MERLIN LEGEND® MAIL
Voice Messaging System
for the MERLIN LEGEND® Communications System
Installation and Upgrade
Lucent Technologies
formerly the communications
systems and technology
units of AT&T
Document 555-600-100
Comcode 107734709
Issue 1
November 1996

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lucent Technologies MERLIN LEGEND and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AT&T Lucent Technologies MERLIN LEGEND

Summary of Contents for AT&T Lucent Technologies MERLIN LEGEND

  • Page 1 MERLIN LEGEND® MAIL Voice Messaging System for the MERLIN LEGEND® Communications System Installation and Upgrade Document 555-600-100 Lucent Technologies Comcode 107734709 formerly the communications Issue 1 systems and technology November 1996 units of AT&T...
  • Page 2 Copyright © 1996, Lucent Technologies Document 555-600-100 All Rights Reserved Comcode 107734709 Printed in U.S.A. Issue 1 November 1996 Notice Every effort was made to ensure that the information in this book was complete and accurate at the time of printing. However, information is subject to change.
  • Page 3 WARNING: This book is intended for trained technicians only. ONLY an authorized Lucent Technologies technician or authorized dealer shall install, set hardware options, or repair this product. DO NOT attempt to install or remove this product. DO NOT open the cover of the MERLIN LEGEND MAIL module.

  • Page 4: Table Of Contents

    Contents Introduction Overview of the MERLIN LEGEND MAIL System Using This Guide Related Documents 1-11 Installing the MERLIN LEGEND MAIL System Overview Prepare for Installation Installation Upgrading the MERLIN LEGEND MAIL System Overview Installing a Voice-Port Card Replacing the Disk Drive Replacing a Two-Port or Four-Port Voice-Port Card Replacing a MERLIN LEGEND MAIL Module...
  • Page 5 Contents Busying Out/Restoring the Module Overview Busying Out the Module Restoring the Module Installing/Removing the Module Overview Installing the Module Removing the Module Using the Serial Number Utility Overview Re-Serializing the Disk Drive Resetting the System Overview Resetting the MERLIN LEGEND MAIL Module Resetting the Remote Maintenance Device Changing the Far-End Disconnect Setting and Adding a 3 db Boost...
  • Page 6 Figures Introduction 1-1. MERLIN LEGEND MAIL Module with a Four-Port Expansion Voice-Port Card 1-2. Two-Port Voice-Port Expansion Card 1-3. Four-Port Voice-Port Expansion Card Upgrading the MERLIN LEGEND MAIL System 3-1. Sliding Voice-Port Card into Module 3-2. Removing Disk Drive Assembly 3-3.

  • Page 7: Introduction

    Introduction Overview of the MERLIN LEGEND MAIL System The MERLIN LEGEND® MAIL Voice Messaging System provides the same features and functionality as the MERLIN MAIL® Voice Messaging System Release 3.0. However, its integrated design houses both the station port and the voice mail functionality in a single module that plugs into the MERLIN LEGEND backplane.

  • Page 8: Merlin Legend Mail Module With A Four-Port Expansion Voice-Port Card

    Introduction RMD Reset Button Reset LEDs for Port 1 LEDs for Port 2 System Reset Button Reset Reset 9-Pin Serial Port (Female) Reset 4-Port Expansion Voice-Port Card LEDs for Port 3 LEDs for Port 4 LEDs for Port 5 LEDs for Port 6 System Status LED Status...
  • Page 9 Introduction System Components The MERLIN LEGEND MAIL system consists of one module that resembles a MERLIN LEGEND system 012 module with no modular jacks and resides in the MERLIN LEGEND system carrier. The MERLIN LEGEND MAIL system module consists of three subassemblies and their components: a base module (which provides two touch-tone receivers and a 1200-baud remote maintenance device) Similar to an 012 module, the MERLIN LEGEND MAIL module is...
  • Page 10 Introduction Description of the Two-Port MERLIN LEGEND MAIL System The two-port MERLIN LEGEND MAIL system includes the base module, hard disk, which provides 21 hours of message storage, and two voice ports. Port Assignments The ports on the two-port MERLIN LEGEND MAIL system are assigned as follows: port 1 - voice mail port 2 - voice mail...

  • Page 11: Two-Port Voice-Port Expansion Card

    Introduction Description of the Four-Port MERLIN LEGEND MAIL System The four-port MERLIN LEGEND MAIL system includes the base module, hard disk, which provides 21 hours of message storage, and four voice ports. The two-port voice-port card required for this system is shown in Figure 1-2. Figure 1-2.

