JRC JMA-5212-4/6 Service Manual
Hide thumbs Also See for JMA-5212-4/6:
Table of Contents

Advertisement

JMA-5212-4/6
JMA-5212-4/6
JMA-5222-7/9
JMA-5222-7/9
JMA-5212-4HS/6HS
JMA-5212-4HS/6HS
MARINE RADAR
MARINE RADAR
EQUIPMENT
EQUIPMENT
FIELD SERVICE
FIELD SERVICE
MANUAL
MANUAL

Advertisement

Table of Contents
loading

Summary of Contents for JRC JMA-5212-4/6

  • Page 1 JMA-5212-4/6 JMA-5212-4/6 JMA-5222-7/9 JMA-5222-7/9 JMA-5212-4HS/6HS JMA-5212-4HS/6HS MARINE RADAR MARINE RADAR EQUIPMENT EQUIPMENT FIELD SERVICE FIELD SERVICE MANUAL MANUAL...
  • Page 3: Table Of Contents

    2.5.5. T/R Control Circuit CMC-1205R..................2-21 Chapter 3_Service Parts 3.1. Service Parts Lists for the Units ..................... 3-1 3.1.1. Spare Parts ........................3-1 3.1.2. Special Parts ........................3-2 3.1.3. NKE-2103 (JMA-5212-4/6/4HS/6HS)................3-2 3.1.4. NKE-2254 (JMA-5222-7/9)....................3-3 3.1.5. NCD-4380 ........................3-3...
  • Page 4 3.2. Exploded Diagrams........................ 3-4 3.2.1. NKE-2103 ........................3-4 3.2.2. NKE-2254 ........................3-8 3.2.3. NDC-1460 ........................3-12 3.2.4. NCE-7699A........................3-16 Chapter 4_Replacement of Major Units 4.1. Scanner Unit .......................... 4-1 4.1.1. Precautions for replacing parts in the scanner unit ............4-1 4.1.2.
  • Page 5 4.2.9. Operation Circuit CCK-979 for the Standard Operation Unit ......... 4-47 4.2.10. PS2 Connector Circuit CQC-1204 for the Standard Operation Unit ......4-49 4.2.11. Trackball TRD-101S(BK)N1 for the Standard Operation Unit........4-51 Chapter 5_Program Update 5.1. Main Program Update Procedure................... 5-1 5.1.1.
  • Page 6 Outline Drawing of the Rectifier NBA-5111 (Option)............7-10 7.2. System Diagrams........................7-11 7.2.1. Overall System Diagram of the Radar JMA-5222-7/9 ............7-11 7.2.2. Overall System Diagram of the Radar JMA-5212-4/6/4HS/6HS ........7-12 7.3. Inter-Unit Connection Diagram..................... 7-13 7.3.1. Inter-Unit Connection Diagram of the JMA-5222-7/9 ............ 7-13 7.3.2.
  • Page 7: Chapter 1_Equipment Overview

    Chapter 1 Equipment Overview...
  • Page 9: Overview

    1.1. Overview This equipment is marine radar equipment satisfying the IMO standard. The radar equipment consists of a scanner unit that generates transmitting signals, transmits and receives radio waves, and amplifies receiving signals, and a display system that displays radar images after removing unwanted radio wave from the radar signals. The radar equipment with which a magnetron tube is used as the transmitting tube transmits 9.4 GHz (X band) pulse-modulated waves.
  • Page 10: Display System

    1.3. Display System The display system processes a radar signal transmitted from the scanner unit, removes unwanted radio wave, and plots/displays radar images in a specified observation range. The user is to stand in front of the display system and observe the conditions around the own ship with the radar images displayed on the display unit by operating the switches and trackball on the operation unit.
  • Page 11: Chapter 2_Equipment Overview

    Chapter 2 Equipment Overview...
  • Page 13: Configuration

    2.1. Configuration 2.1.1. Scanners and Transmitted Output Powers IMO compliance MODEL TRANSMITTED RATE OF SCANNER BAND CATEGORY NUMBER OUTPUT POWER ROTATION JMA-5212-4 4 FT SLOT ANTENNA 10kW 27rpm CAT 2 JMA-5212-6 6 FT SLOT ANTENNA 10kW 27rpm CAT 2 JMA-5222-7 7 FT SLOT ANTENNA 25kW 24rpm...
  • Page 14: Radar Configuration And Ship's Mains

    2.1.2. Radar Configuration and Ship's Mains IMO compliance MODEL PERFORMANCE DISPLAY SCANNER SHIP'S MAINS NUMBER MONITOR UNIT SYSTEM JMA-5212-4 NKE-2103-4 NJU-85 NCD-4380 DC24V JMA-5212-6 NKE-2103-6 NJU-85 NCD-4380 DC24V JMA-5222-7 NKE-2254-7 NJU-85 NCD-4380 DC24V JMA-5222-9 NKE-2254-9 NJU-85 NCD-4380 DC24V Non IMO compliance MODEL PERFORMANCE DISPLAY...
  • Page 15 (Notes) A deicing mechanism (neck heater) is optional. "D" is suffixed to the model number of a scanner unit with a deicing mechanism. Keep in mind that only power supply of 100-115 VAC, 50/60 Hz and single phase is applicable to the neck heater and that a deicing mechanism cannot be installed in the NKE-2103.
  • Page 16: Power System Diagram

    2.2. Power System Diagram Figure 2.1 Power System Diagram...
  • Page 17 Figure 2.1 shows the power system diagram of this equipment. DC power passes through the circuit breaker via the line filter in the power circuit CBD-1702A, and it is re-input to the power circuit CBD-1702A for generating the supply voltage to be used inside the equipment. The power circuits are of the high-efficiency switching type.
  • Page 18: Functional System Diagram

    2.3. Functional System Diagram 2.3.1. Scanner Unit NKE-2254 Scanner Unit SLOT ANTENNA ROTARY MOTOR A, B, Z ENCODER JOINT B101 FILTER DIODE LIMITER V101 RECEIVER PULSE Tune Control RF AMP TRANS DUMMY LOAD Receiver Bandwidth SWITCHING Control IF AMP CIRCUIT PC201 Tx Trigger/Pulse Width VIDEO...
  • Page 19: Display System

