iPF6400
a
Printhead Fixer Cover
Holds the Printhead in place. Do not open this part except during Printhead replacement.
b
Printhead
The printhead is equipped with ink nozzles. It serves a key role in printing.
c
Printhead Fixer Lever
Locks the Printhead Fixer Cover. Do not open this part except during Printhead replacement.
Ink Tank Cover (Inside)
Ink Tank Cover (Inside)
a
Ink Tank
Cartridges of ink in various colors.
User's Guide
Ink Tank Cover (Inside)
669
