Xilinx SP601 User Manual page 31

X-Ref Target - Figure 1-18
SP601 Hardware User Guide
UG518 (v1.1) August 19, 2009
NET "FMC_CLK0_M2C_N"
NET "FMC_CLK0_M2C_P"
NET "FMC_CLK1_M2C_N"
NET "FMC_CLK1_M2C_P"
NET "FMC_LA00_CC_N"
NET "FMC_LA00_CC_P"
NET "FMC_LA01_CC_N"
NET "FMC_LA01_CC_P"
NET "FMC_LA02_N"
NET "FMC_LA02_P"
NET "FMC_LA03_N"
NET "FMC_LA03_P"
NET "FMC_LA04_N"
NET "FMC_LA04_P"
NET "FMC_LA05_N"
NET "FMC_LA05_P"
NET "FMC_LA06_N"
NET "FMC_LA06_P"
NET "FMC_LA07_N"
NET "FMC_LA07_P"
NET "FMC_LA08_N"
NET "FMC_LA08_P"
NET "FMC_LA09_N"
NET "FMC_LA09_P"
NET "FMC_LA10_N"
NET "FMC_LA10_P"
NET "FMC_LA11_N"
NET "FMC_LA11_P"
NET "FMC_LA12_N"
NET "FMC_LA12_P"
NET "FMC_LA13_N"
NET "FMC_LA13_P"
NET "FMC_LA14_N"
NET "FMC_LA14_P"
NET "FMC_LA15_N"
NET "FMC_LA15_P"
NET "FMC_LA16_N"
NET "FMC_LA16_P"
NET "FMC_LA17_CC_N"
NET "FMC_LA17_CC_P"
NET "FMC_LA18_CC_N"
NET "FMC_LA18_CC_P"
NET "FMC_LA19_N"
NET "FMC_LA19_P"
NET "FMC_LA20_N"
NET "FMC_LA20_P"
NET "FMC_LA21_N"
NET "FMC_LA21_P"
NET "FMC_LA22_N"
NET "FMC_LA22_P"
NET "FMC_LA23_N"
NET "FMC_LA23_P"
NET "FMC_LA24_N"
NET "FMC_LA24_P"
NET "FMC_LA25_N"
NET "FMC_LA25_P"
NET "FMC_LA26_N"
NET "FMC_LA26_P"
NET "FMC_LA27_N"
NET "FMC_LA27_P"
NET "FMC_LA28_N"
NET "FMC_LA28_P"
NET "FMC_LA29_N"
NET "FMC_LA29_P"
NET "FMC_LA30_N"
NET "FMC_LA30_P"
NET "FMC_LA31_N"
NET "FMC_LA31_P"
NET "FMC_LA32_N"
NET "FMC_LA32_P"
NET "FMC_LA33_N"
NET "FMC_LA33_P"
NET "FMC_PRSNT_M2C_L"
NET "FMC_PWR_GOOD_FLASH_RST_B"
Figure 1-18: UCF Location Constraints for VITA 57.1 FMC-LPC Connections
www.xilinx.com
LOC = "A10";
LOC = "C10";
LOC = "V9";
LOC = "T9";
LOC = "C9";
LOC = "D9";
LOC = "C11";
LOC = "D11";
LOC = "A15";
LOC = "C15";
LOC = "A13";
LOC = "C13";
LOC = "A16";
LOC = "B16";
LOC = "A14";
LOC = "B14";
LOC = "C12";
LOC = "D12";
LOC = "E8";
LOC = "E7";
LOC = "E11";
LOC = "F11";
LOC = "F10";
LOC = "G11";
LOC = "C8";
LOC = "D8";
LOC = "A12";
LOC = "B12";
LOC = "C6";
LOC = "D6";
LOC = "A11";
LOC = "B11";
LOC = "A2";
LOC = "B2";
LOC = "F9";
LOC = "G9";
LOC = "A7";
LOC = "C7";
LOC = "T8";
LOC = "R8";
LOC = "T10";
LOC = "R10";
LOC = "P7";
LOC = "N6";
LOC = "P8";
LOC = "N7";
LOC = "V4";
LOC = "T4";
LOC = "T7";
LOC = "R7";
LOC = "P6";
LOC = "N5";
LOC = "V8";
LOC = "U8";
LOC = "N11";
LOC = "M11";
LOC = "V7";
LOC = "U7";
LOC = "T11";
LOC = "R11";
LOC = "V11";
LOC = "U11";
LOC = "N8";
LOC = "M8";
LOC = "V12";
LOC = "T12";
LOC = "V6";
LOC = "T6";
LOC = "V15";
LOC = "U15";
LOC = "N9";
LOC = "M10";
LOC = "U13";
LOC = "B3";
Detailed Description
31