    Figure 2.2 shows the functional system diagram of the scanner unit for this equipment. When the power relay for the scanner unit in the display system is turned on and power is supplied to the scanner unit, the power circuit starts power supply to each circuit of the scanner unit.
  • Page 20 The received radar video signal, transmission timing signal, and antenna rotation signal are sent to the display system. The radar video signal is a non-processed, log-compressed signal. The antenna rotation signal is an incremental signal, and 2048 rotation pulses and reference bearing pulses per cycle are used.
  • Page 21 2.3.2. Display System Figure 2.3 Functional System Diagram of the Display System...
  • Page 22 Figure 2.3 shows the functional system diagram of the display system for this equipment. A. Start of the equipment When the power switch on the operation unit is turned on, the power circuit CBD-1702A is started, and generated voltages are supplied to the radar processing circuit CDC-1350. Then, the CPU in each control circuit starts up and performs initialization.
  • Page 23 After converting radar signals (radar video signal, transmission timing signal, and antenna rotation signal which are sent from the scanner) to digital data, the radar signal processing circuit in the radar processing circuit suppresses unwanted waves, and plots and displays radar images in accordance with the display screen. The ARPA processing circuit receives radar signal data for which unwanted waves are suppressed by the radar processing circuit, and performs target tracking.
  • Page 24: Input/Output Specifications

    2.4. Input/Output Specifications This section explains the signals to be connected to connectors in the power circuit CBD-1702A. 2.4.1. SCANNER (J2) SCANNER (J2) is used for connection with the scanner unit. NAME DESCRIPTION APPLICATION 1 MOTOR- 2 MOTOR- 3 TRX- 4 MOTOR+ 5 MOTOR+ 6 TRX+...
  • Page 25: Gps (J3)

    2.4.2. GPS (J3) GPS (J3) is used for connection with the GPS. NAME DESCRIPTION APPLICATION Used for direct connection with a 1 +12V JRC GPS receiver 2 GND Same as above 3 NAVCOM Data return 4 NAVRX Data input Used for direct connection with a 5 NAVTX JRC GPS receiver 2.4.3.
  • Page 26: Ais/Nmea (J6)

    2.4.4. AIS/NMEA (J6) AIS/NMEA (J6) is used for connection with the AIS or external navigator. *) If the AIS is connected, other NMEA equipment cannot be connected. NAME DESCRIPTION APPLICATION Signal (+) received from external 1 NMEA RXD+ equipment Signal (-) received from external 2 NMEA RXD- equipment 3 NMEA TXD+...
  • Page 27: Dip-Sw/Jumper Setting

    2.5. DIP-SW/Jumper Setting 2.5.1. Power Circuit CBD-1702A Jumper setting A jumper post is installed at the location indicated in the figure at right. If an external buzzer is connected to the pin J5-6/7, use the jumper TB1J to determine whether to open or close the buzzer contact in accordance with the status of use under normal conditions.
  • Page 28 To make a connection with the PC plotter and RS232C, connect the jumper TB4J to RS232C as shown in the picture below. Connect the jumper TB4J on the RS232C side. 2-16...
  • Page 29: Gyro I/F Circuit Cmj-304E

    2.5.2. GYRO I/F Circuit CMJ-304E DIP-SW/jumper setting (1) TB100: Not to be used. Leave the factory setting as is. (2) TB105: Availability of setting if input voltage for the gyro is low 1-2: Ordinary setting (factory setting) 2-3: Setting when voltage for the gyro is low (CD56 is lighted when the voltage is 22 VDC or less.
  • Page 30 S4 and S5: Gyro setting and log setting S5 SETTING TABLE STEP SYNC 360X OFF OFF 180X OFF ON DIRECTION NOR PULSE TYPE SYNC Don't care 800P 360X OFF OFF 400P 180X PULSE/NM 200P 90X OFF ON 100P 30X S4 SETTING TABLE LOG ALARM GYRO SIMULATOR LOG SIMULATOR...
  • Page 31 (7) S6: Rest switch Resets the CPU. (8) S7: Zero-degree setting switch Sets, as the due north, the bearing at the point of pressing. (9) S2 and S3: Selection of a gyro type Left: Step Right: Synchro (10) S1: Gyro ON-OFF switch Left: Right: (11) S10: Other settings are not to be used.
  • Page 32: Radar Processing Circuit Cdc-1350

    2.5.3. Radar Processing Circuit CDC-1350 (1) S300: 6-bit DIP-SW. All the bits are factory-set to OFF. Do not change any of the factory settings. S300 OFF (Do not change this setting.) OFF (Do not change this setting.) OFF (Do not change this setting.) OFF (Do not change this setting.) OFF (Do not change this setting.) OFF (Do not change this setting.)
  • Page 33: T/R Control Circuit Cmc-1205R

    2.5.5. T/R Control Circuit CMC-1205R [Type of DIP switch] [Type of jumper pin] • SW1 and SW2 • J92, J93, J95, and J96 { NKE-2254 (2 units: 25 kW, X-band) • Jumper pin setting • DIP switch setting („: Switch) 3 2 1 Jumper pins J92,J93,J95,J96: 1-2 jumpered...
  • Page 34 2-22...
  • Page 35 Chapter 3 Service Parts...
  • Page 37: Service Parts Lists For The Units

    3.1. Service Parts Lists for the Units 3.1.1. Spare Parts 7ZXRD0026 (JMA-5212-4/6/4HS/6HS) Name Type/Code Shape (mm) In Use Spare Parts No. Location 6.35 Inside ST4-5AN1 Fuse processing 31.8 (5ZFCA00050) unit Inside 6.35 ST6-10AN1 Fuse processing 31.8 (5ZFCA00053) unit 7ZXRD0015 (JMA-5222-7/9)
  • Page 38: Special Parts

    A104 Filter NJC9952 NJRC 5AWAX00002 unit Scanner A301 Diode limiter NJS6930 NJRC 5ATBT00006 unit 3.1.3. NKE-2103 (JMA-5212-4/6/4HS/6HS) Location Circuit Block Type Remarks Scanner unit Motor with gear 7BDRD0048 DC brushless motor Scanner unit Modulation circuit CME-363 Magnetron not included Scanner unit...
  • Page 39: Ncd-4380

    3.1.4. NKE-2254 (JMA-5222-7/9) Location Circuit Block Type Remarks DC brushless motor Scanner unit Motor with gear 7BDRD0044A (ordinary speed) DC brushless motor Scanner unit Motor with gear 7BDRD0045A (high speed) CPA-264 included CMB-404 included Scanner unit Modulator NMA-550 CRF-229 included Magnetron not included Scanner unit Modulation circuit...
  • Page 40: Exploded Diagrams

