StorageWorkS | JaNUarY 2009 ProDUCt Book EVA4400 SAN Starter Kits New EVA4400 Starter Kits with dual integrated 10-port 8Gbps SAN switches and FC HBAs D2D Backup Systems New D2D4000 & D2D2500 with integrated data deduplication RDX Backup System New RDX Removable Disk Backup System with pluggable disk cartridges 8Gbps SAN Switches New B-series 8Gbps SAN Switches...
B-series (Brocade) Director-class Switches ... 67 C-series (CISCo) SaN Switches ... 68 C-series (CISCo) Director-class Switches ... 69 8/20q (Qlogic) SaN Switch ... 70 SaN Switches for HP BladeSystem c-Class ...71 Fibre Channel over IP gateways (SaN over WaN) ... 72...
SCSI or SaS interface (SaS available on Dat 160-only). all drives have a 3-year, next-business-day, product exchange warranty (with 9x5 phone support) and include HP Data Protector express Single Server edition software and its Bare Metal Disaster recovery option, providing a backup application to protect a single Windows, Linux or NetWare server.
Page 5
USB 2.0 for plug-and-play installation; SCSI or SaS interface (SaS available on Dat 160-only). all drives have a 3-year, next-business-day, product exchange warranty (with 9x5 phone support) and include HP Data Protector express Single Server edition software and its Bare Metal Disaster recovery option, providing a backup application to protect a single Windows, Linux or NetWare server.
LTO Ultrium Tape Drive half-height models Lto Ultrium is HP’s premier line of tape backup devices. each drive includes backup software (HP Data Protector express Single Server edition with Bare Metal Disaster recovery option), built-in hardware compression and a 3 year warranty.
Page 7
LTO Ultrium Tape Drive half-height models Lto Ultrium is HP’s premier line of tape backup devices. each drive includes backup software (HP Data Protector express Single Server edition with Bare Metal Disaster recovery option), built-in hardware compression and a 3 year warranty.
SaS or SCSI connectivity. HP Lto Ultrium tape drives employ dynamic data rate matching to adjust to the speed of the host, reducing wear and tear on both drive and media and increasing performance, even on slower hosts. HP’s ultra-durable soft-load feature automatically positions the data cartridge and combined with the highly reliable HP leader-capture mechanism ensures trouble free tape handling.
LTO Ultrium Tape Blade for c-Class BladeSystem the HP StorageWorks tape Blades are half-height tape blades providing an integrated data protection solution for BladeSystem c-Class enclosures. these tape blades provide direct backup of the adjacent server blade and network backup capability for all data residing within the enclosure.
DAT Autoloader the HP StorageWorks Dat 72x10 tape autoloader is an ideal backup solution for the small to medium size company with limited It support or a remote site of larger organizations. By reducing administrative tasks, the Dat 72x10 tape autoloader not only simplifies the backup process, but reduces the risk of error as well.
3 Years 4H 24x7 onsite Hardware Support H5526E 3 Years 4H 13x5 onsite Hardware Support go to www.hp.com/go/lookuptool, select ‘Country’ and enter the product number for other Care Pack options. StaNDarD WarraNtY IS 3 YearS NeXt BUSINeSS DaY oNSIte HarDWare SUPPort CLICK’N’GO FOR MORE: Information on tape autoloaders: www.hp.com/go/tape...
MSL2024 Tape Library the HP StorageWorks MSL2024 tape Library combines two 12-slot magazines with an integrated barcode reader in a compact 2U form factor. the MSL2024 supports up to two half-height Lto Ultrium tape drives or one full-height Lto Ultrium tape drive and is available with a choice of Lto-2, -3 and -4 Ultrium tape drives using SCSI, SaS or Fibre Channel (full height models only) connectivity.
Page 13
HP StorageWorks MSL2024 tape Library combines two 12-slot magazines with an integrated bar- code reader in a compact 2U form factor. the MSL2024 supports up to two half-height Lto Ultrium tape drives or one full-height Lto Ultrium tape drive and is available with a choice of Lto-2, -3 and -4 Ultrium What’s included...
