iPF6400
Perform cleaning as follows.
1
On the Tab Selection screen of the Control Panel, press ◀ or ▶ to se-
lect the Settings/Adj. tab (
If the Tab Selection screen is not displayed, press the Menu button.
Note
2
Press the OK button.
The Set./Adj. Menu is displayed.
3
Press ▲ or ▼ to select Maintenance, and then press the OK button.
4
Press ▲ or ▼ to select Head Cleaning, and then press the OK button.
5
Press ▲ or ▼ to select Head Cleaning A or Head Cleaning B, and then press the OK button.
Head cleaning is now executed.
6
Print a test pattern to check the nozzles, and determine whether cleaning has cleared the nozzles. (See
"Checking for Nozzle Clogging.")

Replacing the Printhead

Replacing the Printhead
When to replace the Printhead
This printer is equipped with two printheads.
Replace one or both printheads in the following situations.
If the printing quality does not improve even after one or two cycles of Head Cleaning B from the printer menu
Replace any printheads with poor printing performance.
If the Display Screen indicates "Open top cover and replace the left printhead."
Replace the Printhead on the left side.
If the Display Screen indicates "Open top cover and replace the right printhead."
Replace the Printhead on the right side.
If your Canon dealer has advised Printhead replacement
Replace the Printhead as directed.
Compatible printheads
For information on compatible printheads, see "Printhead."
Precautions when handling the Printhead
Take the following precautions when handling the Printhead.
For safety, keep the Printhead out of the reach of children.
If ink is accidentally ingested, contact a physician immediately.
Caution
Do not touch the Printhead immediately after printing. The Printhead becomes extremely hot, and there is a risk of burns.
User's Guide
).
→P.845
→P.845
Replacing the Printhead
847
