CAUTION:
Do not operate the node for long periods without the access panel. Operating the node without the
access panel results in improper airflow and improper cooling that can lead to thermal damage.
CAUTION:
Electrostatic discharge can damage electronic components. Properly ground yourself before beginning
any installation procedure.
1. Power off the node. See
2. Extend the node from the rack. See
3. Lift up on the hood latch handle which slides the panel toward the rear of the unit.
4. Lift up the panel to remove it.

Installing the VLS9000 Node Access Panel

1. Set the access panel on top of the node about 0.2 inch from the opening with the hood latch
open.
2. Engage the anchoring pin with the corresponding hole in the latch.
3. Push down on the hood latch.
4. Slide the access panel into the closed position.

VLS9000 Node Component Replacement

SATA Hard Drive

CAUTION:
To prevent improper cooling and thermal damage, do not operate the node unless all bays are
populated with either a component or a blank.
1. Press the drive latch release button (1).
256 Component Replacement
Powering Off the System.
Extending the Node from the Rack.
