Administrator's Guide for the VSX Series

Configuring Camera Settings and Video Quality Options

4 - 2
The Cameras and Video Quality screens let you specify camera and video
settings, as appropriate for the equipment you are using.
To configure camera and video settings:
1. Go to System > Admin Settings > Cameras.
2. Configure these settings:
Setting Description
Far Control of Specifies whether the far site can control the position of the
Near Camera near-site camera. When this option is selected, a user at the
far site can control the framing and angle of the camera for
VSX 5000
the best view of the near site.
VSX 6000
VSX 7000
VSX 7000s
VSX 7000e
VSX 8000
Backlight Specifies whether to have the camera automatically adjust
Compensation for a light background. Backlight compensation is best used
in situations where the subject appears darker than the
background.
Camera Specifies how much light is let into the camera's iris. A low
Brightness number allows in less light; a high number allows in more
light.
VSX 3000
VSX 5000
Primary Camera Specifies which camera is the main camera.
Camera Direction Specifies the direction the camera moves when using the
arrow buttons on the remote control.
VSX 5000
VSX 6000
VSX 7000
VSX 7000s
VSX 7000e
VSX 8000
Power Specifies the frequency of the electrical power used for the
Frequency camera.
VSX 3000 •
VSX 5000
•
VCR/DVD Audio Allows you to record a call using one VCR or DVD, while
Out Always On playing recorded content into the call from a second VCR or
DVD.
VSX 7000s
VSX 7000e Do not select this setting if you have only one VCR or DVD
VSX 8000 player connected.
50 Hz—Select if you have a PAL system.
60 Hz—Select if you have an NTSC system.