  • Page 12: Four-Port Voice-Port Expansion Card

    Introduction Description of the Six-Port MERLIN LEGEND MAIL System The six-port MERLIN LEGEND MAIL system includes the base module, hard disk, which provides 21 hours of message storage, and voice ports. The four- port expansion voice-port card required for this system is shown in Figure 1-3. VM 6 Figure 1-3.
  • Page 13 Introduction LED Meanings On the six-port MERLIN LEGEND MAIL system, the four-port expansion voice- port card has four pairs of LEDs (labeled VM3, VM4, VM5, and VM6). The meaning of these LEDs is the same as for the LEDs labeled VM1 and VM2. (See Table 1-1.) The MERLIN LEGEND MAIL System Advantages...
  • Page 14 Introduction MERLIN LEGEND MAIL System Specifications Before installing the MERLIN LEGEND MAIL module, be sure that your installation site meets the environmental requirements provided in Table 1-2. Table 1-2. MERLIN LEGEND MAIL System Specifications Condition Requirement Relative Humidity < 90% 40 °...

  • Page 15: Using This Guide

    Introduction Using This Guide This guide provides the installation, upgrade, troubleshooting, and ordering information for the MERLIN LEGEND MAIL system. The information in this guide replaces the existing installation, upgrade, and ordering information in Chapter 2, Chapter 7, and Appendix G of the MERLIN MAIL® Voice Messaging System Release 3 Planning, Installation, and Use (AT&T 585-320-142) .
  • Page 16 Introduction Appendix A: Ordering Information This appendix provides the ordering codes for the MERLIN LEGEND MAIL system. This appendix replaces the information in Appendix G of the MERLIN MAIL® Voice Messaging System Release 3 Planning, Installation, and Use (AT&T 585-320-142) . Appendix B: Busying Out/Restoring the Module This appendix provides the step-by-step instructions for busying out and restoring the MERLIN LEGEND MAIL module.

  • Page 17: Related Documents

    Introduction Related Documents The documents listed below are MERLIN MAIL Voice Messaging System documents or part of the MERLIN LEGEND Communications System documentation set. These documents can be ordered from the Lucent Technologies Publications Center by calling 1-800-457-1235. Table 1-3. MERLIN MAIL Voice Messaging System Release 3 and MERLIN LEGEND Communications System Release 3.1 and Release 4.1 Documentation Set Document No.
  • Page 18 Introduction Release 3.1 and Release 4.0 Operator Support AT&T 555-640-134 MLX Direct-Line Console Operator's Guide AT&T 555-640-132 Analog Direct-Line Console Operator's Guide AT&T 555-640-136 MLX Queued Call Console Operator's Guide MERLIN LEGEND Communications System Release 3.1 and Release 4.0 Miscellaneous User Support AT&T 555-640-130 Calling Group Supervisor's Guide...

  • Page 19: Installing The Merlin Legend Mail System

    Installing the MERLIN LEGEND MAIL System Overview This chapter describes how to install a new MERLIN LEGEND MAIL module. WARNING The procedures in this chapter are intended for qualified technicians only. Prepare for Installation Before you begin, verify that you have: the required MERLIN LEGEND MAIL system components (see "System Components"...
  • Page 20 Installing the MERLIN LEGEND MAIL System The MERLIN LEGEND system treats the MERLIN LEGEND MAIL module like an 012 module. When installed, the module has a default of 12 extension numbers that are based on the carrier slot in which the module is located. Though the MERLIN LEGEND MAIL module provides 12 ports, only ports 1 through 7 are used by the MERLIN MAIL system.

  • Page 21: Installation

    Installing the MERLIN LEGEND MAIL System Installation When installing the MERLIN LEGEND MAIL module, keep in mind the following: Make sure the MERLIN LEGEND system has a 391A3 or newer power supply module. MERLIN LEGEND MAIL does not support the 391A1 and 391A2 power supply modules.
  • Page 22 Installing the MERLIN LEGEND MAIL System 5. Perform the acceptance tests in Chapter 4 of this document and also the acceptance tests in Chapter 6 of the MERLIN MAIL® Voice Messaging System Release 3 Planning, Installation, and Use (AT&T 585-320-142)

  • Page 23: Upgrading The Merlin Legend Mail System

    Upgrading the MERLIN LEGEND MAIL System Overview This chapter describes how to upgrade the number of voice mail ports in the MERLIN LEGEND MAIL module replace the disk drive in the MERLIN LEGEND MAIL module replace the voice-port card in the MERLIN LEGEND MAIL module replace the MERLIN LEGEND MAIL module replace an existing MERLIN MAIL Voice Messaging System with a MERLIN LEGEND MAIL module...

  • Page 24: Installing A Voice-Port Card

    Upgrading the MERLIN LEGEND MAIL System Installing a Voice-Port Card Customers with a two-port or four-port configuration may want to upgrade to a four-port or six-port configuration to support more subscribers or a greater volume of calls. The MERLIN LEGEND MAIL system can have a maximum of six ports.

