR MENU] key. The Code Input Menu will appear. Press [0] key. Move the cursor onto the “ENT” button in the Code Input menu, and press [ENT] key.

  • Page 366: Tni Blank Setting (Tni Blank)

    7.3.3 TNI Blank Setting (TNI Blank) Set a sector and stop tuning operation in the bearing. If a structure such as the mast is close to the radar antenna, automatic tuning operation may become unstable. In this case, set a TNI blank in the direction of the structure in order to stabilize the tuning operation. Only one TNI blank sector can be created.
  • Page 367 7.3 SETTINGS yyyy [II] TNI Blank Area Creation (Make Sector) Procedure 1. Transmit the radar. Hold down [RADAR MENU] key. The Code Input Menu will appear. Press [0] key. Move the cursor onto the “ENT” button in the Code Input menu, and press [ENT] key.

  • Page 368: Bearing Pulse Output Adjustment (Output Pulse)

    7.3.4 Bearing Pulse Output Adjustment (Output Pulse) Set the output value of bearing pulse. This radar can set the output value to 2048 pulses and 4096 pulses. This setting is allowed only when a 25 kw antenna is used. Procedure Hold down [RADAR MENU] key.

  • Page 369: Language Setting (Language)

    7.3 SETTINGS yyyy 7.3.5 Language Setting (Language) You can switch between Japanese and English. Procedure Hold down [RADAR MENU] key. The Code Input Menu will appear. Press [0] key. Move the cursor onto the “ENT” button in the Code Input menu, and press [ENT] key.

  • Page 370: Date/Time Display Setting (Date/Time Setting)

    7.3.6 Date/Time Display Setting (Date/Time Setting) In displaying the time, it is necessary to set the LOCAL TIME, LOCAL DATE and TIME ZONE. When the “ZDA” sentence of NMEA0183 is received, Date/Time is displayed automatically. * If “ZDA” sentence is not received, the system internal clock function is used to display the date and time. Procedure Press [RADAR MENU] key twice.

  • Page 371: Adjustment

    7.4 ADJUSTMENT yyyy ADJUSTMENT This section describes the electrical adjustment procedures to be performed by service engineers during system installation. CAUTION Do not carry out the adjustments of the equipment except authorized service persons. If wrong setting is carried out, this may cause unstable operation. Do not carry out the adjustments during navigation.

  • Page 372: Noise Level Adjustment (Noise Level)

    7.4.1 Noise Level Adjustment (Noise Level) [I] Noise Level Adjustment for Signal Processing Procedure Hold down [RADAR MENU] key. The Code Input Menu will appear. Press [0] key. Move the cursor onto the “ENT” button in the Code Input menu, and press [ENT] key.
  • Page 373 7.4 ADJUSTMENT yyyy [II] Noise Level Adjustment Mode (Setting Mode) Procedure Hold down [RADAR MENU] key. The Code Input Menu will appear. Press [0] key. Move the cursor onto the “ENT” button in the Code Input menu, and press [ENT] key. The Adjust Menu will appear.

  • Page 374: Adjustment Of Target Tracking Function (Tt)

    7.4.2 Adjustment of Target Tracking Function (TT) CAUTION Optimal values have been set for Video Level and Vector Constant; therefore, never change their values unless absolutely necessary. Failure to comply may result in accidents that would lower target tracking performance. [I] Vector Constant Adjustment (Vector Constant) Adjust the vector follow-up performance of the target tracking function.
  • Page 375 7.4 ADJUSTMENT yyyy Procedure Hold down [RADAR MENU] key. The Code Input Menu will appear. Press [0] key. Move the cursor onto the “ENT” button in the Code Input menu, and press [ENT] key. The Adjust Menu will appear. Press [8] key while the Adjust Menu is open.
  • Page 376 Procedure Hold down [RADAR MENU] key. The Code Input Menu will appear. Press [0] key. Move the cursor onto the “ENT” button in the Code Input menu, and press [ENT] key. The Adjust Menu will appear. Press [8] key while the Adjust Menu is open.
  • Page 377 7.4 ADJUSTMENT yyyy [III] Gate Size Adjustment (Gate Size) Use the target tracking function (TT) to set a target search area. The gate size is adjusted to an optimal value, so do not change it carelessly. Procedure Hold down [RADAR MENU] key. The Code Input Menu will appear.
  • Page 378 [IV] CPA Limit Ring Display On/Off (Limit Ring) Use the target tracking function (TT) to determine whether to display the CPA limit for determining a dangerous ship. When the CPA limit ring display function is turned on and a relative vector is used, the CPA limit ring is displayed as a red circle.

  • Page 379: Main Bang Suppression Adjustment (Mbs Level)

    7.4 ADJUSTMENT yyyy 7.4.3 Main Bang Suppression Adjustment (MBS Level) Main Bang Suppression is adjusted to suppress main bang, a reflection signal from 3D circuit including wave guide tube, that generally appears as a circular image focusing on the center of the radar display. Optimum adjustment allows main bang image to remain lightly on the display.
  • Page 380 Press [2] key. The numeric keypad to be used in MBS Area Menu will appear. Input “20” as an MBS Area setting value. The value can also be entered with the multi-dial. Press [ENT] key after inputting the value. Input [1] key. The numeric keypad to be used in MBS Area Menu will appear.

