Remote Maintenance Device
FIGURE 1-4 The MERLIN MAIL system modem.
1-6 Installing the MERLIN MAIL System
If you reset the switches, you must turn off
NOTE:
the modem and turn it back on before the new
settings go into effect.
Using the cable provided, connect the RS-232-C port
9
of the modem to the modem (COM1) port on the
MERLIN MAIL system.
(Front view)
AC
outlet
Using a modular line cord, connect the modem's
10
telephone line port to a station jack on the
Basic Telephone (012) Module.
Write the jack number on the label and affix the label
11
to the MERLIN MAIL system unit.
Remote Maintenance Device
(Back view)
RS 232-C Telephone
(COM1 port)
line port
On/off
switch
