11. Select Add Availability Windows.
This takes you to a new screen. See
Figure 33 Adding policy windows to a new LAN/WAN replication target
.
12. In the Add Availability Window section of the screen, select the day and enter the time the
replication process should begin.
13. Enter the allowable duration of the replication jobs in hours and minutes.
Replication jobs can only begin during the availability window. When the availability window
ends, any replication jobs currently in progress will continue until they complete. No replication
jobs can begin until the next availability window opens.
14. Select Add.
The window refreshes, and the availability window you just added is moved to the Current
Availability Windows section of the screen.
Repeat steps 12 through 14 for as many availability windows as you need.
15. Select Submit.
The screen returns to the selected library's list of LAN/WAN replication targets.
16. Assign the LAN/WAN replication target to the source library. See
"Managing a LAN/WAN Replication
NOTE:
When you configure a virtual library as a LAN/WAN replication target with Echo Copy, you may
also need to hide it (e.g., using LUN masking or port mapping/zoning) from the front-end SAN in
the case where the same backup application instance sees both the source and destination VLS devices.
(The backup application must not see the same tape barcode in two places at the same time.) See
"LUN Mapping

Viewing the Replication Target Slot Details

On the navigation pane, select Slots from the expanded replication target list to view the replication
target slots. The screen displays the barcode and last successful echo copy for each slot.
(v3.x)" on page 161 for details.
Figure 33.
Library" on page 86.
HP StorageWorks 117
