Base Disk Array Rear Panel Led Status During Normal Operation - HP StorageWorks 9000 - Virtual Library System User Manual

Item Location
4
NOTE:
The hard drive LEDs may not immediately illuminate when the disk array is powered on. The LEDs
illuminate after the hard drives are configured by the VLS firmware.
Figure 39 Base disk array rear panel LED status during normal operation
.
Item Location
1
Power module
2
3
4
5
RAID controller
6
7
8
LED
Power On/OK
LED
AC Power Good (green)
DC-Fan Fault/ Service Required
(yellow)
FC link status (L) (green)
FC link speed (S) (green)
Fault/Service required (yellow)
Power On/OK (green)
Ethernet link status (green)
Expansion port status (green)
LED state
On
LED state
On
Off
On
On
Off
On
On
On
HP StorageWorks 135