  • Page 25: Sliding Voice-Port Card Into Module

    Upgrading the MERLIN LEGEND MAIL System 6. Unplug the voice-port card by sliding it out all of the way. 7. Install the upgrade voice-port card by sliding the card into the card slots, and seating it in the MERLIN LEGEND MAIL module (Figure 3-1). Do not push on the two handles;...

  • Page 26: Removing Disk Drive Assembly

    Upgrading the MERLIN LEGEND MAIL System This section describes how to replace the disk drive in the MERLIN LEGEND MAIL module. CAUTION: Before touching leads, connectors, pins, and other components when handling the disk drive, use a properly grounded wrist strap to prevent damage from electrostatic discharge (ESD).

  • Page 27: Disk Drive Assembly

    Upgrading the MERLIN LEGEND MAIL System Figure 3-3. Disk Drive Assembly 5. Plug the new disk drive assembly into the MERLIN LEGEND MAIL module. 6. Reinstall the MERLIN LEGEND MAIL module. See Appendix C. 7. Restore the slot. See Appendix B. 8.

  • Page 28: Replacing A Two-Port Or Four-Port Voice-Port Card

    Upgrading the MERLIN LEGEND MAIL System Replacing a Two-Port or Four-Port Voice-Port Card This section describes how to replace a two-port or four-port voice-port card (if it is defective) in a MERLIN LEGEND MAIL module. CAUTION: To prevent damage from electrostatic discharge (ESD), avoid touching leads, connectors, pins, and other components.

  • Page 29: Replacing A Merlin Legend Mail Module

    Upgrading the MERLIN LEGEND MAIL System Replacing a MERLIN LEGEND MAIL Module This section describes how to replace a MERLIN LEGEND MAIL module that is defective (for example, port 1 or port 2 is defective or the clock battery is bad). You will want to retain the disk drive from the defective unit so that the customer's messages, greetings, and programming are not lost.
  • Page 30 Upgrading the MERLIN LEGEND MAIL System 6. Take the replacement MERLIN LEGEND MAIL module out of its bag.  If you are not installing a voice-port card, proceed to Step 7.  If you are installing a voice-port card (that is, either a new voice-port card or the voice-port card from the old MERLIN LEGEND MAIL module), perform the following steps: a.

  • Page 31: Replacing An Existing Merlin Mail Vms With A Merlin Legend Mail Module

    Upgrading the MERLIN LEGEND MAIL System Replacing an existing MERLIN MAIL VMS with a MERLIN LEGEND MAIL Module To replace an existing MERLIN MAIL Voice Messaging System with a MERLIN LEGEND MAIL module: 1. Install a completely configured MERLIN LEGEND MAIL module (that is, the correct number of ports physically installed) into the first empty slot in the MERLIN LEGEND system carrier.
  • Page 32 Upgrading the MERLIN LEGEND MAIL System b. Restrict the RMD from making outside calls. To do this, enter MERLIN LEGEND System Programming, select Extensions then Restriction and follow the prompts. For Restriction Type, choose Outward Restrict . Security Alert : This step must be followed to limit the possibility of toll fraud abuse.

  • Page 33: Acceptance Tests And Troubleshooting

    Acceptance Tests and Troubleshooting Overview This chapter describes how to perform the acceptance test to verify proper operation of the Remote Maintenance Device (RMD). This test is intended only to supplement the instructions for performing acceptance tests detailed in Chapter 6 of the MERLIN MAIL® Voice Messaging System Release 3 Planning, Installation, and Use (AT&T 585-320-142) .

  • Page 34: Performing Acceptance Tests

    Acceptance Tests and Troubleshooting Performing Acceptance Tests After you finish programming the MERLIN LEGEND MAIL system, perform the following acceptance test. You should also perform the acceptance tests detailed in Chapter 6 of the MERLIN MAIL® Voice Messaging System Release 3 Planning, Installation, and Use (AT&T 585-320-142) to verify proper operation of each applicable service, including voice mail, automated attendant, and call answer service.

  • Page 35: Troubleshooting

    Acceptance Tests and Troubleshooting Troubleshooting This section provides procedures for troubleshooting the MERLIN LEGEND MAIL module. You should also perform the troubleshooting procedures detailed in Chapter 6 of the MERLIN MAIL® Voice Messaging System Release 3 Planning, Installation, and Use (AT&T 585-320-142) . MERLIN LEGEND MAIL does not answer Verify whether the voice ports on the MERLIN LEGEND MAIL are operating properly:...
  • Page 36 Acceptance Tests and Troubleshooting The Disk Drive is not Working Properly To verify whether the disk drive is working properly: 1. From the Merlin Mail administration menu, type b to shut down the system. When the shut down is complete, the following message appears: Merlin Mail is down.

