Table 1-7: BPI Memory Connections (Cont'd)
SP601 Hardware User Guide
UG518 (v1.1) August 19, 2009
FPGA U1 Pin
H16 FLASH_A6
H15 FLASH_A7
H14 FLASH_A8
H13 FLASH_A9
F18 FLASH_A10
F17 FLASH_A11
K13 FLASH_A12
K12 FLASH_A13
E18 FLASH_A14
E16 FLASH_A15
G13 FLASH_A16
H12 FLASH_A17
D18 FLASH_A18
D17 FLASH_A19
G14 FLASH_A20
F14 FLASH_A21
C18 FLASH_A22
C17 FLASH_A23
F16 FLASH_A24
R13 FPGA_D0_DIN_MISO_MISO1
T14 FPGA_D1_MISO2
V14 FPGA_D2_MISO3
U5 FLASH_D3
V5 FLASH_D4
R3 FLASH_D5
T3 FLASH_D6
R5 FLASH_D7
M16 FLASH_WE_B
L18 FLASH_OE_B
www.xilinx.com
Schematic Netname
Detailed Description
BPI Memory U10
Pin Number Pin
23 A6
22 A7
20 A8
19 A9
18 A10
17 A11
13 A12
12 A13
11 A14
10 A15
8 A16
7 A17
6 A18
5 A19
4 A20
3 A21
1 A22
30 A23
56 A24
33 DQ0
35 DQ1
38 DQ2
40 DQ3
44 DQ4
46 DQ5
49 DQ6
51 DQ7
55 WE_B
54 OE_B