  • Page 381: Adjustment Of Performance Monitor (Nju-85)

    7.4 ADJUSTMENT yyyy 7.4.4 Adjustment of Performance Monitor (NJU-85) After replacement of either of the following units, adjust the performance monitor according to the procedure in this section: x Performance monitor x Antenna unit [I] Transmission Monitor Adjustment (MON Adjustment) Adjust the circuit for monitoring the transmission performance of the radar equipment.
  • Page 382 [II] Reception Monitor Adjustment (MON Indicator Adjustment) Adjust the circuit for monitoring the reception performance of the radar equipment. Procedure Hold down [RADAR MENU] key. The Code Input Menu will appear. Press [0] key. Move the cursor onto the “ENT” button in the Code Input menu, and press [ENT] key.

  • Page 383: Maintenance Menu

    7.5 MAINTENANCE MENU yyyy MAINTENANCE MENU This item is provided for equipment maintenance, including settings of antenna safety switch, master reset, etc. CAUTION Only our service engineers are to make the adjustment. Neglecting this caution may cause accidents and failures. Do not make the adjustments during navigation.

  • Page 384: Scanner Safety Switch Setting (Safety Switch)

    7.5.1 Scanner Safety Switch Setting (Safety Switch) Use this switch to measure the transmission/reception performance while the antenna is in stopped state. Procedure Hold down [RADAR MENU] key. The Code Input Menu will appear. Press [0] key. Move the cursor onto the “ENT” button in the Code Input menu, and press [ENT] key.

  • Page 385: Initialization Of Memory Area (Area Initial)

    7.5 MAINTENANCE MENU yyyy 7.5.2 Initialization of Memory Area (Area Initial) If system operation is unstable, it may be stabilized by initializing the memory area. To initialize the memory area, follow the procedure in this section. The memory area is reset to the factory setting when initialized. [I] Partial Master Reset Procedure Hold down [RADAR MENU] key.
  • Page 386 [II] All Master Reset (All Master Reset) Procedure Hold down [RADAR MENU] key. The Code Input Menu will appear. Press [0] key. Move the cursor onto the “ENT” button in the Code Input menu, and press [ENT] key. The Adjust Menu will appear. Press [2] key.

  • Page 387: Save Of Internal Memory Data (Card2)

    7.5 MAINTENANCE MENU yyyy 7.5.3 Save of Internal Memory Data (Card2) The system can save internal memory data such as item settings in menus onto a flash memory card. If the radar processing circuit in the system has been replaced, the set values before the circuit replacement can be restored by reading the set values you saved before the replacement.
  • Page 388 [II] Reading of Internal Settings from Card (Card to Internal) Read the saved memory data from the flash memory card into the system memory. Perform the read operation in order to return the system to the previous operation condition after replacement of the radar processing circuit in the system.

  • Page 389: Update Of Character String Data (String Data Update)

    7.5 MAINTENANCE MENU yyyy 7.5.4 Update of Character String Data (String Data Update) The system is designed to transfer and display external character strings as the second language display. The second language is factory-set to "Japanese." Ask our agent or sales department for the supply of character strings to be updated. To update character strings, the flash memory card (option) containing the character string file must be inserted in card slot 2.

  • Page 390: Clear Of Antenna Operation Time (Txrx Time Clr)

    7.5.5 Clear of Antenna Operation Time (TXRX Time CLR) The system adds up the following operation time and contains it in the antenna unit: x Transmission time x Motor run time Clear the above total time when the magnetron or antenna unit motor is replaced. [I] Transmission Time Clear (TX Time Clear) Clear the transmission time of the antenna unit.
  • Page 391 7.5 MAINTENANCE MENU yyyy [II] Motor Run Time Clear (Motor Time Clear) Clear the transmission time of the antenna unit. Perform the following procedure to clear the transmission time when the magnetron is replaced. Procedure Hold down [RADAR MENU] key. The Code Input Menu will appear.
  • Page 392 [III] Antenna -> Display Unit (TXRX to Display Unit) Save the following antenna time data from the antenna unit into the display unit. x Antenna's operating hours x Transmission time x Motor run time Perform the following procedure to inherit the antenna time data when the antenna's internal control circuit is replaced.
  • Page 393 7.5 MAINTENANCE MENU yyyy [IV] Display Unit -> Antenna (Display Unit to TXRX) Restore the antenna time data from the display unit into the antenna's internal control circuit. Perform the following procedure to inherit the antenna time data when the antenna's internal control circuit is replaced.

  • Page 394: Update Of Ais Processor Program (Ais Proc Program Update)

    7.5.6 Update of AIS Processor Program (AIS PROC Program Update) AIS processor programs can be updated by using a flash memory card. In order to update AIS processor programs, the flash memory card (optional) containing the update program file must be inserted in the card slot 2 beforehand.

  • Page 395: Maintenance And Inspection

    REPLACEMENT OF MAJOR PARTS....... 8-23 8.4.1 Parts Required for Periodic Replacement ....8-25 8.4.2 Replacement of magnetron ........8-25 8.4.3 Motor Replacement ........... 8-31 8.4.4 Replacement of Diode Limiter (A303) (JMA-5212-4/6, 5222-7/9) ..........8-37 8.4.5 Replacement of Backup Battery........ 8-38...

  • Page 396: Routine Maintenance

    ROUTINE MAINTENANCE DANGER Never carry out internal inspection or repair work of the equipment by users. Inspection or repair work by unauthorized personnel may result in fire hazard or electric shock. Ask the nearest branch, business office or a dealer for inspection and repair.