MSL4048 Tape Library the HP StorageWorks MSL4048 tape Library combines four 12-slot magazines with an integrated barcode reader in a compact 4U form factor. the MSL4048 supports up to four half-height Lto Ultrium tape drives or up to two full-height Lto Ultrium tape drive and is available with a choice of Lto3 or Lto4 Ultrium tape drives using SCSI, SaS or Fibre Channel (full-height models only) connectivity.
Page 15
HP StorageWorks MSL4048 tape Library combines four 12-slot magazines with an integrated barcode reader in a compact 4U form factor. the MSL4048 supports up to four half-height Lto Ultrium tape drives or up to twofull-height Lto Ultrium tape drive and is available with a choice of Lto3 or Lto4 Ultrium tape drives using SCSI, SaS or Fibre Channel (full-height models only) connectivity.
MSL8096 Tape Library the HP StorageWorks MSL8096 tape Library combines eight 12-slot magazines with an integrated barcode reader in a compact 8U form factor. the MSL8096 supports up to four Lto3 & Lto4 half-height or full-height Ultrium tape drives with a choice of SCSI, SaS or Fibre Channel (full-height models only) connectivity.
Page 17
HP StorageWorks MSL8096 tape Library combines eight 12-slot magazines with an integrated barcode reader in a compact 8U form factor. the MSL8096 supports up to four Lto3 & Lto4 half-height or full-height Ultrium tape drives with a choice of SCSI, SaS or Fibre Channel (full-height models only) connectivity.
MSL6030 and MSL6026 Tape Libraries the HP StorageWorks MSL6000 series of tape Libraries allows for multi-unit stacking to support a growing backup infrastructure with up to 16 drives and 240 slots. available with a choice of SDLt, Lto3 and Lto4 tape drives, SCSI or SaN attached.
MSL6060 and MSL6052 Tape Libraries the HP StorageWorks MSL6000 series of tape Libraries allows for multi-unit stacking to support a growing backup infrastructure with up to 16 drives and 240 slots. available with a choice of SDLt, MSL6060 LTO3 Generation...
16 tape drives and capacity up to 505 slots. the eML e-Series is ideally suited for medium to large data centers and as a companion for the HP StorageWorks enterprise Virtual array (eVa) family. Based on the HP StorageWorks extended tape Library architecture (etLa), controllers between the SaN and the tape drives regulate traffic and help to ensure that rogue I/o requests do not interrupt the backup or recovery job in progress.
A. the products on this page are Configure-to-order (Cto). Customers may create sample configurations with list pricing using the HP enterprise Configurator available at www.hp.com/products/configurator. HP Business Partners may configure solutions using Sales Builder for Windows (SBW) available from Partner online. Please contact your HP or HP Business Partner account manager for a full configuration with pricing quotation.
RDX Backup System the HP StorageWorks rDX removable Disk Backup System is an easy to use, robust data protection solution for workstations and entry level servers. It offers fast disk backup performance (up to 108gB/hr) with removable disk cartridges. available in internal and external versions, the rDX Backup System docking stations use 160-, 320- & 500gB removable disk cartridges and will also accommodate future higher capacity cartridges.
UE315E 3 Years 13x5 onsite Hardware Support go to www.hp.com/go/lookuptool, select ‘Country’ and enter the product number for other Care Pack options. StaNDarD WarraNtY IS 1 Year NeXt BUSINeSS DaY, PartS eXCHaNge PLUS 1 Year 9X5 SoFtWare PHoNe SUPPort For models that include an integrated tape drive, the tape drive carries its own separate warranty. Hewlett-Packard provides a 3 year, next business day, parts exchange warranty for the StorageWorks Ultrium tape drive, plus 9x5 phone support for the duration of the warranty.
D2D2500 Backup System the HP StorageWorks D2D2500 Backup System provides consolidated disk-based data protection for up to six servers in a 1U rack-mountable iSCSI device. Ideal for remote or branch offices and smaller It environments, the D2D2500 works with existing backup software applications to automate daily backup tasks.