    3.2. Exploded Diagrams 3.2.1. NKE-2103 PRODUCT CODE SERVICE CODE NOTE Radiator Assy. MDNAX5041 NAX-16B-6 NAX-16B-6 Radiator Assy. MDNAX5041 Bolts BRTG07249 M10X35SUS S-cort Spring Washers BRTG00404 SW10 SUS Washers MTL315466 Support Assy. MPGK31182 Antenna Support MTC301684 Slide Plate MTT309252 Waterproof Ring 309256A O-Ring BRPK00054...
  • Page 41 Packing MTT305919A Swich Cover MPPK00925A Cable Push Plate MTB366112 Cable Clamp BRBP00009 Cross-recessed Head Screw BSNK04010B NK4X10Bs Cross-recessed Head Screw BSNC04010B NC4X10Bs 9-10 Cross-recessed Head Screw BSNB05010B NB5X10Bs Tranceiver Assy. MDNZT5023 NZT-2103 10-1 Main Chassis MPBX44420 10-2 Wave Guide Circuit MPAB31606 10-2-1 CIR-Attachment...
  • Page 42 Washers BRTG00883 Corted Bolts BRTG09192 M8X20 SUS304 corted Sealing Washers BRTG06850 SUSW8S1 Hex-Head Setscrew BRTG1030G M4X0.7X6 SUS304 Bolts BRTG09297 M8X25 FE SW W ZMC4RBU Bolts BRTG09296 M6X70 FE SW W ZMC4RBU Cross-recessed Head Screw BSNC04025B NC4X25Bs Bolts BRTG06852 M4X12 SW W SUS304 Bolts BRTG09004 M5X16 SW W SUS304...
  • Page 43 Figure 3.1 Exploded Diagram of the NKE-2103...
  • Page 44: Nke-2254

    3.2.2. NKE-2254 PART NAME PRODUCT CODE SERVICE CODE NOTE Radiator Assy. NAX-16B 9ft/7ft/6ft Bolt BRTG07249 HEX10X35 SUS304 Spring Washer BRTG00404 SW10 Washer MTL315466 Support Assy. MPBX40223 Antenna Support MTC301223A Slide Plate MTT309252 O-Ring BRPK00054 P42 ID41.7 D3.5 Housing Assy. Housing MTC301727 Sleev MTL317432...
  • Page 45 Wave Guide MPAB31207A Encoder Assy. MPEM30202 13-1 Encoder MDMW11068 CHT-71A CHT-71 13-2 Spur Gear MTT006909B 13-3 Click MTD001842 13-4 Plate Encoder Mounting MTB366793A 13-5 Upset Bolt BRTG06852 M4X12 SW W SUS304 Motor Assy. 14-1 Motor MPEM30204 7BDRD0044A CBP-168A 14-2 14-3 Flange for Motor MTC301225 14-4...
  • Page 46 21-19 Nut Plate MTB389894 21-20 MPEM30151 21-21 Cross-Recessed Head Screw BSNC04030B 21-22 Bolt BRTG07502 M5X16 SW W SUS304 21-23 O-Ring BRPK00019 21-24 Bolt BRTG07397 M4X12 SW SUS304 21-25 Cross-recessed Head Screw BRTG05659 NK4X0.7X65Bs Performance Monitor Unit NJU-85 NJU-85 PM Adapter MPBC43041A Neck Heator kit MDMW11067A...
  • Page 47 Figure 3.2 Exploded Diagram of the NKE-2254 3-11...
  • Page 48: Ndc-1460

    3.2.3. NDC-1460 PARTS LIST RADAR PROCESS UNIT NDC-1460/JMA-5200MK2 Fig. DRAWING No. DESCRIPTION NOTE JRC CODE MTZ303979 Nameplate MPNN45149 -1/1 Warning Label MPNN43252 Drip-proof Rubber MPPK30497A Coaching Clip CS-4U BRBP05299 SHINAGAWA-SHOKO Spacer BSB-308E BRBP06402 HIROSUGI Bracket MTB382448 D-sub Cover MTB381018 Label MPNN40470 Panel MPBC40313...
  • Page 49 41 Wing Nut BSBN04000B 42 Washer W4Bs BSFW04000B 43 Spring Washer BSSW04000S MTZ303979 44 Nut N4Bs BSHN04000W -1/1 45 Nut LN4Bs BSLN04000W 46 Sems Screw NC3X8Bs BSNC03008B 47 Sems Screw NC2.6X10Bs BSNC02610B 48 Sems Screw NB3X6Bs BSNB03006B 49 LAN I/F Process Unit CMH-2224 50 Mounting Plate MPBC43241...
  • Page 50 14 Spacer Assy MPBC42659 15 Rear Cover Assy MPBC42660 22 Knob MPHD30389 48 Knob MPHD30390 18 Stopper Screw BRTG00561 KOSHIN 19 Dripproof Ring MPPK30299 20 Rubber Cap MPNG00102 21 Nameplate (Japanese) MPNM35344 22 Key Sheet (Japanese) MPNM35345 23 Cover MPNN37100A 24 Gasket for Trackball MTT305538 25 Drip-proof Rubber 1...
  • Page 51 Connector Fuse nut Connector nut Figure 3.3 Exploded Diagram of the NDC-1460 3-15...
  • Page 52: Nce-7699A

    3.2.4. NCE-7699A DESCRIPTION DRAWING No. NOTE JRC CODE Panel MTV303808 Cover MTV303809 Rubber Key MTV304379A Packing MTV303811 16 Knob MPHD30383 38 Knob MPHD30378 Packing (for speaker) MTZ301931 Packing (for vibrationproof) MTT306943 Speaker Trackball Cover MTV303599 Teflon Ring MTT308975 Trackball Spacer MTT309110 Keyboad Unit CCK-979...
  • Page 53 Figure 3.4 Exploded Diagram of the NCE-7699A 3-17...
  • Page 54 3-18...
  • Page 55 Chapter 4 Replacement of Major Units...
  • Page 57: Scanner Unit

    4.1. Scanner Unit 4.1.1. Precautions for replacing parts in the scanner unit Follow the precautions below to carry out parts replacement without getting injured. Confirm that all the radar equipment (if more than one unit is used) is turned off before you start the parts replacement.
  • Page 58: Parts Replacement For The Scanner Unit Nke-2254

    4.1.2. Parts Replacement for the Scanner Unit NKE-2254 [Required tools] • Tools for removing the cover from the scanner unit A wrench (width across flats 13 mm for M8 bolts) • Tools used in each part replacement procedure [Replacement procedure] Before starting the work, turn off the safety switch at the bottom of the scanner Ship's heading...
  • Page 59: Magnetron Replacement / Nke-2254

    (3) Replace the parts, which need replacement, according to the procedures in the subsequent sections. Be careful not to lose screws or brackets removed during replacement. (4) After the parts replacement, mount the pedestal cover, set the safety switch to ON. (Be sure to cap the safety switch.) The packing shall be clean, free from dust and dirt when you mount the cover.
  • Page 60 Make sure there is no charge remaining Magnetron in the modulation high-voltage circuit board, and then remove the screws (two M4 Remove the screws) holding the magnetron cables four screws. (yellow and green) in place. Remove the screws (four M4 screws) holding the magnetron in place, then replace the magnetron after cutting the Remove the...
  • Page 61: Motor Replacement / Nke-2254

