2. Specifications

2.1.

Core System

Embedded 9
CPU
Intel® Core™ i7-9700TE Processor, 8C, 1.8/3.8GHz, 12M, 35W
Intel® Core™ i7-9700E Processor, 8C, 2.6/4.4GHz, 12M, 65W
Intel® Core™ i5-9500TE Processor, 6C, 2.2/3.6GHz, 9M, 35W
Intel® Core™ i5-9500E Processor, 6C, 3.0/4.2GHz, 9M, 65W
Intel® Core™ i3-9100E Processor, 4C, 3.1/3.7GHz, 6M, 65W
Intel® Core™ i3-9100TE Processor, 4C, 2.2/3.2GHz, 6M, 35W
Embedded 8
Intel® Core™ i7-8700 Processor, 6C, 3.2/4.6GHz, 12M, 65W
Intel® Core™ i7-8700T Processor, 6C, 2.4/4.0GHz, 12M, 35W
Intel® Core™ i5-8500 Processor, 6C, 3.0/4.1GHz, 9M, 65W
Intel® Core™ i5-8500T Processor, 6C, 2.1/3.5GHz, 9M, 35W
Intel® Core™ i3-8100 Processor, 4C, 3.6GHz, 6M, 65W
Intel® Core™ i3-8100T Processor, 4C, 3.1GHz, 6M, 35W
Intel® Pentium® Gold G5400 Processor, 2C, 3.7GHz, 4M, 58W
Intel® Pentium® Gold G5400T Processor, 2C, 3.1GHz, 4M, 35W
Intel® Celeron® G4900 Processor, 2C, 3.1GHz, 2M, 54W
Intel® Celeron® G4900T Processor, 2C, 2.9GHz, 2M, 35W
Note:
Chipset
Intel® Q370/H310 Chipset
Memory
Dual-channel non-ECC 2400 MHz DDR4 memory up to 32GB in dual SODIMM sockets
Embedded BIOS
AMI EFI in 16MB SPI BIOS
2.2.

Rear I/O Connectors

Display
3x DisplayPort (Q370) , 2x DisplayPort (H310)
LAN
Dual GbE RJ-45
USB
4x USB 3.0;
Audio
7.1 channel audio via 5 jacks and S/PDIF output on rear I/O
2.3.

Debug Connector

40-pin Multipurpose Flat Cable Connector: used in combination with DB-40 debug module providing BIOS
POST code LED, BMC access, SPI BIOS flashing, Power Testpoints, Debug LEDs
Specifications
th
Gen. Intel® Core™ i7/i5/i3 and Pentium®/Celeron® Processor, LGA1151 socket
Gen. Intel® Core™ i7/i5/i3 and Pentium®/Celeron® Processor, LGA1151 socket
th
The availability of features may vary between processor SKUs and operating systems.
4x USB 2.0
AmITX-CF-G
3
