iPF6400
You can select the interval of the variation in adjustment values between neighboring adjustment pattern im-
ages from the range of 1 to 10. The larger the value, the greater the differences between the states of the
adjustment pattern images. Note that if the adjustment item is Tone, the Adjustment Value Spacing cannot
be selected.
• (Swap) button
Rearranges the adjustment pattern with the Horizontal Axis and Vertical Axis adjustment items swapped.
• Rotate 90 degrees
Rotating the image may make it easier to conserve paper and compare images.
Select Per Image to rotate each of the images in the adjustment pattern by 90 degrees.
Select Entire Image after layout to rotate the entire adjustment pattern by 90 degrees.
When None is selected, the image is not rotated.
• Pattern Size
You can specify the size of the image when printing the adjustment pattern.
When Auto is selected, the image is enlarged or reduced to fit the adjustment pattern into the Use Paper Size.
When Dimensions is selected, the image is printed at the input image size without enlarging or reducing. Dimen-
sions cannot be selected when the paper feed method is Manual.
•
If the input image size is large, check the Paper Size before starting printing because it may be larger than the actual
printed material size.
Note
•
Select Dimensions in Pattern Size to print at the input image size without enlarging or reducing the images.
•
Patterns that extend past the horizontal width of the paper are printed wrapped onto the next line.
• Pattern Spacing
You can select None or Available. If Available is selected, you can insert a background between each image.
The background color can be specified in Pattern Background.
• Pattern Background
You can select the background color from White, Black, and Gray.
If it is difficult to compare the differences between neighboring adjustment pattern images, changing the back-
ground color may make it easier to compare. The Pattern Spacing can be selected if Pattern Background is
Available.
• Update Base Values in the Color Settings Sheet
Select this check box and click the Close button to apply the setting values (standard values) of the image en-
closed in the blue frame in the center of the preview area in the Color Settings sheet (color or monochrome).
• Print Conditions
Displays the paper type, print mode, and output profile configured in the main window. This makes it possible to
check the details of each of the settings when printing the adjustment pattern without returning to the main win-
dow.
