Saving Configuration Settings - HP StorageWorks 9000 - Virtual Library System User Manual

Saving Configuration Settings

NOTE:
The VLS firmware ensures a persistent VLS serial number and Fibre Channel port WWPNs, so that
in the event of any hardware failure and replacement (such as the system board or Fibre Channel
host bus adapter card), the VLS still appears exactly the same to the external SAN. It does this by
generating a VLS serial number and Fibre Channel port WWPNs at first boot, which are based on
the system board's MAC address. The VLS serial number and Fibre Channel port WWPNs are saved
on the VLS hard drives and with the virtual library configuration settings in the configuration file.
HP highly recommends that you save your virtual library configuration and the VLS network settings
to an external configuration file, so they can be restored in the event of a disaster.
To save your virtual library configuration and the VLS network settings to an external configuration
file:
1. Open a Command View VLS session and log in as the administrator. See
"Opening a Command View VLS Session from a Web
2. Select Chassis in the navigation tree.
3. Click Save Config under Maintenance Tasks.
The Save Configuration window opens.
4. Right-click Download Configuration Files.
5. Select Save Target As.
A zip file is displayed in the File name box.
6. Click Save, wait for the file to finish downloading, and then click Close.
The Save Configuration window re-opens.
7. Click Finish.
NOTE:
Optionally, you can set the device to automatically save and E-mail the configuration file at midnight
after the configuration is modified. See
Browser" on page 143.
"Edit the Email Settings" on page 194.
HP StorageWorks 189
