11. Install the new switch onto the racking shelf and then mount the racking shelf in the rack. See
Installing Fibre Channel Switches 4/10q onto Racking Shelf
4/10q or
12. Reconnect all cables to the new switch exactly as they were connected to the failed switch.
13. Re-install the 1U cover plate for the racking shelf to the front of the rack.
14. Power on the new switch.

Fibre Channel Switch 4/16q Replacement

To replace a Fibre Channel Switch 4/10q:
1. Power off the switch.
2. Make a note of all cable connections to the switch then disconnect the cables.
3. Remove the 1U cover plate for the switch from the front of the rack.
4. Remove the four bolts from the rail flanges on the rear rack uprights using a #2 Phillips screwdriver.
5. Loosen the two nuts securing the rail ends to the adjustable mounting flanges, which are mounted
on the front rack uprights, using a 7/16 inch wrench.
6. Slide the switch out the rear of the rack.
CAUTION:
Make sure the switch is supported below, either by equipment mounted in the next rack slot
or with your hand, before sliding the switch off the adjustable mounting flanges that support
it.
7. Disconnect the AC power cables from the back of the switch.
8. Remove the rack rails from the switch.
9. Install the rack rails on the new switch and then mount the switch in the rack. See
to Fibre Channel Switches 4/16q
10. Reconnect all cables to the new switch exactly as they were connected to the failed switch.
11. Re-install the 1U cover plate for the switch to the front of the rack.
12. Power on the new switch.

Fibre Channel Transceiver Replacement

To replace a Fibre Channel transceiver
1. Power off the system. See
266 Component Replacement
4/16q.
and
Powering Off the
and
Racking Fibre Channel Switches 4/10q or
System.
Racking Fibre Channel Switches
Attaching Rails
4/16q.
