SP601 Master UCF
The UCF template is provided for designs that target the SP601. Net names provided in the
constraints below correlate with net names on the SP601 rev. C schematic. On identifying
the appropriate pins, the net names below should be replaced with net names in the user
RTL. See the
SP601 Hardware User Guide
UG518 (v1.1) August 19, 2009
Constraints Guide
NET "CPU_RESET"
NET "DDR2_A0"
NET "DDR2_A1"
NET "DDR2_A2"
NET "DDR2_A3"
NET "DDR2_A4"
NET "DDR2_A5"
NET "DDR2_A6"
NET "DDR2_A7"
NET "DDR2_A8"
NET "DDR2_A9"
NET "DDR2_A10"
NET "DDR2_A11"
NET "DDR2_A12"
NET "DDR2_BA0"
NET "DDR2_BA1"
NET "DDR2_BA2"
NET "DDR2_CAS_B"
NET "DDR2_CKE"
NET "DDR2_CLK_N"
NET "DDR2_CLK_P"
NET "DDR2_DQ0"
NET "DDR2_DQ1"
NET "DDR2_DQ2"
NET "DDR2_DQ3"
NET "DDR2_DQ4"
NET "DDR2_DQ5"
NET "DDR2_DQ6"
NET "DDR2_DQ7"
NET "DDR2_DQ8"
NET "DDR2_DQ9"
NET "DDR2_DQ10"
NET "DDR2_DQ11"
NET "DDR2_DQ12"
NET "DDR2_DQ13"
NET "DDR2_DQ14"
NET "DDR2_DQ15"
NET "DDR2_LDM"
NET "DDR2_LDQS_N"
www.xilinx.com
for more information.
LOC = "N4";
LOC = "J7";
LOC = "J6";
LOC = "H5";
LOC = "L7";
LOC = "F3";
LOC = "H4";
LOC = "H3";
LOC = "H6";
LOC = "D2";
LOC = "D1";
LOC = "F4";
LOC = "D3";
LOC = "G6";
LOC = "F2";
LOC = "F1";
LOC = "E1";
LOC = "K5";
LOC = "H7";
LOC = "G1";
LOC = "G3";
LOC = "L2";
LOC = "L1";
LOC = "K2";
LOC = "K1";
LOC = "H2";
LOC = "H1";
LOC = "J3";
LOC = "J1";
LOC = "M3";
LOC = "M1";
LOC = "N2";
LOC = "N1";
LOC = "T2";
LOC = "T1";
LOC = "U2";
LOC = "U1";
LOC = "K3";
LOC = "L3";
