1.
Remove the existing node from the rack:
a.
Power off the system. See
b.
From the back of the node, make a note of all cable connections then disconnect the cables.
c.
From the front of the node, loosen the captive thumbscrews until the thumbscrews are free
of the rack.
d.
Pull the node out from the rack until it stops.
e.
Squeeze the release brackets (see
2.
Install the new node into the rack. See
3.
Reconnect the cables to the new node exactly as they were connected to the previous node.
4.
Configure the node according to the instructions provided in
1 through
5.
Reboot the system. See
Fibre Channel Switch 4/10q Replacement
To replace a Fibre Channel Switch 4/10q:
1.
Power off the switch.
2.
Make a note of all cable connections to the switch then disconnect the cables.
3.
Remove the 1U cover plate for the racking shelf on which the 4/10q switch sits from the front of
the rack.
4.
Remove the four bolts from the rail flanges on the rear rack uprights using a #2 Phillips screwdriver.
5.
Loosen the two nuts securing the rail ends to the adjustable mounting flanges, which are mounted
on the front rack uprights, using a 7/16 inch wrench.
6.
Slide the racking shelf out the rear of the rack.
CAUTION:
Make sure the racking shelf is supported below, either by equipment mounted in the next
rack slot or with your hand, before sliding the racking shelf off the adjustable mounting
flange that support it.
7.
Temporarily remove the retaining brace from the edge of the racking shelf.
8.
Disconnect the DC cord of the power supply from the back of the switch.
9.
Remove the switch from the racking shelf.
Release the prongs on the backstop from the slots on the back of the switch.
10.
To remove the switch power supply from the racking shelf:
a.
Pull up the locking tab near the back edge of the power supply clamp.
b.
Remove the switch power supply from the racking shelf.
To ease the removal of the power supply, slightly lift the outside edge of the power supply
clamp.
c.
Disconnect the AC power cord from the back of the power supply and from the AC power
source.
Powering Off the
7.
Rebooting the
System.
Figure
84), then pull the node free from the rails.
Installing the VLS Node into a
Configuring the Secondary Nodes
System.
Rack.
HP StorageWorks
265
