Default Jumper and Switch Settings
Table B-1
Table B-1: Default Jumper and Switch Settings
SP601 Hardware User Guide
UG518 (v1.1) August 19, 2009
shows the default jumper and switch settings for the SP601.
REFDES Type/Function
SW1 SLIDE, POWER ON-OFF
SW2 DIP, 2-POLE, MODE
1 M0
2 M1
SW8 DIP, 4-POLE, GPIO
1
2
3
4
J4 HDR_1X3, JTAG BYPASS
J14 HDR_1X2, SUSPEND
J15 HDR_1X2, SPI SELECT
www.xilinx.com
Appendix B
Default
OFF
ON (1)
OFF (0)
OFF
OFF
OFF
OFF
JUMP 1-2 (EXCLUDE FMC)
OPEN (0 = AWAKE)
ON (U17 SPI MEM SELECTED)