  • Page 397: Maintenance On Each Unit

    yyyy 8.2 MAINTENANCE ON EACH UNIT yyyy MAINTENANCE ON EACH UNIT 8.2.1 Scanner Unit NKE-2103/2254 DANGER When conducting maintenance work on the antenna, make sure to turn its main power off. Failure to comply may result in electrocution or injuries. Make sure to turn off the antenna operation switch.
  • Page 398 Precautions in Mounting the Cover When the cover is removed for regular checkup and replacement of parts and refitted after such work, the procedure of fastening bolts shall be taken with the following precautions: (a) The proper fastening torque of the fitting bolts (M8) is 1176 to 1470 N•cm (120 to 150kgf•cm) (which makes the inside water-tight and protects the packings against permanent compressive strain).
  • Page 399 yyyy 8.2 MAINTENANCE ON EACH UNIT yyyy (1) Radiator Attention z If the radiator front face (radiation plane) is soiled with smoke, salt, dust, paint or birds’ droppings, wipe it with a piece of soft cloth wetted with alcohol or water and try to keep it clean at all times. Otherwise, radar beam radiation may attenuate or reflect on it, resulting in deterioration of radar performance.

  • Page 400: Display Unit Ncd-4380

    8.2.2 Display Unit NCD-4380 WARNING When cleaning the screen, do not wipe it too strongly with a dry cloth. Also, do not use gasoline or thinner to clean the screen. Otherwise the screen surface may be damaged. Dust accumulated on the screen will reduce clarity and darken the video. For cleaning it, wipe it with a piece of soft cloth (flannel or cotton).

  • Page 401: Performance Check

    yyyy 8.3 PERFORMANCE CHECK yyyy PERFORMANCE CHECK Make operational check on the radar equipment regularly and if any problem is found, investigate it immediately. Pay special attention to the high voltage sections in checking and take full care that no trouble is caused by any error or carelessness in measurement.

  • Page 402: 8.3.1 Test Menu

    8.3.1 Test Menu The performance status of this radar equipment can be checked on the TEST Menu. Self-diagnostic function Self Test [II] Monitor check Monitor Test [III] Operation panel check Keyboard Test [IV] Performance monitor MON Display Error log display Error Logging [VI] System information display System INFO...

  • Page 403: 8.3.1.1 Self-Diagnosis Function

    yyyy 8.3 PERFORMANCE CHECK yyyy 8.3.1.1 Self-diagnosis function Check of Memory, Scanner Unit, and Communications Lines 1) Memory check Memory Test Sensor Test 2) Antenna check Line Test 3) Communication line check Procedure Press [1] key while the Test Menu is open.
  • Page 404 [II] Sensor Test Checks for signals from the antenna. Antenna’s safety switch check Safety Switch Antenna rotation signal check AZI Pulse Heading line signal check HL Pulse MH Current Check on the load current of high voltage in the modulator Radar trigger signal check Trigger Radar video check...

  • Page 405: 8.3.1.2 Monitor Test

    yyyy 8.3 PERFORMANCE CHECK yyyy 8.3.1.2 Monitor Test Checks for the display. The test pattern will be shown on the display. Procedure Press [2] key while the Test Menu is open. The Monitor Test Menu will appear. Select the item number you want to display, pressing numeric keys [1] to [5] of the test pattern.

  • Page 406: 8.3.1.3 Operation Panel Test

    8.3.1.3 Operation Panel Test Checks for the controls and switches of the operation panel. 1) Key check Key Test 2) Buzzer check Buzzer Test Light 3) Keyboard light check Procedure Press [3] key while the Test Menu is open. The Keyboard Test Menu will appear. Select the item number you want to check, pressing numeric keys [1] to [3] of the item.
  • Page 407 yyyy 8.3 PERFORMANCE CHECK yyyy [II] Buzzer Test Checks for the operation panel buzzer. Procedure Press [2] key while the Keyboard Test menu is open. The buzzer will sound. The buzzer automatically stops after it sounds for a specified length of time. Exit Press [RADAR MENU] key.

  • Page 408: 8.3.1.4 Mon Display

    8.3.1.4 MON Display The performance monitor status is shown. * A performance monitor unit is required. Transmitter System Check attenuation in the transmitter system Attenuation Value Receiver System Check attenuation in the receiver system MON Pattern Range Attenuation Value Procedure Press [4] key while Test Menu is open.

  • Page 409: 8.3.1.5 Alarm Logging

    yyyy 8.3 PERFORMANCE CHECK yyyy 8.3.1.5 Alarm Logging Displays previously occurred system errors with the dates and times when they occurred. The current error is displayed in reverse video. Procedure Press [5] key while the Test Menu is open. The Alarm Log will appear. Error logs will be displayed.
  • Page 410 Table 8-2 System alarm warning list 1: Antenna Message Description TXRX(SSW Off) Antenna Safety switch is off TXRX(AZI) Antenna Rotation signal error TXRX(HL) Antenna Reference rotation signal error TXRX(MHV) Antenna Abnormal modulated high voltage TXRX(Time Out) Antenna No communication TXRX(Data) Antenna Abnormality in communication data, abnormality in checksum, and data disagreement TXRX(Heater) Antenna Abnormal MAG heater voltage...
  • Page 411 yyyy 8.3 PERFORMANCE CHECK yyyy Table 8-4 System alarm warning list 3: External device communication Message Description NSK(Time Out) NSK unit No communication GYRO(Data) Gyro Abnormality in communication data (error bit detection) Log(Data) Log Abnormality in communication data (error bit detection) Heading(Time Out) Course No communication Heading(Data)

