B Specifications

This section provides the VLS node, Fibre Channel switch, Ethernet switch, and disk array enclosures
specifications.

VLS9000 Node

Item
Height
Depth
Width
Weight (fully loaded
Weight (no drives installed)
Rated input voltage
Rated input frequency
Rated input current
Rated input power
BTUs per hour
Rated steady-state power
SATA hard drive
Power supply
DVD-CD drive
Memory
Processor

VLS9000 series Disk Array Enclosure

Item
Dimensions
Specification
4.3 cm (1.70 in)
69.2 cm (27.3 in)
42.6 cm (16.8 in)
17.9 kg (39.5 lb)
14.1 kg (31.0 lb)
100 VAC to 240 VAC
50 Hz to 60 Hz
7.1 A (120 VAC); 3.5 A (240 VAC)
852 W
2910 (120 VAC); 2870 (240 VAC)
700 W
60 GB capacity
7,200 rpm rotational speed
700 W
8x/24x IDE
4 x 1024 MB DDR2 SRAM ECC
Pentium® quad-core Xeon™ processor (2.0 GHz)
Specification
59.7 x 44.7 x 8.8 cm (23.5 x 17.6 x 3.5 in)
