Line Compensation - AT&T MERLIN LEGEND Release 2.0 Programming Summary Manual

DS1 Facilities

Line Compensation

Use this procedure to specify the amount of cable loss in decibels based on
the length of cable between the 100D module and the channel service unit or
far end. The choices are as follows:
1 = 0.6 dB loss
2 = 1.2 dB loss
3 = 1.8 dB loss
4 = 2.4 dB loss
5 = 3.0 dB loss
Summary: Line Compensation
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
Console Procedure
PC Procedure
5-8
Line Compensation
System manager
All
100D module idle
Form 3b, Incoming Trunks - DS1 Connectivity (100D
Module)
1 (0.6 dB loss)
1 - 5
No
No
LinesTrunks
Enter Line Comp
compensation value
[F4] [F1] Type slot no.
[Alt] + [P] Type line compensation value
[F10] [F5] [F5]
Dial Slot no.
LS/GS/DS1
Drop Dial line
Enter Exit
[F10]
Exit
[F6]