UJ752E 3 Years 13x5 4H onsite Hardware Support go to www.hp.com/go/lookuptool, select ‘Country’ and enter the product number for other Care Pack options. StaNDarD WarraNtY IS 1 Year NeXt BUSINeSS DaY PartS eXCHaNge PLUS 1 Year 9X5 PHoNe SUPPort CLICK’N’GO FOR MORE: Detailed Product Specifications: www.hp.com/go/d2d...
A. the products on this page are Configure-to-order (Cto). Customers may create sample configurations with list pricing using the HP enterprise Configurator available at www.hp.com/products/configurator. HP Business Partners may configure solutions using Sales Builder for Windows (SBW) available from Partner online. Please contact your HP or HP Business Partner account manager for a full configuration with pricing quotation.
A. the products on this page are Configure-to-order (Cto). Customers may create sample configurations with list pricing using the HP enterprise Configurator available at www.hp.com/products/configurator. HP Business Partners may configure solutions using Sales Builder for Windows (SBW) available from Partner online. Please contact your HP or HP Business Partner account manager for a full configuration with pricing quotation.
UPgraDe FroM Data ProteCtor eXPreSS SINgLe SerVer eDItIoN Data Protector express Single Server edition ships Free with every HP Ultrium and Dat tape Drive. this part number allows registered owners of Data Protector express Single Server edition to acquire Data Protector express at a reduced cost.
Page 29
Supports the HP one Button Disaster recovery feature of HP tape products. one LtU per machine that requires automated disaster recovery.
HP StorageWorks Storage Mirroring Software provides host-based replication for customers seeking a lower-cost alternative to fabric or array-based replication. Patented replication and failover technology continuously captures byte-level data changes as they occur and replicates those changes to one or more target servers in any location without geographic limitations.
Host bus adaptors are used to directly connect internal tape drives, external tape drives, tape autoloaders and tape libraries to server hosts. to determine compatibility of a particular combination of HBa and backup device, refer to www.hp.com/go/productbulletin and www.hp.com/go/connect. Cabling, (if required, as many backup devices include an appropriate cable), can be checked...
Page 32
SaS, SCSI and Fibre Channel Cable kits. HP SaS and SCSI Cable kits are used to connect internal tape drives, external tape drives, tape autoloaders and tape libraries to server hosts. to determine compatibility of a particular combination of SaS or SCSI cable, HBa and backup device, refer to www.hp.com/go/productbulletin.
HP StorageWorks rack-Mount Shelves are supported by ProLiant, HP Integrity, and alphaServer platforms. available in SCSI, SaS and USB interfaces, the 1U rack-Mount kit accommodates up to two half-height internal tape drives and supports a range of tape technologies, including Dat, DLt VS, and half-height Lto Ultrium.
(DaS) for HP ProLiant and Integrity Servers. Connection to servers is usually performed using HP Smart array Controllers (although SCSI and SaS controllers without hardware raID may also be used). Supported configurations are listed in the appropriate QuickSpecs for the MSa enclosures at www.hp.com/go/productbulletin.
(DaS) for HP ProLiant and Integrity Servers. Connection to servers is usually performed using HP Smart array Controllers (although SCSI and SaS controllers without hardware raID may also be used). Supported configurations are listed in the appropriate QuickSpecs for the MSa enclosures are found at www.hp.com/go/productbulletin.
Page 36
(DaS) for HP ProLiant and Integrity Servers. Connection to servers is usually performed using HP Smart array Controllers (although SCSI and SaS controllers without hardware raID may also be used). Supported configurations are listed in the appropriate QuickSpecs for the MSa enclosures are found at www.hp.com/go/productbulletin.
Upgrade drive enclosure including drives to Support Plus 24 (3 Year 24x7 4H onsite) UK228E Upgrade drive enclosure including drives to Support Plus (3 Year 13x5 4H onsite) go to www.hp.com/go/lookuptool, select ‘Country’ and enter product number for Care Pack options. CLICK’N’GO FOR MORE: Information on Modular Smart array: www.hp.com/go/msa Detailed Product Specifications: www.hp.com/go/productbulletin...
