Rear LED Displays
Three sets of LEDs are displayed on the rear of the Sun IB switch.
the meaning of each LED.

Rear Display LEDs for the Sun Nine-Port InfiniBand Switch

TABLE 1-2
Location
IB ports
RJ-45/Ethernet link status
Rear status
FIGURE 1-2
FIGURE 1-2
Color Meaning if Lit
Green Operational/Link up
Amber Fault—port requires attention
Green Operational
Amber Status/Fault
White
Green Operational
Amber Status/Fault
Rear status LEDs
Sun Nine-Port Infiniband Switch Showing Rear LEDs
shows the location of the LEDs.
Meaning if Blinking
Traffic activity
Locate function started
Port LEDs
describes
TABLE 1-2
Link LEDs
