Replacing the Printhead
There may be ink around the nozzles of the Printhead you remove. Handle the Printhead carefully during replacement. The
ink may stain clothing.
Important
Do not open the Printhead pouch until immediately before installation. After removing the Printhead from the pouch, install it
right away. If the Printhead is left after the pouch is opened, the nozzles may dry out, which may affect printing quality.
Access the menu for Printhead replacement
When replacing the Printhead immediately after printing, wait a few minutes before replacing it. The metal parts of the Print-
head become hot during printing, and there is a risk of burns from touching these parts.
Caution
Your hands may become dirty during Printhead replacement. Use the gloves provided with the new Printhead for replace-
ment.
Important
Prepare a new Ink Tank when ink levels are low.
Note
When the remaining capacity of Maintenance cartridge is low, prepare a new Maintenance cartridge.
1
Remove any paper that has been advanced by selecting Eject Paper in the Control Panel menu.
When using a roll, rewind it.
(See "Removing the Roll from the Printer.")
When using sheets, remove the sheet.
(See "Removing Sheets.")
2
Clean inside the Top Cover. (See "Cleaning Inside the Top Cover.")
3
On the Tab Selection screen of the Control Panel, press ◀ or ▶ to se-
lect the Settings/Adj. tab (
Note
4
Press the OK button.
The Set./Adj. Menu is displayed.
5
Press ▲ or ▼ to select Maintenance, and then press the OK button.
6
Press ▲ or ▼ to select Replace P.head, and then press the OK button.
7
Press ▲ or ▼ to select the Printhead for replacement.
Select Printhead L when replacing the left printhead and Printhead R when replacing the right printhead.
Make sure your selection is correct.
8
Press the OK button.
848
The ink begins to be drawn in, and instructions appear on the Display Screen after this has finished.
It takes about three minutes for the ink to be drawn in.
→P.560
).
If the Tab Selection screen is not displayed, press the Menu button.
→P.538
→P.861