Page 38
Upgrade drive enclosure including drives to Support Plus 24 (3 Year 24x7 4H onsite) UK228E Upgrade drive enclosure including drives to Support Plus (3 Year 13x5 4H onsite) go to www.hp.com/go/lookuptool, select ‘Country’ and enter product number for Care Pack options. CLICK’N’GO FOR MORE: Information on Modular Smart array: www.hp.com/go/msa Detailed Product Specifications: www.hp.com/go/productbulletin...
SB40c Storage Blade for BladeSystem c-Class the HP StorageWorks SB40c is a half-height c-Class storage blade supporting up to six hot-plug Small Form Factor (SFF) Serial attached SCSI (SaS) or Serial ata (Sata) hard disk drives. Using the onboard Smart array...
HP StorageWorks 3gb SaS BL Switch for HP BladeSystem c-Class enclosures enables an external shared SaS solution for blade servers. Installed in pairs, the 3gb SaS BL Switch allows each blade server with a Smart array P700m controller to access storage on attached HP StorageWorks MSa2000sa.
Hardware options available include memory upgrades, disk upgrades, additional NICs, raID controllers plus internal and external tape drives. Software options include Microsoft iSCSI Software target, HP Storage Mirroring and HP Data Protector express Backup Software. HP Care Pack Options UH162E Support Plus 24 –...
Hardware options available include memory upgrades, external disk upgrades, external raID controllers and external tape drives. Software options include Microsoft iSCSI Software target, upgrade to Windows Storage Server 2003 r2 Standard edition, HP Storage Mirroring and HP Data Protector express Backup Software.
Support Plus - 3 Years 4H 13x5 onsite Hardware Support go to www.hp.com/go/lookuptool, select ‘Country’ and enter product number for care pack options StaNDarD WarraNtY IS 1 Year PartS eXCHaNge, 1 Year LaBoUr aND 1 Year oNSIte, NeXt BUSINeSS DaY reSPoNSe CLICK’N’GO FOR MORE:...
3 Years 13x5 4H onsite Hardware Support plus 3 Years 9x5 Software Phone Support go to www.hp.com/go/lookuptool, select ‘Country’ and enter the product number for other Care Pack options. StaNDarD WarraNtY IS 3 YearS NeXt BUSINeSS DaY oNSIte PLUS 1 Year 9x5 SoFtWare PHoNe SUPPort CLICK’N’GO FOR MORE:...
Support Plus - 3 Years 4H 13x5 onsite Hardware Support go to www.hp.com/go/lookuptool, select ‘Country’ and enter product number for Care Pack options. StaNDarD WarraNtY IS 3 YearS PartS eXCHaNge, 3 YearS LaBoUr & 3 YearS oNSIte, NeXt BUSINeSS DaY reSPoNSe CLICK’N’GO FOR MORE:...
3 Years 24x7 Phone Support and Software Updates UF132E 3 Years 9x5 Phone Support and Software Updates go to www.hp.com/go/lookuptool, select ‘Country’ and enter product number for Care Pack options. CLICK’N’GO FOR MORE: Information on NaS: www.hp.com/go/nas Detailed Product Specifications: www.hp.com/go/productbulletin...
AiO400r and AiO400t Storage Systems HP StorageWorks aio400r and aio400t Storage Systems are unified storage solutions that provide shared storage for Microsoft exchange and Microsoft SQL Servers (iSCSI SaN), enhanced file serving for end-user all-in-one Storage Systems arrive preconfigured and highly integrated with management application and wizards that enable growing businesses to easily manage, grow, and protect data without requiring them to become storage experts.
Storage System is a high storage density, performance-optimized, and easily expandable solution built on the HP ProLiant DL185 g5 Storage Server. It provides shared storage expansion for application servers (iSCSI SaN), enhanced file serving for end-user clients (NaS), and comprehensive data protection features all in a 12-drive/2U rack-mount package.