  • Page 412: 8.3.1.6 System Info

    8.3.1.6 System INFO Displays the current system information. Processor software version information Indicator Scanner software version information TXRX System No. System number TXRX Time Total operating time of the scanner unit (Total power-on time of the antenna unit) Total Total operating time (Total power-on time) Motor Transmit Total transmitting time (Total time during which radar was transmitted)

  • Page 413: 8.3.1.7 Magi

    yyyy 8.3 PERFORMANCE CHECK yyyy 8.3.1.7 MAGI Displays the MAGI bar indicating the magnetron current to check. Procedure Check if the MAGI bar in the Test Menu reads the value below in a range of 24 6kW: 4 to 5 scale marks 10 kW: 4 to 7 scale marks 25 kW: 6 to 9 scale marks Exit...

  • Page 414: 8.3.2 Line Monitor

    8.3.2 Line Monitor Serial communication data can be seen on the built-in Line monitor. Line monitor can be used to make sure that the serial data are received properly. Procedure Hold down [RADAR MENU] key. The Code Input Menu will appear. Press [0] key.
  • Page 415 yyyy 8.3 PERFORMANCE CHECK yyyy LINE MONITOR display Received data ; The received serial communication data are displayed. Transmitted data ; The transmitted serial communication data are displayed. On-screen controls ; Line monitor can be controled by the following soft keys on the upper right corner of the LINE MONITOR.

  • Page 416: Gps Reception Status Display (Gps Status)

    8.3.3 GPS Reception Status Display (GPS Status) Display the reception status of the GPS receiver (GPS, DGPS and WAAS receivers) currently connected. Seize the status of satellites that are currently performing positioning. Procedure Press [RADAR MENU] key. The Main Menu will appear. Press [7] key.
  • Page 417 yyyy 8.3 PERFORMANCE CHECK yyyy GPS Status Display The following items are to appear on the Status display. DATE/TIME Local date and time (UTC) Greenwich Mean Time Current latitude and longitude FIX MODE Fix Mode (2D positioning/3D positioning) Altitude of own ship. Setting the Fix Mode to 2D displays the antenna height initially set.

  • Page 418: Replacement Of Major Parts

    REPLACEMENT OF MAJOR PARTS The system includes parts that need periodic replacement. The parts should be replaced as scheduled. Use of parts over their service life can cause a system failure. WARNING Direct exposure to electromagnetic waves at close range will have adverse effects on the human body.
  • Page 419 yyyy 8.4 REPLACEMENT OF MAJOR PARTS yyyy CAUTION Turn off the main power source before replacing parts. Otherwise, an electric shock or trouble may be caused. Before replacing the magnetron, turn off the main power source and wait for 5 minutes or more until the high voltage circuits are discharged.

  • Page 420: 8.4.1 Parts Required For Periodic Replacement

    8.4.1 Parts Required for Periodic Replacement Here are parts required for periodic replacement Part name Interval 1. Magnetron 4000 hours 2. Motor 10000 hours 3. LCD backlight 50000 hours 4. Fan motor 20000 hours 5. Backup battery 5 years 8.4.2 Replacement of magnetron Before replacing the magnetron, turn off the main power source, wait for five minutes or more, and confirm that no charge remains in the high-voltage modulator circuit.
  • Page 421 yyyy 8.4 REPLACEMENT OF MAJOR PARTS yyyy How to replace a 10 kW antenna magnetron Make sure that all radars are turned off before replacing the magnetron (if there are multiple radar devices, turn them all off). It is also recommended that the breaker be turned off for safety. Step 1: Turn off the antenna safety switch.
  • Page 422 Step 3: Remove the cable. J210 Cover Loosen all the screws (4 places). J209 Slide the cover to the left and remove it. Remove the encoder connector (1 place). (J209) Remove the equipment cable connectors (5 places). (J1 through J5) Screws (4 places) Remove the safety switch connectors Cable clamp screw...
  • Page 423 yyyy 8.4 REPLACEMENT OF MAJOR PARTS yyyy Step 4: Remove the transmitter-receiver. Hexagon bolts (5 places) Loosen all the hexagon bolts. Slide upward and remove the transmitter-receiver. Transmitter-receiver Step 5: Replace the magnetron. Remove the screws (2 places) and remove the Transmitter-receiver magnetron cable.
  • Page 424 How to replace a 25 kW antenna magnetron Make sure that all radars are turned off before replacing the magnetron (if there are multiple radar devices, turn them all off). It is also recommended that the breaker be turned off for safety. Step 1: Turn off the antenna safety switch.
  • Page 425 yyyy 8.4 REPLACEMENT OF MAJOR PARTS yyyy Step 3: Replace the magnetron. Magnetron cover Remove the screws (M4X10, at 4 places) and remove the magnetron cover. Screws (4 places) Screws (4 places) Magnetron Remove the screws (M4X12, at 2 places) and remove the magnetron cable.

