6. Once the new secondary node has finished rebooting, log on to Command View VLS and log
in as the administrator. See
"Opening a Command View VLS Session from a Web
7. Select the System tab.
8. Select Nodes from the navigation tree.
9. Select Add Node from the task bar in the main window. This will bring up the Add Node Wizard.
10. Verify that the node name in the Node Name field is the next available number that you configured
previously. For example, the primary node, previously configured as Node 0, is identified as
Node 0 in the list of nodes on the navigation tree. The first secondary node added should be
Node 1. The next secondary node added should be Node 2.
11. Select Finish to add the node.
12. Power on array 1 (or next array in series).
NOTE:
The VLS sequentially numbers arrays as they are added starting with Array 0 . Only power
up and install one array at a time, so you can control the number assigned to each array.
Only power up one array for each node configured to prevent a capacity license violation.
13. Add the array 1 (or next array in series) storage to the VLS:
a. Open a Command View VLS session and log in as the administrator. See
"Opening a Command View VLS Session from a Web
b. In the Storage tab navigation tree, select Storage LUNs.
c. Select Discover Unconfigured Storage from the task bar.
14. Repeat these steps to add nodes until all of the nodes are listed in the navigation tree.
NOTE:
Node numbering must be sequential with no gaps. Gaps in ID numbering will prevent the VLS from
recognizing any nodes with an ID after the gap. For example, if node numbering is 0, 1, 2, 4, 5, the
VLS will not recognize nodes 4 and 5.
74 Multi-node Setup
Browser" on page 143.
Browser" on page 143.
