SP601 Evaluation Board

Overview

The SP601 board enables hardware and software developers to create or evaluate designs
targeting the Spartan®-6 XC6SLX16-2CSG324 FPGA.
The SP601 provides board features for evaluating the Spartan-6 family that are common to
most entry-level development environments. Some commonly used features include a
DDR2 memory controller, a parallel linear flash, a tri-mode Ethernet PHY, general-
purpose I/O (GPIO), and a UART. Additional functionality can be added through the
VITA 57.1.1 expansion connector.
board features with details provided in

Additional Information

Additional information and support material is located at:
•
This information includes:
•
•
•
•
•
•
•
•
•
For information about the Spartan-6 family of FPGA devices, including product
highlights, data sheets, user guides, and application notes, see the Spartan-6 FPGA website
at http://www.xilinx.com/support/documentation/spartan-6.htm.
SP601 Hardware User Guide
UG518 (v1.1) August 19, 2009
http://www.xilinx.com/sp601
Current version of this user guide in PDF format
Example design files for demonstration of Spartan-6 FPGA features and technology
Demonstration hardware and software configuration files for the SP601 linear and SPI
memory devices
Reference Design Files
Schematics in PDF format and DxDesigner schematic format
Bill of materials (BOM)
Printed-circuit board (PCB) layout in Allegro PCB format
Gerber files for the PCB (Many free or shareware Gerber file viewers are available on
the internet for viewing and printing these files.)
Additional documentation, errata, frequently asked questions, and the latest news
