Mounting A Disk Array Enclosure Into A Rack - HP StorageWorks 9000 - Virtual Library System User Manual

Item Description
2 array 3, expansion disk array 1
3 array 3, expansion disk array 0
4 array 3, base disk array
5 array 2, expansion disk array 2
6 array 2, expansion disk array 1
7 array 2, expansion disk array 0
8 array 2, base disk array

Mounting a Disk Array Enclosure into a Rack

WARNING!
The disk array weighs 33.6 kg (74 lb) full. At least two people are required to lift, move,
and install the disk array.
If only one person is to perform the installation, remove the power modules and hard drives from a
disk array enclosure before installing it, and if possible position it on top of another device or shelf
in the rack to hold it as you attach all the brackets.
CAUTION:
When positioning a disk array enclosure in the rack, ensure the air vents at the front and back of the
enclosure are not blocked.
52 Hardware Installation
Item Description
10 array 1, expansion disk array 1
11 array 1, expansion disk array 0
12 array 1, base disk array
13 array 0, expansion disk array 2
14 array 0, expansion disk array 1
15 array 0, expansion disk array 0
16 array 0, base disk array