    After transmitting on a long range for about fifteen minutes, return to the service engineer menu and adjust the tuning. Perform the adjustment in the service engineer menu until the tuning display bar on the display unit reaches the eighth calibration mark. With the service engineer menu open, also make sure the magnetron current is shown between the fifth and seventh calibration markings.
  • Page 62 Remove the four hexagon bolts (M8), Remove the and detach the mounting plate from the four bolts. motor. Attach the mounting plate to the new motor. Be sure to tighten all the four Motor hexagon bolts with specified torque (210 kgf˜cm). Mounting plate Install the motor in the scanner unit.
  • Page 63: Motor Drive Circuit Board Replacement / Nke-2254

    4.1.5. Motor drive circuit board replacement / NKE-2254 [Required tools] • A Phillips screwdriver for 4 mm screws • Tools for removing the scanner unit covers (See Section 4.1.2.) [Replacement procedure] (1) Remove the cover from the left (port) side (see Section 4.1.2), disconnect the cables and remove the three screws (M4) from the motor driver circuit, and then detach the...
  • Page 64: Modulator Circuit (Cpa-264) Replacement / Nke-2254

    [Operation check] After completing the replacement work, check the operation by following the procedure below. Turn on the radar, transmit radar signals when the countdown is finished, and check that radar images are displayed normally. There shall be no abnormal noise emitted when the motor starts running, when it is running, or when it stops.
  • Page 65 Loosen the screws (nine M4 screws) Remove the two screws. Loosen the holding the cover in place, remove the nine screws. screws (two M4 screws) holding the heat radiation plate in place, and remove the cover. Remove the cables connected to the Remove the Remove the modulator circuit board, then remove the...
  • Page 66: Power Supply Circuit Board (Cbd-1682A) Replacement / Nke-2254

    4.1.7. Power supply circuit board (CBD-1682A) replacement / NKE-2254 [Required tools] • A Phillips screwdriver for 4 mm screws • A Phillips screwdriver for 5 mm screws • Tools for removing the scanner unit covers (See Section 4.1.2) [Replacement procedure] Remove the cover on the right (starboard) side (see Section 4.1.2), remove the cables Remove the five cables.
  • Page 67: T/R Control Circuit (Cmc-1205R) Replacement / Nke-2254

    Remove the screws (six M4 screws) holding Remove the six screws. the power supply circuit board in place and replace the power supply circuit board. If the square heat radiation sheet on the casing on the back of the power supply circuit board (the soldered side) is damaged, affix a new sheet to the replacement power supply circuit board.
  • Page 68 Remove the cover on the right (starboard) Remove the five cables. side (see Section 4.1.2), remove the cables connected to the transmitter-receiver unit and the screws (three M5 screws) holding the transmitter-receiver unit in place, and remove the transmitter-receiver unit. Remove the three screws.
  • Page 69: Receiver (Nrg-162A) Replacement / Nke-2254

    [Operation check] After having completed the replacement, follow the procedure below to check the operation. Turn on the radar, open the service engineer menu, restore the scanner unit times, and make sure that the data has been correctly continued before/after the T/R control circuit board replacement (check the transmission time and the motor rotation time).
  • Page 70 Remove the screws (five M4 screws) holding the receiver in place and remove Remove the five screws. the cables connected to the receiver, then replace the receiver. Transfer the metal fitting from the removed receiver to the replacement receiver and fit the receiver into the casing.
  • Page 71: Encoder Replacement / Nke-2254

    4.1.10. Encoder replacement / NKE-2254 [Required tools] • A Phillips screwdriver for 4 mm screws • A Phillips screwdriver for 5 mm screws • A wrench (width across flats 7 mm for M4 bolts) • A wrench (width across flats 8 mm for M6 bolts) •...
  • Page 72 Remove the metal fitting and the gear Remove the nut. Metal fitting wheel from the encoder, attach them to the replacement encoder and fit it into the casing. Encoder Remove the three screws. After having replaced the encoder, reassemble the unit by following the disassembly procedure in the reverse order.
  • Page 73: Magnetron Fan Replacement / Nke-2254

    4.1.11. Magnetron fan replacement / NKE-2254 [Required tools] • A Phillips screwdriver for 4 mm screws • A Phillips screwdriver for 5 mm screws • Tools for removing the scanner unit covers (See Section 4.1.2) Remove the cover on the right (starboard) side (see Section 4.1.2), remove the cables Remove the five cables.
  • Page 74: Modulator Fan Replacement / Nke-2254

    Remove the screws (four M4 screws) holding the fan in place and replace the fan. Remove the four screws. After having replaced the fan, reassemble the unit by following the disassembly procedure in the reverse order. Do not forget to tighten the bolts and screws, and do not forget to reconnect the cables.
  • Page 75 (1) Remove the cover on the right (starboard) Remove the five side (see Section 4.1.2), remove the cables cables. connected to the transmitter-receiver unit and the screws (three M5 screws) holding the transmitter-receiver unit in place, and remove the transmitter-receiver unit. Remove the three screws.
  • Page 76 Remove the screws (four M4 screws) Remove the four screws. holding the fan in place and replace the fan. After having replaced the fan, reassemble the unit by following the disassembly procedure in the reverse order. Do not forget to tighten the bolts and screws, and do not forget to reconnect the cables.
  • Page 77: Nke-2103 Scanner Unit Parts Replacement

    4.1.13. NKE-2103 scanner unit parts replacement [Required tools] • Tools for removing the cover from the scanner unit A wrench (width across flats 13 mm for M8 bolts) • Tools used in each part replacement procedure [Replacement procedure] Turn off the safety switch at the bottom of Ship's heading the scanner unit.
  • Page 78: Magnetron Replacement For The Nke-2103

    4.1.14. Magnetron Replacement for the NKE-2103 [Required tools] • A Phillips screwdriver for 4 mm screws • A Phillips screwdriver for 5 mm screws • Tools for removing the scanner unit covers (See Section 4.1.2) [Replacement procedure] Open the top cover (see Section 4.1.2), Slide loosen the four screws (M4), remove the transmitter-receiver unit cover, and disconnect...
  • Page 79 Remove the six screws (M4) that secure Remove the six Nut plate screws. the magnetron, and replace the magnetron. A shielded screwdriver shall be used for magnetron replacement. Touching the magnetron with metal (a tool) causes performance deterioration. Magnetron Cable: Green Cable: Yellow Adjust the lead wires (yellow and green) of the new magnetron to an appropriate length, and tighten the screws to secure the cables.
  • Page 80: Motor Replacement For The Nke-2103

