Chapter 1: SP601 Evaluation Board

14. FPGA_PROG_B Pushbutton Switch

The SP601 provides one dedicated, active low FPGA_PROG_B pushbutton switch, as
shown in
X-Ref Target - Figure 1-28
Table 1-21: FPGA_PROG_B Pushbutton Switch Connections
X-Ref Target - Figure 1-29

Power Management

AC Adapter and 5V Input Power Jack/Switch

The SP601 is powered from a 5V source that is connected through a 2.1mm x 5.5mm type
plug (center positive). SP601 power can be turned on or off through a board mounted slide
switch. When the switch is in the on position, a green LED (DS15) is illuminated.

Onboard Power Supplies

The diagram in
handling on each supply. The typical operating currents are significantly below the
maximum capable. The board is normally shipped with a 15W power supply, which
should be sufficient for most applications.
40
Figure 1-28.
FPGA PROG B
Figure 1-28: FPGA_PROG_B Pushbutton Switch Topology
FPGA U1 Pin Schematic Netname
V2 FPGA_PROG_B
NET "FPGA_PROG_B" LOC = "V2";
Figure 1-29: UCF Location Constraints for BPI Flash Connections
Figure 1-30 shows the power supply architecture and maximum current
www.xilinx.com
VCC2V5
1
R24
4.7K
5%
2
1/16W
Pushbutton
1
P1 P4
2
P2
SW3
4
3
UG518_28_070809
SW3 Pin
1
SP601 Hardware User Guide
UG518 (v1.1) August 19, 2009
