[1] Slant adjusting lever
This lever is used to fine adjust slant of rules lines.
[2] Printhead
The printhead has nozzles. It is an important component used to perform printing.
[3] Printhead fixer lever
This lever is used to lock the printhead fixer cover.
[4] Printhead fixer cover
This cover is used to secure the printhead.

1.5.6 Ink Tank Cover (Inside)

iPF650 / iPF655
[4] [1]
[3] [2]
F-1-22
Chapter 1
0023-1268
1-15