Support Plus – 3 Years 13x5 4H onsite Hardware Support Plus 3 Years 9x5 Software Phone Support go to www.hp.com/go/lookuptool, select ‘Country’ and enter product number for Care Pack options. StaNDarD WarraNtY IS 3 YearS NeXt BUSINeSS DaY oNSIte PLUS 1 Year 9x5 SoFtWare PHoNe SUPPort CLICK’N’GO FOR MORE:...
Q. How do I obtain a configuration and price quotation for these products? A. the products on this page are Configure-to-order (Cto). Customers may create sample configurations with list pricing using the HP enterprise Configurator available at www.hp.com/products/configurator. HP Business Partners may configure solutions using Sales Builder for Windows (SBW) available from Partner online.
Q. How do I obtain a configuration and price quotation for these products? A. the products on this page are Configure-to-order (Cto). Please contact your HP or HP Business Partner account manager for a full configuration with pricing quotation.
Q. How do I obtain a configuration and price quotation for these products? A. the products on this page are Configure-to-order (Cto). Please contact your HP or HP Business Partner account manager for a full configuration with pricing quotation.
HP StorageWorks 2000 Modular Smart arrays (MSa2000) are new generation SaN arrays designed for storage consolidation in growing businesses. available in both Fibre Channel and iSCSI versions, they support expansion up to 48tB using Sata HDDs or 21.6tB using SaS HDDs.
Page 54
Modular Smart Array 2000 New generation HP Storage array designed for growing business. available in both fibre channel and iSCSI versions MSA2000i (GbE connected iSCSI SAN Array) At least one of these base enclosures is required per iSCSI SAN AJ746A MSa2012i Single Controller Modular Smart array Single controller, 12-bay base enclosure with two 1gbe iSCSI connections and one ethernet port for management.
HP StorageWorks enterprise Virtual array family is an enterprise class storage array system designed to automate array management tasks allowing more storage capacity to be managed with fewer resources. the enterprise Virtual arrays are designed for the data center where there is a critical need for improved storage utilisation and scalability.
PDUs, SaN infrastructure, and racking components to provide a ready- to-run solution which can be delivered installed in an HP rack or in the case of some models, including the eVa4400 Starter kit, can be supplied without racking components to allow integration into customers existing rack infrastructure.
Q. How do I obtain a configuration and price quotation for these products? the products on this page are Configure-to-order (Cto). Customers may create sample configurations with list pricing using the HP enterprise Configurator available at www.hp.com/products/configurator. HP Business Partners may configure solutions using Sales Builder for Windows (SBW) available from Partner online.
Q. How do I obtain a configuration and price quotation for these products? the products on this page are Configure-to-order (Cto). Customers may create sample configurations with list pricing using the HP enterprise Configurator available at www.hp.com/products/configurator. HP Business Partners may configure solutions using Sales Builder for Windows (SBW) available from Partner online.
VLS 12000 eVa gateway accelerates backup and restore performance in complex SaN environments by emulating popular tape libraries and tape drives while using HP eVa as the storage pool. By emulating multiple tape drives simultaneously, more backup jobs can be done in parallel resulting in reduced backup times and, because the data resides on disk, single file restores are exceptionally fast.
Q. How do I obtain a configuration and price quotation for these products? the products on this page are Configure-to-order (Cto). Customers may create sample configurations with list pricing using the HP enterprise Configurator available at www.hp.com/products/configurator. HP Business Partners may configure solutions using Sales Builder for Windows (SBW) available from Partner online.
Q. How do I obtain a configuration and price quotation for these products? the products on this page are Configure-to-order (Cto). Customers may create sample configurations with list pricing using the HP enterprise Configurator available at www.hp.com/products/configurator. HP Business Partners may configure solutions using Sales Builder for Windows (SBW) available from Partner online.
Page 62
When downtime is not an option, the XP disk array family provides always-on availability for access to mission critical information. Now in their 5th generation, the HP StorageWorks XP Disk arrays combine a completely redundant hardware platform with unique data replication capabilities for complete business continuity. and through HP StorageWorks XP thin Provisioning Software and the seamless scalability of the hardware, they can quickly adapt to change and accelerate the growth of the business.
