A P P E N D I X

Specifications

This appendix provides the technical specifications for the Sun IB switch. It contains
the following sections:
"Interface Signals" on page 73
■
"Switch Architecture" on page 74
■
"System Management" on page 75
■
"High Availability" on page 75
■
"LED Descriptions" on page 76
■
"Power Requirements" on page 76
■
"Environmental Specifications" on page 77
■

Interface Signals

TABLE B-1
TABLE B-1
RJ-45 Pin
1
2
3
4
5
6
7
8
lists the RJ-45-to-DB-25 RS-232 pinouts.

Pin Descriptions for the RJ-45-to-DB-25 Serial Converter Cable

Signal
RTS
DTR
TXD
GND
GND
RXD
NC
CTS
DB-25 RS-232 Pin Signal
5 CTS
6 DSR
3 RXD
7 GND
7 GND
2 TXD
20 DTR
4 RTS
73