    After long range transmission for about 15 minutes, open the service engineer menu again and perform tuning adjustment. In the service engineer menu, perform adjustment for the tune indicator bar on the display to reach 80%. In the service engineer menu, also confirm that the magnetron current indicator shows 50 to 70%.
  • Page 81: Motor Control Power Circuit Replacement For The Nke-2103

    [Operation check] After completing the replacement work, check the operation by following the procedure below. Turn on the radar, transmit radar signals when the countdown is finished, and check that radar images are displayed normally. There shall be no abnormal noise emitted when the motor starts running, when it is running, or when it stops.
  • Page 82: Modulation Circuit (Cme-363) Replacement For The Nke-2103

    [Operation check] After completing the replacement work, check the operation by following the procedure below. Turn on the radar, transmit radar signals when the countdown is finished, and check that radar images are displayed normally. 4.1.17. Modulation Circuit (CME-363) Replacement for the NKE-2103 [Required tools] •...
  • Page 83: Power Circuit (Cbd-1783) Replacement For The Nke-2103

    [Operation check] After completing the replacement work, check the operation by following the procedure below. Turn on the radar, transmit radar signals when the countdown is finished, and check that radar images are displayed normally. After long range transmission, open the service engineer menu, and confirm that the magnetron current indicator shows 50 to 70%.
  • Page 84: Receiver (Nrg-610) Replacement For The Nke-2103

    Remove the six M4 screws and two M3 Remove the six screws (M4). Remove the two screws, and detach the power circuit from screws (M3). the mounting plate. After the power circuit replacement, carry out the work in reverse order of removal. Be sure to tighten all the bolts and screws and connect all the cables.
  • Page 85 Remove the 3D circuit and receiver from the transmitter-receiver unit according to the procedure below. (a) Remove the M4 screw near the magnetron. Remove the M4 screw. (b) Remove the three screws (M4) from Motor control power circuit the motor control power circuit, and remove the 3D circuit from the chassis.
  • Page 86: Encoder Replacement For The Nke-2103

    After the receiver replacement, carry out the work in reverse order of removal. Be sure to tighten all the bolts and screws and connect all the cables. After receiver replacement, perform the assembly procedure, paying attention to the fitting of the transmitter-receiver unit. If the fitting is poor, loosen the screws and perform the adjustment again.
  • Page 87 Remove the metal fitting and gear wheel Remove the nut. from the old encoder, mount them on the Metal fitting new encoder, and install the encoder in the chassis. Remove the Encoder three screws. After the encoder replacement, carry out the work in reverse order of removal.
  • Page 88: Display System

    4.2. Display System 4.2.1. Brilliance Control Circuit CCK-970 [Notes] Do not directly touch the LCD surface. Do not directly touch the AR filter. To protect the LCD surface and parts, carry out the work on a soft cloth. [Required tools] A Phillips screwdriver for 3 mm screws A hexagonal Allen wrench (1.5 mm) [Removal]...
  • Page 89 (3) Disconnect the cables, remove the two screws, and remove the brilliance control circuit CCK-970 (TCH-002R). (Phillips screwdriver for 3 mm screws) Remove [Mounting] (1) Mount the circuit. (2) Connect the cables, and mount the front panel. (3) Mount the rubber bushing on the shaft of the control. Mounting direction (4) Insert and secure the control, checking how it turns and if you can feel the reaction (clicking) of the control when pressing it.
  • Page 90: Power Supply Unit Nbd-866A

    4.2.2. Power Supply Unit NBD-866A [Note] Before the power supply unit can be replaced, the power connectors of the processor unit must be disconnected. [Required tools] A Phillips screwdriver for 3 mm screws [Removal] (1) Remove the six screws to remove the top cover. (Phillips screwdriver for 3 mm screws) Remove Remove...
  • Page 91 (3) Disconnect the connectors from the power circuit, and remove the power supply unit to replace it. [Mounting] (1) Mount the new power supply unit in reverse order of removal. [Operation check] Check that the equipment starts normally. Transmit radar signals and check that radar images are displayed normally. 4-35...
  • Page 92: Radar Processing Circuit Cdc-1350

    4.2.3. Radar Processing Circuit CDC-1350 [Note] Save necessary setup data onto a memory card before starting the replacement. Take notes of the transmission time and operating time of the scanner unit. [Required tools] A socket wrench for 5.5 mm bolts A Phillips screwdriver for 3 mm screws [Removal] (1) Remove the top cover according to Section 4.2.2.
  • Page 93 (4) Remove the eight hexagonal support posts that secure the radar processing circuit. (Socket wrench for 5.5 mm bolts) Remove Remove (5) Remove the nine screws that secure the radar processing circuit, and replace it. (Phillips screwdriver for 3 mm screws) Remove Remove [Mounting]...
  • Page 94: Battery

    (5) Check that the connected external sensors (e.g., true bearing, ship speed, latitude/longitudinal, and AIS) are displayed normally. 4.2.4. Battery [Notes] (1) If the battery is inserted with the polarities being opposite, remove it immediately. Do not use the battery any more. (2) Do not place the battery on a board or conductive object during the work.
  • Page 95 [Mounting] (1) Check the polarities of the battery. Make sure that the positive polarity is upward. (2) Insert the battery into the battery holder sideways. (3) Check that the battery is fully inserted. [Operation check] (1) Check that the equipment starts normally. (2) Check that an error message is not displayed.
  • Page 96: Target Tracking (Tt) Unit Nca-877A

    4.2.5. Target Tracking (TT) Unit NCA-877A [Required tools] A Phillips screwdriver for 3 mm screws [Removal] (1) Remove the top cover according to Section 4.2.2. (2) The TT circuit can be seen on the radar processing circuit. (3) Remove the four screws that secure the ARPA circuit, and remove the TT circuit lifting it straight up. (Phillips screwdriver for 3 mm screws) Remove Remove...
  • Page 97: Ais Processing Circuit Nqa-2155

    4.2.6. AIS Processing Circuit NQA-2155 [Required tools] A Phillips screwdriver for 3 mm screws [Removal] (1) Remove the top cover according to Section 4.2.2. (2) The AIS processing circuit can be seen on the radar processing circuit. AIS processing circuit (3) The AIS circuit and power circuit are connected with connector-attached cables.
  • Page 98 (4) Remove the four screws that secure the AIS processing circuit, and replace it. (Phillips screwdriver for 3 mm screws) [Mounting] (1) Confirm that the DIP switch and short plug settings are the same between the old and new AIS processing circuits.
  • Page 99: Gyro I/F Circuit Cmj-304E

