2 Hardware Installation

This section details the steps to install the VLS hardware from installation preparation to final cabling.

Preparing for the Installation

Tools for Installation

• Two people
• #1 and #2 Phillips screwdriver
• Standard screwdriver
• Allen wrench (provided; used with 6-mm screws and #12-24 x 3/8-inch sockethead screws)
• #3 Pozidrive screwdriver
• 7/16 inch wrench
• Box cutting knife
CAUTION:
Do not use any power tools. They could strip or damage connections.

Taking ESD Precautions

To prevent damaging the system, be aware of the precautions you need to follow when setting up
the system or handling parts. A discharge of static electricity from a finger or other conductor may
damage system boards or other static-sensitive devices. This type of damage may reduce the life
expectancy of the device.
To prevent electrostatic damage:
• Avoid hand contact by transporting and storing products in static-safe containers.
• Keep electrostatic-sensitive parts in their containers until they arrive at static-free workstations.
• Place parts on a grounded surface before removing them from their containers.
• Avoid touching pins, leads, or circuitry.
• Always be properly grounded when touching a static-sensitive component or assembly.

Grounding Methods to Prevent Electrostatic Discharge

Several methods are used for grounding. Use one or more of the following methods when handling
or installing electrostatic-sensitive parts:
• Use a wrist strap connected by a ground cord to a grounded workstation or computer chassis.
Wrist straps are flexible straps with a minimum of 1 megaohm ±10 percent resistance in the
ground cords. To provide proper ground, wear the strap snug against the skin.
