Front Panel LED Displays
Two sets of LEDs are displayed on the front panel of the Sun IB switch.
describes the meaning of each LED.

Front Panel LEDs for the Sun Nine-Port InfiniBand Switch

TABLE 1-1
Location
Front panel status
PSU and fan module
Front panel status LEDs
FIGURE 1-1
2 Sun IB Switch 9P Administration Guide • October 2006
Color Meaning if Lit
White
Green Switch is up and running
Amber Switch requires attention
Green AC on
Green DC on
Amber Fault—the PSU requires attention
Blue Ready-to-remove
PSU and fan module LEDs
Front Panel LEDs
shows the location of the LEDs.
FIGURE 1-1
TABLE 1-1
Meaning if Blinking
Locate function started