  • Page 426: 8.4.3 Motor Replacement

    8.4.3 Motor Replacement First remove the cover, and then remove the socket of the motor. Remove the screws that hold the motor, and remove the motor. Connect the leads correctly after replacing the motor. How to replace a 10 kW antenna motor Make sure that all radars are turned off before replacing the magnetron (if there are multiple radar devices, turn them all off).
  • Page 427 yyyy 8.4 REPLACEMENT OF MAJOR PARTS yyyy Step 3: Remove the cable. Cover Loosen all the screws (4 places). J210 J209 Slide the cover to the left and remove it. Remove the encoder connector (1 place). (J209) Remove the equipment cable connectors (5 places).
  • Page 428 Step 4: Remove the transmitter-receiver. Hexagon bolts (5 places) Loosen all the hexagon bolts (5 places). Slide upward and remove the transmitter-receiver. Transmitter-receiver Step 5: Replace the motor. Remove the motor cable from the cable clamp. Remove the hexagon bolts (M6, at 4 places) and then remove the motor.
  • Page 429 yyyy 8.4 REPLACEMENT OF MAJOR PARTS yyyy How to replace a 25 kW antenna motor Make sure that all radars are turned off before replacing the magnetron (if there are multiple radar devices, turn them all off). It is also recommended that the breaker be turned off for safety. Step 1: Turn off the antenna safety switch.
  • Page 430 Step 4: Replace the motor. Hexagon bolts (4 places) The motor is fixed with 4 hexagon bolts (M8 x 20 SW W, embedded type). Remove all the hexagon bolts (4 pieces). Motor Protrusions for adjusting the motor position Remove the motor. The motor weighs about 6 kg.
  • Page 431 yyyy 8.4 REPLACEMENT OF MAJOR PARTS yyyy Step 5: Connect the motor cables. Reconnect the cables to the motor control power circuit. Step 6: Put the cover on. Before attaching the cover to the antenna, make sure that the gasket of the cover is not deformed or cracked.

  • Page 432: Replacement Of Diode Limiter (A303) (Jma-5212-4/6, 5222-7/9)

    8.4.4 Replacement of Diode Limiter (A303) (JMA-5212-4/6, 5222-7/9) Remove the 4 screws fixing the receiver. Remove the 4 screws fixing the diode and the limiter, and remove diode limiter. When mounting the diode limiter, take care of the mounting direction and mount it in the arrow direction facing it the receiver front end.

  • Page 433: 8.4.5 Replacement Of Backup Battery

    yyyy 8.4 REPLACEMENT OF MAJOR PARTS yyyy 8.4.5 Replacement of Backup Battery Caution: Replacement of backup battery must be made by specialized service personnel. For details, refer to Service Manual. A coin-cell battery maintains radar system configuration, date, and time information while power off condition. radar system configuration is saving to non-volatile memory at fixed intervals.
  • Page 434 8 39...

  • Page 435: Troubleshooting And After-Sales Service

    SECTION 9 TROUBLESHOOTING AND AFTER-SALES SERVICE Fault Finding............. 9-1 9.1.1 List of Alarms and other Indications ..9-1 9.1.2 Operation Checking ........9-4 9.1.3 Fuse Checking ........... 9-4 TROUBLE SHOOTING........9-5 9.2.1 Spares ............9-6 9.2.2 Special Parts ..........9-8 9.2.3 Circuit Block to be Repaired ....

  • Page 436: Fault Finding

    FAULT FINDING In case of semiconductor circuits, it is deemed that there are few cases in which the used semiconductor devices have inferior quality or performance deterioration except due to insufficient design or inspection or by other external and artificial causes. In general, the relatively many causes are disconnection in a high-value resistor due to moisture, a defective variable resistor and poor contact of a switch or relay.
  • Page 437 yyyy 9.1 FAULT FINDING yyyy Table 9-3 List of Target Tracking Alarms and AIS Function Alarms Message Description TT(CPA/TCPA) TT Dangerous target AIS(CPA/TCPA) AIS Dangerous target Radar Alarm(In) Radar alarm (approaching) Radar Alarm(Out) Radar alarm (leaving) TT Automatic new target acquisition in the automatic acquisition area TT(New Target AIS Automatic new target acquisition in the automatic acquisition area AIS(New Target...
  • Page 438 Table 9-5 List of System Operation Error Messages and Warnings Message Description Not Allowed The executed operation is invalid. No Heading Data There is no bearing data. No Position Data There is no position data. Can't Transmit Transmission cannot be executed. Invalid Data The value is invalid.

  • Page 439: Operation Checking

    yyyy 9.1 FAULT FINDING yyyy 9.1.2 Operation Checking When the system is operating, the operation status (located at the upper right of the screen) is changing pictures. If picture freeze occurred, turn off the system and restart the system. 9.1.3 Fuse Checking Melted fuses are caused by any clear cause.

  • Page 440: Trouble Shooting

    TROUBLE SHOOTING As this radar equipment includes complicated circuits, it is necessary to request a specialist engineer for repair or instructions for remedy if any circuit is defective. There are also troubles by the following causes, which should be referred to in checking or repair work. Poor Contact in Terminal Board of Inter-Unit Cables Poor contact in terminal board The cable end is not fully connected, that it, contacted with earthed another terminal.

