Chapter 1: SP601 Evaluation Board

Features

The SP601 board provides the following features:
•
•
•
•
•
•
•
•
•
•
•
•
•
•
10
1. Spartan-6 XC6SLX16-2CSG324 FPGA
2. 128 MB DDR2 Component Memory
3. SPI x4 Flash
4. Linear Flash BPI
5. 10/100/1000 Tri-Speed Ethernet PHY
7. IIC Bus
♦
8Kb NV memory
♦
External access 2-pin header
♦
VITA 57.1 FMC-LPC connector
8. Clock Generation
♦
Oscillator (Differential)
♦
Oscillator Socket (Single-Ended, 2.5V or 3.3V)
SMA Connectors (Differential)
9. VITA 57.1 FMC-LPC Connector
10. Status LEDs
♦
FPGA_AWAKE
♦
INIT
♦
DONE
13. User I/O
♦
User LEDs
♦
User DIP switch
♦
User pushbuttons
♦
GPIO male pin header
14. FPGA_PROG_B Pushbutton Switch
Configuration Options
♦
3. SPI x4 Flash (both onboard and off-board)
♦
4. Linear Flash BPI
♦
JTAG Configuration
Power Management - AC Adapter and 5V Input Power
Supplies
