Table 1-13: LPC Pinout
K J H
1 NC NC VREF_A_M2C
2 NC NC PRSNT_M2C_L
3 NC NC GND
4 NC NC CLK0_M2C_P
5 NC NC CLK0_M2C_N
6 NC NC GND
7 NC NC LA02_P
8 NC NC LA02_N
9 NC NC GND
10 NC NC LA04_P
11 NC NC LA04_N
12 NC NC GND
13 NC NC LA07_P
14 NC NC LA07_N
15 NC NC GND
16 NC NC LA11_P
17 NC NC LA11_N
18 NC NC GND
19 NC NC LA15_P
20 NC NC LA15_N
21 NC NC GND
22 NC NC LA19_P
23 NC NC LA19_N
24 NC NC GND
25 NC NC LA21_P
26 NC NC LA21_N
27 NC NC GND
28 NC NC LA24_P
29 NC NC LA24_N
30 NC NC GND
31 NC NC LA28_P
32 NC NC LA28_N
33 NC NC GND
SP601 Hardware User Guide
UG518 (v1.1) August 19, 2009
G F E
GND NC NC
CLK1_M2C_P NC NC
CLK1_M2C_N NC NC
GND NC NC
GND NC NC
LA00_P_CC NC NC
LA00_N_CC NC NC
GND NC NC
LA03_P NC NC
LA03_N NC NC
GND NC NC
LA08_P NC NC
LA08_N NC NC
GND NC NC
LA12_P NC NC
LA12_N NC NC
GND NC NC
LA16_P NC NC
LA16_N NC NC
GND NC NC
LA20_P NC NC
LA20_N NC NC
GND NC NC
LA22_P NC NC
LA22_N NC NC
GND NC NC
LA25_P NC NC
LA25_N NC NC
GND NC NC
LA29_P NC NC
LA29_N NC NC
GND NC NC
LA31_P NC NC
www.xilinx.com
D
PG_C2M
GND DP0_C2M_P
GND DP0_C2M_N
GBTCLK0_M2C_P
GBTCLK0_M2C_N
GND DP0_M2C_P
GND DP0_M2C_N
LA01_P_CC
LA01_N_CC
GND LA06_P
LA05_P LA06_N
LA05_N
GND
LA09_P LA10_P
LA09_N LA10_N
GND
LA13_P
LA13_N LA14_P
GND LA14_N
LA17_P_CC
LA17_N_CC
GND LA18_P_CC
LA23_P LA18_N_CC
LA23_N
GND
LA26_P LA27_P
LA26_N LA27_N
GND
TCK
TDI
TDO
3P3VAUX
TMS
Detailed Description
C B A
GND NC NC
NC NC
NC NC
GND NC NC
GND NC NC
NC NC
NC NC
GND NC NC
GND NC NC
NC NC
NC NC
GND NC NC
GND NC NC
NC NC
NC NC
GND NC NC
GND NC NC
NC NC
NC NC
GND NC NC
GND NC NC
NC NC
NC NC
GND NC NC
GND NC NC
NC NC
NC NC
GND NC NC
GND NC NC
SCL NC NC
SDA NC NC
GND NC NC
GND NC NC