  • Page 441: Spares

    yyyy 9.2 TROUBLE SHOOTING yyyy 9.2.1 Spares Table 9-7 Spares 7ZXRD0026 : Scanner NKE-2103 (10kw) Name Type/Code Shape (mm) Number Parts No. Location Application Inside ST4-5AN1 6.35 For the antenna Fuse processing 31.8 motor (5ZFCA00050) unit Inside For the power ST6-10AN1 6.35 Fuse...
  • Page 442 7ZXRD0027 : Processor unit NDC-1460 Name Type Cde Shape (mm) In use Spare Parts No. Loccation Application 44.0 LTWBD- Inside Mainly for GPS Connector 06BFFA-LL7001 processing connection unit (5JCDX00032) 44.0 LTWBD- Mainly for Inside connecting course Connector 08BFFA-LL7001 processing equipment such as a unit (5JCDX00034) GPS compass...

  • Page 443: Special Parts

    NJRC Scanner unit 5AWAX00002 A301 Diode Limiter NJS6930 NJRC Scanner unit 5ATBT00006 9.2.3 Circuit Block to be Repaired Table 9-9 Circuit Block to be Repaired (JMA-5212-4/6) Location Circuit Block Type Remarks Scanner Motor with gear 7BDRD0048 DC brushless motor Scanner...
  • Page 444 Table 9-10 Circuit Block to be Repaired (JMA-5222-7/9) Location Circuit Block Type Remarks Scanner Motor with gear 7BDRD0044A DC brushless motor (ordinary speed) Scanner Motor with gear 7BDRD0045A DC brushless motor (high speed) Scanner Modulator NMA-550 Including CPA-264 Including CMB-404 Excluding Magnetron Scanner Receiver...

  • Page 445: After-Sales Service

    yyyy 9.3 AFTER-SALES SERVICE yyyy AFTER-SALES SERVICE 9.3.1 Keeping period of maintenance parts Keeping period of maintenance parts is ten years from the production is discontinued. 9.3.2 When you Request for Repair If you suppose the product may be out of order, read the description in Section 9.1 “FAULT FINDING”...

  • Page 446: Radar Failure Check List

    Radar Failure Check List When placing an order for repair of the product, it is requested that you could confirm the check items and fill the results and sent the sheet to our contact. If there is any unclear items, contact the ship on which the product is installed, and give the correct information on the product.

  • Page 447: Disposal

    SECTION 10 DISPOSAL 10.1 DISPOSAL OF THE UNIT......10-1 10.2 DISPOSAL OF USED BATTERIES ..10-2 10.3 DISPOSAL OF USED MAGNETRON ..10-3 10.4 ABOUT THE CHINA ROHS..... 10-4...

  • Page 448: Disposal Of The Unit

    10.1 DISPOSAL OF THE UNIT When disposing of this unit, be sure to follow the local laws and regulations for the place of disposal. 10 1...

  • Page 449: Disposal Of Used Batteries

    yyyy 10.2 DISPOSAL OF USED BATTERIES yyyy 10.2 DISPOSAL OF USED BATTERIES WARNING When disposing of used lithium batteries, be sure to insulate the batteries by taping the † and terminals. Otherwise, heat generation, explosion or a fire may occur. In this unit, Lithium batteries are used for the following parts: Radar Processing circuit (CDC-1350): BT1 (Maxell: CR2450) z Do not store used lithium batteries.

  • Page 450: Disposal Of Used Magnetron

    10.3 DISPOSAL OF USED MAGNETRON Magnetron is used in the Scanner NKE 1130/2103/2254 z When the magnetron is replaced with a new one, return the used magnetron to our dealer or business office. For detail, consult with our dealer or business office. 10 3...

  • Page 451: About The China Rohs

    yyyy 10.3 DISPOSAL OF USED MAGNETRON yyyy 10.4 ABOUT THE CHINA ROHS (Names & Content of toxic and hazardous substances or elements (Type): JMA-5200MK2 Series (Name): RADAR (Toxic and Hazardous Substances and Elements) (Part name) (Pb) (Hg) (Cd) (Cr6+) (PBB) (PBDE) ˜...
  • Page 452 10 5...

  • Page 453: Specifications

    SECTION 11 SPECIFICATIONS 11.1 JMA-5212-4/6 TYPE RADAR............11-1 11.2 JMA-5222-7/9 TYPE RADAR............11-2 11.3 SCANNER (NKE-2103-4/6).............11-3 11.4 SCANNER (NKE-2254-7/9).............11-4 11.5 DISPLAY UNIT (NCD-4380) ............11-5 11.6 PROCESSOR UNIT (NDC-1460) ............11-6 11.7 TARGET TRACKING UNIT (NCA-877A) ........11-8 11.8 AIS UNIT (NQA-2155) ..............11-9 11.9 PLOTTER UNIT ................11-10 11.10...

  • Page 454: Jma-5212-4/6 Type Radar

    11.1 JMA-5212-4/6 TYPE RADAR (1) Class of emission (2) Display Color Raster Scan, PPI Method (3) Screen 15-inch Color LCD Effective diameter of radar display, more than 180 mm (4) Range Scale 0.125, 0.25, 0.5, 0.75, 1.5, 3, 6, 12, 24, 48, 96 nm...

  • Page 455: Jma-5222-7/9 Type Radar

    yyyy 11.2 JMA-5222-7/9 TYPE RADAR yyyy 11.2 JMA-5222-7/9 TYPE RADAR (1) Class of emission (2) Display Color Raster Scan, PPI Method (3) Screen 15-inch Color LCD Effective diameter of radar display, more than 180 mm (4) Range Scale 0.125, 0.25, 0.5, 0.75, 1.5, 3, 6, 12, 24, 48, 96 nm (5) Range Resolution Less than 30m (6) Minimum Detective Range...