    4.2.7. GYRO I/F Circuit CMJ-304E [Required tools] A Phillips screwdriver for 3 mm screws [Removal] (1) Remove the four screws that secure the NSK Unit NCT-4106A cover. (Phillips screwdriver for 3 mm screws) (2) Disconnect the gyro/log cables. Remove (3) Detach the connector that is attached to the Remove GYRO•LOG I/F circuit.
  • Page 100 (4) Remove the six screws that secure the GYRO/LOG I/F circuit, and replace it. (Phillips screwdriver for 3 mm screws) [Mounting] (1) Check that the DIP switch settings of the GYRO I/F circuit are correct. Check the GYRO I/F circuit fuses. (2) Assemble the unit in reverse order of removal.
  • Page 101: Gyro I/F Circuit Fuses

    4.2.8. GYRO I/F Circuit Fuses [Required tools] A Phillips screwdriver for 3 mm screws A standard screwdriver for 3 mm screws [Removal] (1) Remove the ten screws (4: upper, 3: right side, and 3: left side) from the processor unit cover, and remove it.
  • Page 102 (4) Take out the fuse and check if it is blown. If it is blown, replace it. (5) Similarly, check the three other fuses. [Mounting] (1) Assemble the unit in reverse order of removal. (2) Start the equipment, and set the true bearing value. [Operation check] (1) Check that an error message is not displayed.
  • Page 103: Operation Circuit Cck-979 For The Standard Operation Unit

    4.2.9. Operation Circuit CCK-979 for the Standard Operation Unit [Required tools] A hexagonal Allen wrench (1.5 mm) A Phillips screwdriver for 3 mm screws [Removal] (1) Loosen the slotted-head screws that secure the six controls, and remove the controls. (Hexagonal Allen wrench: 1.5 mm) Remove (2) Remove the seven setscrews, and open the rear cover.
  • Page 104 (4) Remove the 20 setscrews, and remove the front cover. (Phillips screwdriver for 3 mm screws) (5) Peel off the key rubber, disconnect the connector, and replace the board. Peel off Remove [Mounting] (1) Assemble the operation unit in reverse order of removal. When mounting the front cover, make sure that the keys on the key rubber fit snugly into the corresponding holes in the front cover.
  • Page 105: Ps2 Connector Circuit Cqc-1204 For The Standard Operation Unit

    4.2.10. PS2 Connector Circuit CQC-1204 for the Standard Operation Unit [Required tools] A Phillips screwdriver for 3 mm screws [Removal] (1) Remove the seven setscrews, and open Remove the rear cover. (Phillips screwdriver for 3 mm screws) Remove (2) Disconnect the two connectors, and remove the rear cover.
  • Page 106 [Mounting] (1) Assemble the unit in reverse order of removal. [Operation check] (1) Check that the equipment starts normally. (2) Check that an error message is not displayed. (3) Perform a key test, buzzer test, and light test according to Section 8.3.1.3 of the instruction manual, and check that no abnormality is detected.
  • Page 107: Trackball Trd-101S(Bk)N1 For The Standard Operation Unit

    4.2.11. Trackball TRD-101S(BK)N1 for the Standard Operation Unit [Required tools] A Phillips screwdriver for 3 mm screws [Removal] (1) Remove the seven setscrews, and open Remove the rear cover. (Phillips screwdriver for 3 mm screws) Remove (2) Disconnect the connector from the trackball, and replace the trackball.
  • Page 108 4-52...
  • Page 109: Chapter 5_Program Update

    Chapter 5 Program Update...
  • Page 111: Main Program Update Procedure

    5.1. Main Program Update Procedure 5.1.1. Items to be Provided • Compact flash card • PC card adapter for compact flash cards • New electronic program file (File name: 5200MK2prg.bin) 5.1.2. Update Procedure Copy the new electronic program file into the root directory on the compact flash card.
  • Page 112: Ais Processing Circuit Update Procedure

    5.2. AIS Processing Circuit Update Procedure 5.2.1. Items to be Provided • Compact flash card • PC card adapter for compact flash cards • New electronic program file (File name: AIS5200MK2prg_V****.bin) (**** indicates the program version.) 5.2.2. Update Procedure Copy the new electronic program file for AIS processing circuit into the root directory on the compact flash card.
  • Page 113: How To Check The Version

    5.3. How to Check the Version Select "Main Menu" - "1. RADAR Menu" - "8. RADAR Sub Menu" - "9. Test Menu" - "6. System INFO." Move the cursor onto the "Exit" button, and press the CLR/INFO key on the keyboard five times.
  • Page 115: Chapter 6_Troubleshooting

    Chapter 6 Troubleshooting...
  • Page 117: Operation Check

    Perform operation checks on the radar equipment at regular intervals, and if any abnormality is detected, immediately start inspection on the abnormality. In particular, be careful of the high voltages during operation checks, and caution should be taken to avoid incorrect or carelessness measurement which can cause trouble.
  • Page 118: Self-Diagnostic Function (Self Test)

    6.1.1. Self-diagnostic Function (Self Test) This function checks the memory, scanner unit, and communication lines. 1. Memory Test 1. Display-system internal memory check 2. TXRX Test 2. Scanner unit check 3. Line Test 3. Communication line check Display-system internal memory check (Memory Test) Checks the internal memory operating conditions.
  • Page 119: Display Unit Check (Monitor Test)

    Communication line check (Line Test) Checks the status of communication with optional equipment, external navigators, or the likes. TXRX Check on connection with the scanner unit Check on connection with the NSK (NCT-4106A) unit Compass Check on connection with equipment on the compass port COM1 Check on connection with the COM1 port...
  • Page 120: Operation Unit Check (Keyboard Test)

    6.1.3. Operation Unit Check (Keyboard Test) This function checks the controls and switches on the operation panel. 1. Key Test 1. Key check 2. Buzzer Test 2. Buzzer check 3. Light 3. Operation panel light check Key check (Key Test) Checks the controls and switches on the operation panel.
  • Page 121: Performance Monitor (Mon Display)

    6.1.4. Performance Monitor (MON Display) This function displays the performance monitor status. * Transmitter System Check on the attenuation of the transmitter system Attenuation Value * Receiver System Check on the attenuation of the receiver system MON Pattern Range Attenuation Value Note: When checking the attenuation of the transmitter system, read the value one minute after you open this menu.
  • Page 122: System Information Display (System Info)

    6.1.6. System Information Display (System INFO) This function displays system information such as the hours of using the magnetron, the program versions, etc. * Indicator Ver.**.** Display system program version * TXRX Ver.**.** Scanner program version * System No. No.**.** Display system number * TXRX Time Transmit *** hrs...
  • Page 123: Error Message Lists

