Xilinx SP601 User Manual page 52

Appendix D: SP601 Master UCF
52
NET "DDR2_LDQS_P"
NET "DDR2_ODT"
NET "DDR2_RAS_B"
NET "DDR2_UDM"
NET "DDR2_UDQS_N"
NET "DDR2_UDQS_P"
NET "DDR2_WE_B"
NET "FLASH_A0"
NET "FLASH_A1"
NET "FLASH_A2"
NET "FLASH_A3"
NET "FLASH_A4"
NET "FLASH_A5"
NET "FLASH_A6"
NET "FLASH_A7"
NET "FLASH_A8"
NET "FLASH_A9"
NET "FLASH_A10"
NET "FLASH_A11"
NET "FLASH_A12"
NET "FLASH_A13"
NET "FLASH_A14"
NET "FLASH_A15"
NET "FLASH_A16"
NET "FLASH_A17"
NET "FLASH_A18"
NET "FLASH_A19"
NET "FLASH_A20"
NET "FLASH_A21"
NET "FLASH_A22"
NET "FLASH_A23"
NET "FLASH_A24"
NET "FLASH_CE_B"
NET "FLASH_D3"
NET "FLASH_D4"
NET "FLASH_D5"
NET "FLASH_D6"
NET "FLASH_D7"
NET "FLASH_OE_B"
NET "FLASH_WE_B"
NET "FMC_CLK0_M2C_N"
NET "FMC_CLK0_M2C_P"
NET "FMC_CLK1_M2C_N"
NET "FMC_CLK1_M2C_P"
NET "FMC_LA00_CC_N"
NET "FMC_LA00_CC_P"
NET "FMC_LA01_CC_N"
NET "FMC_LA01_CC_P"
NET "FMC_LA02_N"
NET "FMC_LA02_P"
NET "FMC_LA03_N"
NET "FMC_LA03_P"
NET "FMC_LA04_N"
NET "FMC_LA04_P"
NET "FMC_LA05_N"
NET "FMC_LA05_P"
NET "FMC_LA06_N"
NET "FMC_LA06_P"
NET "FMC_LA07_N"
www.xilinx.com
LOC = "L4";
LOC = "K6";
LOC = "L5";
LOC = "K4";
LOC = "P1";
LOC = "P2";
LOC = "E3";
LOC = "K18";
LOC = "K17";
LOC = "J18";
LOC = "J16";
LOC = "G18";
LOC = "G16";
LOC = "H16";
LOC = "H15";
LOC = "H14";
LOC = "H13";
LOC = "F18";
LOC = "F17";
LOC = "K13";
LOC = "K12";
LOC = "E18";
LOC = "E16";
LOC = "G13";
LOC = "H12";
LOC = "D18";
LOC = "D17";
LOC = "G14";
LOC = "F14";
LOC = "C18";
LOC = "C17";
LOC = "F16";
LOC = "L17";
LOC = "U5";
LOC = "V5";
LOC = "R3";
LOC = "T3";
LOC = "R5";
LOC = "L18";
LOC = "M16";
LOC = "A10";
LOC = "C10";
LOC = "V9";
LOC = "T9";
LOC = "C9";
LOC = "D9";
LOC = "C11";
LOC = "D11";
LOC = "A15";
LOC = "C15";
LOC = "A13";
LOC = "C13";
LOC = "A16";
LOC = "B16";
LOC = "A14";
LOC = "B14";
LOC = "C12";
LOC = "D12";
LOC = "E8";
SP601 Hardware User Guide
UG518 (v1.1) August 19, 2009