  • Page 456: Scanner (Nke-2103-4/6)

    11.3 SCANNER (NKE-2103-4/6) (1) Dimensions 10kW-4ft: Height 458mmuSwing Circle 1285mm 10kW-6ft: Height 458mmuSwing Circle 1910mm (2) Mass 10kW-4ft: Approx. 38 kg 10kW-6ft: Approx. 40 kg (3) Polarization Horizontal Polarization (4) Directional Characteristic Horizontal Beam Width: 1.8° (4ft, –3dB width) 1.2° (6ft, –3dB width) Vertical Beam Width: 20°...

  • Page 457: Scanner (Nke-2254-7/9)

    yyyy 11.4 SCANNER (NKE-2254-7/9) yyyy 11.4 SCANNER (NKE-2254-7/9) (1) Dimensions 25kW-7ft: Height 536mmuSwing Circle 2270mm 25kW-9ft: Height 536mmuSwing Circle 2825mm (2) Mass 25kW-7ft: Approx. 58 kg 25kW-9ft: Approx. 60 kg (3) Polarization Horizontal Polarization (4) Directional Characteristics Horizontal Beam Width: 1.0°...

  • Page 458: Display Unit (Ncd-4380)

    11.5 DISPLAY UNIT (NCD-4380) (1) Structure Desk Top Type (LCD Monitor Unit/Keyboard Unit/Processor Unit Separation Structure) (2) Screen 15-inch Color LCD 1024x768 dot (XGA) Viewing Distance: 1m from the center of Display (3) Display mode Radar mode Synthesis mode (Synthesis Radar echo and Coastline) Plotter mode (Require Plotter Unit (option)) (4) Range Scale 0.125, 0.25, 0.5, 0.75, 1.5, 3, 6, 12, 24, 48, 96nm...

  • Page 459: Processor Unit (Ndc-1460)

    yyyy 11.6 PROCESSOR UNIT (NDC-1460) yyyy 11.6 PROCESSOR UNIT (NDC-1460) (1) Structure Desk Top Type (Horizontal putting and length putting using combinedly) (2) Dimensions Height 125mmuWidth 340mmuDepth 347mm (3) Mass Approx. 4kg (4) Tune Method AUTO/MANUAL (Bar-graph indicate) (5) STC (SEA) AUTO/MANUAL (6) FTC (RAIN) AUTO/MANUAL...
  • Page 460 (15) Twice zoom The zoom center is 66% radius of any range. (Except 0.125nm) (16) Radar trails indication True motion: (Only true motion) Relative motion: True motion trails and relative motion trails can be selected. Trail time length: 15 sec/30 sec/1 min/3 min/6 min/10 min/15 min/30 min/60 min/Continuous/OFF Arbitrary trail time length can be displayed at any time.

  • Page 461: Target Tracking Unit (Nca-877A)

    yyyy 11.7 TARGET TRACKING UNIT (NCA-877A) yyyy 11.7 TARGET TRACKING UNIT (NCA-877A) Radar mode, synthesis mode 1) Acquisition MANUAL/AUTO (by automatic acquisition/activation zone) 2) Tracking 30 target (Automatic tracking) Maximum tracking range: 32nm (Available all range scale) 3) Display Tracking data: 2 at the same time. (Can be scroll.) Naming function: Possible to name by the alphabet up to 8 characters to each target.

  • Page 462: Ais Unit (Nqa-2155)

    11.8 AIS UNIT (NQA-2155) Radar mode, synthesis mode 1) Activation 30 target MANUAL/AUTO (by automatic activation/activation zone) 2) Display 130 target (sleeping target and activated target) AIS data: 1 at the same time. (simple display) Vector display: True/Relative Past position The message can be displayed.

  • Page 463: Plotter Unit

    yyyy 11.9 PLOTTER UNIT yyyy 11.9 PLOTTER UNIT Plotter (Normal) (Synthesis mode) Projection: Mercator projection (Latitude 70 degree or less.) Scale: Radar synchronize range scale Own ship trail: Color of 1 stage. Interval of storage 3/5/10/30 sec, 1/3/5/10/30/60 min or every 0.1/0.2/0.3/0.5/1/3/5/10 nm and OFF Cursor mark : Storage Capacity 7,000 point...
  • Page 464 Plotter (Option NDB-44) (Synthesis mode) Projection: Mercator projection (Latitude 85 degree or less.) Scale: 1/1,000 to 1/10,000,000 are continuously selected. 10 stage can be changed (Preset can be used) Own ship trail: Color of 7 stages. Interval of storage: 3/5/10/30 sec, 1/3/5/10/30/60 min or every 0.1/0.2/0.3/0.5/1/3/5/10 nm and OFF Storage capacity of own ship trail: 7,000 point Cursor mark:...

  • Page 465: Keyboard Unit (Nce-7699A)

    yyyy 11.10 KEYBOARD UNIT (NCE-7699A) yyyy 11.10 KEYBOARD UNIT (NCE-7699A) Structure Structure of keyboard unit is separate from processor unit. Desk-Top type Correspond Flush mount Switch Gain (Transmit pulse width can be changed by PUSH-SW.) SEA (AUTO/MANU can be changed by PUSH-SW.) RAIN (AUTO/MANU can be changed by PUSH-SW.) MULTI (Adjustment item can be changed by PUSH-SW) EBL (Floating EBL ON/OFF can be changed by PUSH-SW.)