    6.2. Error Message Lists 6.2.1. Error Messages for the Scanner Unit TXRX(SSW Off) Description This message indicates that the safety switch on the scanner unit is OFF. Transmission is not allowed when the safety switch is OFF. Location of cause o Procedure x Set the safety switch to ON.
  • Page 124 TXRX(Reverse) Description In circumstances where the antenna is subjected to "external force due to strong wind (equivalent to wind speed 51.5 m/s) that exceeds the capacity for driving the scanner, the scanner unit enters the protection mode and does not drive the motor. If the motor is reversed by strong wind under such circumstances, this error message is displayed.
  • Page 125 TXRX(Video) Description This message indicates that the radar video signal from the scanner is faulty. If TXRX(MHV) or TXRX(Heater) is displayed, handle the error first. Since this message is displayed even when the transmitter is not operating, first check the magnetron current on the test menu of the display system, and check if the transmission function is normal.
  • Page 126 TXRX(Fan1) TXRX(Fan2) Description These messages indicate that the fan in the scanner unit is faulty. Location of cause o Procedure x Check the insertion of P1113 and J1114 on the CMC-1205R. B103 and B104 in the x Replace the B103 and B104. scanner unit TXRX(Motor) Description...
  • Page 127 TXRX(AZI) Description This message indicates that a rotation signal is not output from the scanner. If the message is displayed, the radar forcibly stops transmission. A rotation signal may not be output when the motor is stopped. First check that the motor is running. If the driving system is protected from strong wind, the motor is stopped, and the error message may be displayed.
  • Page 128 TXRX(HL) Description This message indicates that a reference position signal is not output from the scanner. If the message is displayed, the radar forcibly stops transmission. A reference position signal may not be output when the motor is stopped. First check that the motor is running. If the motor is not running, the motor, the relay circuit CSC-656, an equipment cable, or the power terminal board circuit in the display system may be faulty.
  • Page 129 TXRX(Data) Description This message indicates that communication between the display system and scammer is faulty. If the message is displayed, radar transmission is not permitted. The communication error is caused by either of the following: • Cable fault between the display system and scanner unit •...
  • Page 130: Error Messages For The Display System

    6.2.2. Error Messages for the Display System Keyboard(Data) Keyboard2(Data) Description These messages indicate that communication with the operation unit is faulty. Keyboard(Data) indicates the communication status of the main operation unit; Keyboard 2(Data) indicates the communication status of the sub-operation unit. The operation unit may be faulty, an operation unit cable may be broken, the power terminal board circuit in the display system may be faulty, or the radar processing circuit may be faulty.
  • Page 131 PROC(Trigger) Description This message indicates that the trigger signal from the scanner is faulty. If TXRX(Trigger) or TXRX(Data) is displayed, handle the error first. A scanner equipment cable may be broken, the power terminal board circuit in the display system may be faulty, or the radar processing circuit may be faulty.
  • Page 132 PROC(HL) Description This message indicates that the reference position signal from the scanner is faulty. If TXRX(HL) or TXRX(Data) is displayed, handle the error first. A scanner equipment cable may be broken, the power terminal board circuit in the display system may be faulty, or the radar processing circuit may be faulty.
  • Page 133 PROC(INT) Description This message indicates that the processing reference pulse signal in the radar processing circuit is faulty. If TXRX(Trigger), TXRX(Data), or PROC(Trigger) is displayed, handle the error first. A scanner equipment cable may be broken, the power terminal board circuit in the display system may be faulty, or the radar processing circuit may be faulty.
  • Page 134 ASIC1 to RADAR Description This message indicates that the signal to the DSP circuit from the radar processing circuit in the display system is faulty. In general, the DSP circuit is not installed, so the message is not to be displayed. RADAR to ASIC2 Description This message indicates that the signal to the radar processing circuit from the DSP circuit in the...
  • Page 135: Error Messages For The External Input-Output Equipment

    NSK(Time Out) Description This message indicates that the communication signals of the NSK unit connected to the display system and the radar processing circuit are faulty. If the message is displayed, the true bearing value cannot be displayed. The NSK unit, the power terminal board circuit in the display system, or the radar processing circuit may be faulty.
  • Page 136 Heading(Time Out), Heading(Data) Description These messages indicate that true bearing data cannot be recognized by the radar processing circuit in the display system. If either of the messages is displayed, the true bearing value cannot be displayed. The input-output unit or the radar processing circuit may be faulty. The baud rate of the serial port for Heading may not be correct.
  • Page 137 Position(Data) Description This message indicates that position data cannot be recognized by the radar processing circuit in the display system. If the message is displayed, latitudes and longitudes cannot be displayed. The power terminal board circuit in the display system or the radar processing circuit may be faulty.
  • Page 138 GPS(Data) Description This message indicates that date data cannot be recognized by the radar processing circuit in the display system. If the message is displayed, the automatic time correction function cannot be used. The power terminal board circuit in the display system or the radar processing circuit may be faulty.
  • Page 139 2AXW(Time Out), 2AXW(Data), 2AXG(Time Out), 2AXG(Data) Description These messages indicate that the serial log signal is faulty if 2AXG 2AXW is selected as the ship speed information to be used. If any of the messages is displayed, the ship speed cannot be displayed. The power terminal board circuit in the display system or the radar processing circuit may be faulty.
  • Page 140 AIS(Time Out), AIS(Data) Description These messages indicate that AIS data cannot be recognized by the AIS processing circuit in the display system. If either of the messages is displayed, AIS information cannot be displayed. The power terminal board circuit in the display system, the AIS processing circuit, or the radar processing circuit may be faulty.
  • Page 141 Depth(Time Out), Depth(Data) Description If water depth data is received from a serial port, these messages indicate that the serial data is abnormal. If either of the messages is displayed, water depth data cannot be displayed. The power terminal board circuit in the display system or the radar processing circuit may be faulty.
  • Page 142 Temperature(Time Out), Temperature(Data) Description If water temperature data is received from a serial port, these messages indicate that the serial data is abnormal. If either of the messages is displayed, water temperature data cannot be displayed. The power terminal board circuit in the display system or the radar processing circuit may be faulty.
  • Page 143 Wind(Time Out), Wind(Data) Description If wind direction/speed data is received from a serial port, these messages indicate that the serial data is abnormal. If either of the messages is displayed, wind direction/speed data cannot be displayed. The power terminal board circuit in the display system or the radar processing circuit may be faulty.
  • Page 144 Current(Time Out), Current(Data) Description If tidal current data is received from a serial port, these messages indicate that the serial data is abnormal. If either of the messages is displayed, tidal current data cannot be displayed. The power terminal board circuit in the display system or the radar processing circuit may be faulty.
  • Page 145 Rate of Turn(Time Out), Rate of Turn(Data) Description If turning speed data (Rate of Turn) is received from a serial port, these messages indicate that the serial data is abnormal. If either of the messages is displayed, ROT cannot be displayed. The power terminal board circuit in the display system or the radar processing circuit may be faulty.
  • Page 146 Rudder(Time Out), Rudder(Data) Description If rudder angle sensor data is received from a serial port, these messages indicate that the serial data is abnormal. If either of the messages is displayed, the rudder angle cannot be displayed. The power terminal board circuit in the display system or the radar processing circuit may be faulty.
  • Page 147: Examples Of Trouble

