iPF6400
This function is not available with CAD Tracing Paper, CAD Translucent Matte Film, or CAD Clear Film.
Important
If adjustment is not possible as expected using special media, try another type of paper, or try Manual adjustment.
(See "Manual Adjustment to Straighten Lines and Colors.")
Because the results of adjustment vary depending on the type of paper used for adjustment, use the same type of paper as
you will use for printing.
Note
If Standard does not improve printing, try adjusting the printhead manually.
(See "Manual Adjustment to Straighten Lines and Colors.")
If the printhead position was not adjusted during initial setup or when the printhead was replaced, execute Initial adjustmt.
(See "Adjustment When Installing the Printhead.")
Advanced adjustment can enable superior printing quality when printing fine lines or text at high precision on glossy or semi-
glossy photo or proofing paper.
(See "Enhancing Printing Quality.")
Items to Prepare
When Using Rolls
An unused roll at least 254.0 mm (10.00 in) wide
When Using Sheets
Standard : Six sheets of unused paper, A4/Letter size (or one sheet when using A2)
Simple : One sheet of unused paper, A4/Letter size
Perform adjustment as follows.
1
Load paper.
Loading Rolls on the Roll Holder
Loading Rolls in the Printer
Loading Sheets in the Feed Slot
Always make sure the loaded paper matches the type of paper specified on the printer. Adjustment cannot be com-
pleted correctly unless the loaded paper matches the settings.
Important
2
On the Tab Selection screen of the Control Panel, press ◀ or ▶ to se-
lect the Settings/Adj. tab (
If the Tab Selection screen is not displayed, press the Menu button.
Note
3
Press the OK button.
The Set./Adj. Menu is displayed.
User's Guide
→P.732
→P.732
→P.734
→P.728
→P.531
→P.534
→P.554
).
Automatic Adjustment to Straighten Lines and Colors
731
