AT&T MERLIN LEGEND Release 2.0 Programming Summary Manual page 98

Lines and Trunks
Summary: Trunks to Pools Assignment
Programmable by
M o d e
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
Console Procedure
†
PC Procedure
† Entry mode available
System manager
Hybrid/PBX
Trunk idle
Form 2c, System Numbering — Trunk Jacks
All loop-start trunks are assigned to the Main Pool
(factory-set extension number 70); all tie trunks are
assigned to the pool with the factory-set extension
number 891; no factory-set extension assigned to
ground-start trunks.
Line numbers
Yes
Yes
†
LinesTrunks
Select block of lines
Enter
Enter Exit
[F4] [F9]
Select block of lines
[F10] [F5]
Dial pool dial-out code
Pools
Toggle LED On/Off
Exit
Type pool dial-out code
Toggle letter R On/Off
[F5]
Trunks to Pools Assignment
[F10]
4-19
