Fibre Channel Switch 4/16Q - HP StorageWorks 9000 - Virtual Library System User Manual

Item
Media transmission ranges
Cable types
Fabric latency
Fabric point-to-point bandwidth
Fabric aggregate bandwidth
Maximum frame sizes
Per-port buffering
Management processor
Management methods
Access methods
Diagnostics
Fabric services
Voltage
Current
Power
Frequency

Fibre Channel Switch 4/16q

Item
Dimensions
Specification
Optical
• Shortwave: 500 m (1,640 ft.)
• Longwave: 10 km (6.2 mi.)
50/62.5 micron multimode fiber optic
9 micron single-mode fiber optic
• Less than 0.4 μs (best case, no contention)
• Cut-through routing
848 MB/s Full Duplex per port
• Single chassis: Over 80 Gb/s (full duplex) end-to-end
• Non-blocking architecture
2148 bytes (2112 byte payload)
• ASIC-embedded memory (non-shared)
• Each port has a guaranteed 8-credit zero wait state buffer for
full performance up to 10km
Pentium class
SNMP, Telnet, GS-3
• In-band
• Ethernet 10/100 BaseT with RJ45
• Power-up self-test of all functionality except media modules
• Field-selectable full self-test including media modules
• Simple name server
• Fabric zoning
• Registered State Change Notification (RSCN)
• I/O StreamGuard™
90/265 VAC
20 VA
25 W maximum (with full optics configuration)
47/63 Hz
Specification
17 x 20 x 1.70 in. (43.2 x 50.8 x 4.32 cm) 1U height
HP StorageWorks 297
