iPF6400
Setting
Print Area Layout
Roll Paper Preview
Print Selected Range
Place a checkmark here to only print the selected range.
When you select Preview in the Image, then select a portion of the image on the preview display, this becomes valid.
Note
Perform Proof in Preview
Place a checkmark here to simulate the colors of the output product in the preview.
If Auto (Color) is selected under Output Profile, some media types are enabled.
If ICC profile is selected under Output Profile, this is always enabled.
Note
The actual color balance of the print product and the simulation product may differ with some environments and condi-
tions. In addition, when you have selected an ICC Profile with Output Profile and it is not compatible with the printer or
media that you are using, the color balance of the actual print product will differ.
Image Properties button
When you click the button to open the Image Properties dialog box, where Image Size, Resolution, Bit and
Color Space information of the image imported to Print Plug-In are displayed.
Click the Close button to return to Print Plug-In for Photoshop/Digital Photo Professional.
User's Guide
*You can change the image print position when you drag the image while the cursor is displayed
as
.
The entire image is displayed.
*You can select the print range when you drag the image while the cursor is displayed as
*When you click the image while the cursor is displayed as
Display the media size and roll paper information on the top in the layout printing on roll paper.
*To select Roll Paper Preview, select Roll Paper in Paper Source.
Details
, the selected area is deselected.
Preview Area
.
261
