System Operator Positions
Summary: QCC Operator Positions
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
Console Procedure
PC Procedure
DLC Operator Positions
DLC operator positions can be assigned to the first and fifth ports on the first
modules with digital or analog multiline station jacks. A maximum of eight
DLC operator positions can be assigned. Any combination of operator
positions can be assigned as long as there are no more than four QCC
operators and no more than 8 operators in total.
Use this procedure to specify telephones that serve as central answering
positions for all incoming calls, for Call Management Systems connected to
operator ports, or as calling group supervisors. (You do not need to use this
procedure in a Key or Behind Switch system unless you have more than one
DLC position.) Trunks are assigned on individual buttons. The system
programming console can have several incoming calls ringing simultaneously.
For a new system, remove the factory set DLC operator position assignment
for any telephone not used as an operator position.
System manager
Hybrid/PBX
System idle
Form 2a, System Numbering - Station Jacks
Type - DLC
first or fifth ports on MLX module (maximum—2 per
module, maximum—4 QCCs per system)
Yes
No
Operator
Positions
ext. no.
Enter
[F3]
[F1]
[F2]
[F3]
QCC System Operator Positions
Queued Call
StoreAll
Type ext. no.
Dial
[F10]
3-5