    6.3. Examples of Trouble 6.3.1. Internal Circuits The radar display flickers on and off Description The radar is operating normally, but the radar display appears and disappears at intervals. Location of cause o Procedure Connection A connector may not be connected correctly. Check the connection of the RGB connector (J7) and LCD power connector (J6).
  • Page 148 Lines you have not entered are displayed. Description Lines you have not entered are shown on the radar display. Location of cause o Procedure They may be PI (parallel index) lines. Check that PI display is off. The MOB key may have been pressed. Hold down the MOB key to see if the condition is improved.
  • Page 149: External Equipment

    6.3.2. External Equipment Connection cannot be established with external equipment for NMEA output. Description The following may cause this trouble: connection polarity, baud rate setting, setting for using external navigator, or output-equipment fan failure. Location of cause o Procedure Polarity If the connection is correct, the output is LOW at the time of no signal when viewed with the negative side as reference on the oscilloscope.
  • Page 150 6-34...
  • Page 151: Chapter 7_Drawings

    Chapter 7 Drawings...
  • Page 153: Outline Drawings

    Outline Drawing of the Rectifier NBA-5111 (Option) Figure 7.10 Overall System Diagram of the Radar JMA-5222-7/9 Figure 7.11 Overall System Diagram of the Radar JMA-5212-4/6/4HS/6HS Figure 7.12 Inter-Unit Connection Diagram of the JMA-5222-7/9 Figure 7.13 Inter-Unit Connection Diagram of the JMA-5212-4/6/4HS/6HS Figure 7.14 Internal Connection Diagram of the Scanner Unit NKE-2254...
  • Page 154: Outline Drawing Of The Scanner Unit Nke-2254-7

    7.1.1. Outline Drawing of the Scanner Unit NKE-2254-7 Outline Drawing of the Scanner Unit NKE-2254-7 Figure 7.1...
  • Page 155: Outline Drawing Of The Scanner Unit Nke-2254-9

    7.1.2. Outline Drawing of the Scanner Unit NKE-2254-9 Outline Drawing of the Scanner Unit NKE-2254-9 Figure 7.2...
  • Page 156: Outline Drawing Of The Scanner Unit Nke-2103-4/4Hs

    7.1.3. Outline Drawing of the Scanner Unit NKE-2103-4/4HS Outline Drawing of the Scanner Unit NKE-2103-4/4HS Figure 7.3...
  • Page 157: Outline Drawing Of The Scanner Unit Nke-2103-6/6Hs

    7.1.4. Outline Drawing of the Scanner Unit NKE-2103-6/6HS Outline Drawing of the Scanner Unit NKE-2103-6/6HS Figure 7.4...
  • Page 158: Outline Drawing Of The Display System Ndc-1460

    7.1.5. Outline Drawing of the Display System NDC-1460 Outline Drawing of the Display System NDC-1460 Figure 7.5...
  • Page 159: Outline Drawing Of The Display Unit Nwz-164

    7.1.6. Outline Drawing of the Display Unit NWZ-164 Outline Drawing of the Display Unit NWZ-164 Figure 7.6 DISPLAY AREA...
  • Page 160: Outline Drawing Of The Operation Unit Nce-7699A

    7.1.7. Outline Drawing of the Operation Unit NCE-7699A Outline Drawing of the Operation Unit NCE-7699A Figure 7.7...
  • Page 161: Outline Drawing Of The Multi-Function Operation Unit Nce-7729A

    7.1.8. Outline Drawing of the Multi-function Operation Unit NCE-7729A Outline Drawing of the Multi-function Operation Unit NCE-7729A Figure 7.8...
  • Page 162: Outline Drawing Of The Rectifier Nba-5111 (Option)

    7.1.9. Outline Drawing of the Rectifier NBA-5111 (Option) Outline Drawing of the Rectifier NBA-5111 (Option) Figure 7.9 7-10...
  • Page 163: System Diagrams

    7.2. System Diagrams 7.2.1. Overall System Diagram of the Radar JMA-5222-7/9 Overall System Diagram of the Radar JMA-5222-7/9 Figure 7.10 7-11...
  • Page 164: Overall System Diagram Of The Radar Jma-5212-4/6/4Hs/6Hs

    7.2.2. Overall System Diagram of the Radar JMA-5212-4/6/4HS/6HS Overall System Diagram of the Radar JMA-5212-4/6/4HS/6HS Figure 7.11 7-12...
  • Page 165: Inter-Unit Connection Diagram

    7.3. Inter-Unit Connection Diagram 7.3.1. Inter-Unit Connection Diagram of the JMA-5222-7/9 Inter-Unit Connection Diagram of the JMA-5222-7/9 Figure 7.12 7-13...
  • Page 166: Inter-Unit Connection Diagram Of The Jma-5212-4/6/4Hs/6Hs

    7.3.2. Inter-Unit Connection Diagram of the JMA-5212-4/6/4HS/6HS Inter-Unit Connection Diagram of the JMA-5212-4/6/4HS/6HS Figure 7.13 7-14...
  • Page 167: Unit Internal Connection Diagrams

    7.4. Unit Internal Connection Diagrams 7.4.1. Internal Connection Diagram of the Scanner Unit NKE-2254 Internal Connection Diagram of the Scanner Unit NKE-2254 Figure 7.14 7-15...
  • Page 168: Internal Connection Diagram Of The Scanner Unit Nke-2103

    7.4.2. Internal Connection Diagram of the Scanner Unit NKE-2103 Internal Connection Diagram of the Scanner Unit NKE-2103 Figure 7.15 7-16...
  • Page 169: Internal Connection Diagram Of The Processor Unit Ndc-1460

    7.4.3. Internal Connection Diagram of the Processor Unit NDC-1460 Internal Connection Diagram of the Processor Unit NDC-1460 Figure 7.16 7-17...
  • Page 172 For further information,contact: Not use the asbestos '6/ Printed in Japan...

Table of Contents
