Preferences Dialog Box

Preferences Dialog Box

This dialog box appears when you select Preferences from the imagePROGRAF Advanced Preview menu. You can
set the preferences for Free Layout.
• Units
Set the unit for paper length, margins, and so on.
• Gridlines
You can input a grid line width value in numerical characters so that they serve as a guide to laying out objects.
•
You can input between 10.0 and 200.0(mm) (between 0.39 and 7.87(inch)).
•
You can change the numbers by clicking either ▲ button or ▼ button.
Note
• Divisions
You can change the number of divisions of grid lines so that they serve as a guide to laying out objects.
•
You can input between 1 and 10.
•
You can change the numbers by clicking either ▲ button or ▼ button.
Note
• Grid Color
Select the grid line color.
• Print Object Frames
You can print the object border.
•
If you do not want to print the object border, deselect the Print Object Frames check box.
Note
• Object Frame Style
You can select the object frame style for printing.
The following settings are available for the object frame style.
Setting
Solid Line
Dotted Line
Dashed Line
User's Guide
You can print the solid line as the frame style.
You can print the dotted line as the frame style.
You can print the dashed line as the frame style.
Preferences Dialog Box (Mac OS X)
Details
433