Q. How do I obtain a configuration and price quotation for these products? A. the products on this page are Configure-to-order (Cto). Customers may create sample configurations with list pricing using the HP enterprise Configurator available at www.hp.com/products/configurator. HP Business Partners may configure solutions using Sales Builder for Windows (SBW) available from Partner online.
Q. How do I obtain a configuration and price quotation for these products? A. the products on this page are Configure-to-order (Cto). Please contact your HP or HP Business Partner account manager for a full configuration with pricing quotation.
FC 2243 4gbps PCI-X DC HBa (emulex LP1 1002) 4gbps PCI-X-to-Fibre Channel Host Bus adapter for Windows and Linux. HP Care Pack Options go to www.hp.com/go/lookuptool, select ‘Country’ and enter the product number for Care Pack options. CLICK’N’GO FOR MORE: More Information www.hp.com/go/san...
Fibre Channel Cables are supplied to oM2 or oM3 specification. the two cable types are physically interchangeable with oM3 supporting longer distances. You can find supported distances by reviewing any 8gb SaN Switch QuickSpecs at www.hp.com/go/productbulletin. Fibre Channel Cables (OM2)
HP Care Pack Options 3 Years 4H 24x7 Support Plus 24 3 Years 4H 13x5 Support Plus go to www.hp.com/go/lookuptool, select ‘Country’ and enter the product number for other Care Pack options. CLICK’N’GO FOR MORE: Information on SaN Infrastructure: www.hp.com/go/san Detailed Product Specifications: www.hp.com/go/productbulletin...
3 Year 24X7 4H Support Plus 24 Hardware Support 3 Year 13X5 4H Support Plus Hardware Support go to www.hp.com/go/lookuptool, select ‘Country’ and enter the product number for other Care Pack options. StaNDarD WarraNtY IS 1 Year oNSIte NeXt BUSINeSS DaY SUPPort CLICK’N’GO FOR MORE:...
Q. How do I obtain a configuration and price quotation for these products? A. the products on this page are Configure-to-order (Cto). HP Business Partners may configure solutions using Sales Builder for Windows (SBW) available from Partner online. Please contact your HP or HP Business Partner account manager for a full configuration with pricing quotation.
3 Year 24X7 4H Support Plus 24 Hardware Support 3 Year 13X5 4H Support Plus Hardware Support go to www.hp.com/go/lookuptool, select ‘Country’ and enter the product number for other Care Pack options. StaNDarD WarraNtY IS 1 Year NeXt BUSINeSS DaY oNSIte SUPPort CLICK’N’GO FOR MORE:...
A. the products on this page are Configure-to-order (Cto). HP Business Partners may configure solutions using Sales Builder for Windows (SBW) available from Partner online. Please contact your HP or HP Business Partner account manager for a full configuration with pricing quotation.
3 Years 4H 24x7 onsite Hardware Support UH143E 3 Years Next Business Day onsite Hardware Support go to www.hp.com/go/lookuptool, select ‘Country’ and enter the product number for other Care Pack options. StaNDarD WarraNtY IS 1 Year oNSIte NeXt BUSINeSS DaY reSPoNSe CLICK’N’GO FOR MORE: Information on SaN Infrastructure: www.hp.com/go/san...
3 Year 24X7 4H Support Plus 24 Hardware Support 3 Year 13X5 4H Support Plus Hardware Support go to www.hp.com/go/lookuptool, select ‘Country’ and enter the product number for other Care Pack options. StaNDarD WarraNtY IS 1 Year NeXt BUSINeSS DaY oNSIte SUPPort CLICK’N’GO FOR MORE:...
A. the products on this page are Configure-to-order (Cto). HP Business Partners may configure solutions using Sales Builder for Windows (SBW) available from Partner online. Please contact your HP or HP Business Partner account manager for a full configuration with pricing quotation.
HP Care Pack Sales or Registration aUS Care Pack team: 1800 500 255 HP Care Pack or HP Contract Support: Standard Warranty Support: (only use this option if you do not have a Care Pack or Contract) When making a support call, please ensure you have the following information: •...
