Item Description
1 VLS9000-series disk arrays
2 VLS9000-series Ethernet switch or connectivity kit (32-port kit shown)
3 VLS9000-series nodes
Figure 7 VLS9000-series two-rack configuration
.
The VLS9000-series is a scalable storage solution. For more information on VLS9000-series
configuration options, see
Whether you are installing one rack or multiple racks of VLS9000-series equipment, the rack mounting
order is essentially the same. See
Use the following information to understand rack mounting VLS9000-series equipment:
• Depending on the configuration, a VLS9000 series device requires between one and four racks.
If available, install racks two through four next to the first rack. See
30 Hardware Installation
VLS9000-series Components.
Figure 7 and Installing the VLS Node into a Rack.
Figure 8.