  • Page 466: Performance Monitor (Nju-85)

    11.11 PERFORMANCE MONITOR (NJU-85) Dimensions Height 130mmuWidth 149mmuDepth 70mm Mass Approx. 1.2kg Operating frequency 9410 ±30MHz 11.12 INPUT ENABLE SIGNAL Navigation equipment: IEC61162-1/2 Receive port NAV1/NAV2/GPS port Receive capability sentence. Longitude/Latitude: GGA>RMC>RMA>GNS/GLL Waypoint: RMB>BWC(BWR) COG/SOG: RMC>RMA>VTG SPEED: VBW Day/Time information: ZDA Alarm acknowledge: ACK Rate of Turn : ROT Rudder : RSA...

  • Page 467: Output Enable Signal

    yyyy 11.13 OUTPUT ENABLE SIGNAL yyyy 11.13 OUTPUT ENABLE SIGNAL Slave video Radar video: TIY, VD, BP(2048p), BZ (Option) Navigation information IEC61162-1/2 Radar system data: RSD Own ship data: OSD Tracking target data: TTM, TLL, TTD, TLB Alarm: ALR Auto pilot: APB Bearing of destination: BOD Latitude/Longitude data : GGA, GLL, RMC Waypoint data : RMB, BWC...

  • Page 468: Equipment Distance Between Other Instruments

    11.15 EQUIPMENT DISTANCE BETWEEN OTHER INSTRUMENTS Maximum LCD monitor to processor unit Keyboard unit to processor unit Scanner to display unit (10/25kw) 11.16 OTHERS (OPTION) x Equipment cable 10/25 kW type (connectors on both ends) Cable length: 10m CFQ-6912-10/15m CFQ-6912-15 20m CFQ-6912-20/30m CFQ-6912-30 40m CFQ-6912-40/50m CFQ-6912-50 65m CFQ-6912-65...
  • Page 469 FIGURE 1 JMA-5212-4/6, JMA-5222-7/9 BLOCK DIAGRAM FIGURE 2 JMA-5212-4/6 INTER-CONNECTION DIAGRAM FIGURE 3 JMA-5222-7/9 INTER-CONNECTION DIAGRAM FIGURE 4 PRIMARY POWER SUPPLY DIAGRAM, TYPE JMA-5212-4/6, JMA-5222-7/9 FIGURE 5 PROCESSOR UNIT, NDC-1460 INTER-CONNECTION DIAGRAM FIGURE 6 KEY-BOARD UNIT, NCE-7699A INTER-CONNECTION DIAGRAM FIGURE 7 NKE-2103 SCANNER UNIT INTERCONNECTION DIAGRAM...
  • Page 470 Figure 1 JMA-5212-4/6, JMA-5222-7/9 Block Diagram...
  • Page 471 Figure 2 JMA-5212-4/6 Inter-connection Diagram...
  • Page 472 Figure 3 JMA-5222-7/9 Inter-connection Diagram...
  • Page 473 Figure 4 Primary Power Supply Diagram, Type JMA-5212-4/6, JMA-5222-7/9...
  • Page 474 Figure 5 Processor Unit, NDC-1460 Inter-connection Diagram...
  • Page 475 Figure 6 Key-board Unit, NCE-7699A Inter-connection Diagram...
  • Page 476 19 Fig.19 NKE-2103 Scanner Unit Interconnection Diagram Figure 7 NKE-2103 Scanner Unit Interconnection Diagram...
  • Page 477 Figure 8 NKE-2254 Interconnection Diagram of Scanner Unit...
  • Page 478 Area 5 (Own ship’s information) Area 6 (Other ship’s information) Area 1 Area 3 (Top-left corner of (Top-right corner of the radar display) the radar display) CMPS Cursor 000.0 000.0 Compass True 089.6 35 33.037' 0.0kn 5.37 NM 140 01.597'E Rings 1NM EBL1 045.0...
  • Page 479 Area 1 (Top-left corner of the radar display) Refer to Section 7.1.2. Refer to Section 3.4.3. 000.0 Compass Refer to Section 3.4.9, 3.4.10 or 4.2. Rings 1NM Refer to Section 3.5.8. RM(R) H UP Off Center Refer to Section 3.5.9. Refer to Section 3.5.11.
  • Page 480 Area 4 (Bottom-right corner of the radar display) Refer to Section 3.6.2 Refer to Section 2.3.4. or 3.6.3. Refer to Section 3.5.15. Refer to Plotter Option Refer to Plotter Option Manual Section 3.42. Manual Section 3.35. TRK 30 sec Shift Refer to Section 3.6.1.
  • Page 481 Area 7 (Panel display) AIS ID DEST POSN EPFS RAIM POSN Accuracy AIS ID Range TCPA /min Refer to Section 5.3.6. AIS ID Name Call SIGN MMSI IMO Number NAV Status AIS ID AtoN Real/Virtual AtoN Type Area 7 (Panel display) TT ID Range Cource...
  • Page 482 Area 8 (Operation/message) Refer to Section 3.3.3. Refer to Section 3.3.2. < > Brilliance Refer to Section 2.3.9. Refer to Section 3.3.2. Panel Day1 Refer to Section 3.3.4. Refer to Section ?.?.?. < > Menu Refer to Section 3.2.2. Refer to Section ?.?.?. Close RADAR Refer to Section 3.11.1.