  • Page 37: A Ordering Codes

    Ordering Codes Overview This appendix provides the ordering codes for the MERLIN LEGEND MAIL system. This appendix replaces the information in Appendix G of the MERLIN MAIL® Voice Messaging System Release 3 Planning, Installation, and Use (AT&T 585-320-142) . Ordering Codes Table A-1 provides the ordering codes for the MERLIN LEGEND MAIL System.
  • Page 38 Ordering Codes Upgrade 4-port MERLIN MAIL R3 7107-313/A system to 6-port MERLIN LEGEND MAIL system MERLIN LEGEND MAIL 2-port voice- 107831893 port card MERLIN LEGEND MAIL 4-port voice- 107831901 port card MERLIN LEGEND MAIL Base Module 107831851 (without disk drive) MERLIN LEGEND MAIL Disk Drive 107831885...

  • Page 39: Busying Out/Restoring The Module

    Busying Out/Restoring the Module Overview This appendix provides the step-by-step instructions for busying out and restoring the MERLIN LEGEND MAIL module. These instructions are cross- referenced in the procedures provided in Chapter 3 of this guide. Busying Out the Module CAUTION: Although the system is designed for modules to be removed and replaced without affecting call processing, there is still a possibility that partially...

  • Page 40: Restoring The Module

    Busying Out/Restoring the Module Restoring the Module After installing the MERLIN LEGEND MAIL module, you must restore it to terminate the busy-out condition. To restore the module: 1. At the SPM Main Menu, select Maintenance . 2. At the Maintenance menu, select Slot . 3.

  • Page 41: Installing/Removing The Module

    Installing/Removing the Module Overview This appendix provides the step-by-step instructions for installing and removing the MERLIN LEGEND MAIL module. These instructions are cross-referenced throughout upgrade procedures provided in Chapter 3 of this guide. CAUTION: To avoid damage, do not force the module. If the module does not insert easily, press the bottom-rear locking tab, remove the module, and inspect the module and carrier for damage or obstruction.

  • Page 42: Installing The Module

    Installing/Removing the Module Installing the Module To install the MERLIN LEGEND MAIL module: 1. Lower the module onto the rod on the top of the carrier in the appropriate slot. 2. Be sure that the connector on the module mates properly with the connector on the carrier.

  • Page 43: D Using The Serial Number Utility

    Using the Serial Number Utility Overview This appendix provides the step-by-step instructions for re-serializing the disk drive in the MERLIN LEGEND MAIL module. These instructions are cross- referenced in the upgrade procedures provided in Chapter 3 of this guide. WARNING This procedure should be performed by qualified technicians only.

  • Page 44: Re-Serializing The Disk Drive

    Using the Serial Number Utility Re-Serializing the Disk Drive To re-serialize the disk drive: 1. At the MERLIN LEGEND MAIL administration menu, type b. 2. Enter the password to shut down the MERLIN LEGEND MAIL system. 3. When prompted, type y to verify that you want to shut down the system. 4.

  • Page 45: E Resetting The System

    Resetting the System Overview This appendix provides the instructions for resetting the MERLIN LEGEND MAIL module and RMD. Resetting the MERLIN LEGEND MAIL Module You should perform a system reset when any of the following conditions occur: the MERLIN LEGEND MAIL ports are “locked up” (that is, not answering calls on specific ports).

  • Page 46: Resetting The Remote Maintenance Device

    Resetting the System Resetting the Remote Maintenance Device You should reset the RMD only if instructed by the BCS National Service Assistance Center (NSAC). Typically, you will be asked to reset the RMD if the modem does not answer. WARNING This procedure should be performed by qualified technicians only.

  • Page 47: Changing The Far-End Disconnect Setting And Adding A 3 Db Boost

    Changing the Far-End Disconnect Setting and Adding a 3 db Boost Overview This appendix provides the step-by-step instructions for changing the far-end disconnect setting and adding a 3 db boost. NOTE: These settings should not have to be modified. These settings may only need to be changed if the system is operating in countries other than the United States and Canada.
  • Page 48 Changing the Far-End Disconnect Setting and Adding a 3 db Boost CAUTION: Before touching leads, connectors, pins, and other components when handling the disk drive, use a properly grounded wrist strap to prevent damage from electrostatic discharge (ESD). 1. Busy out the slot in which the MERLIN LEGEND MAIL module is installed.
  • Page 49 Changing the Far-End Disconnect Setting and Adding a 3 db Boost Figure F-2 shows the location of the switch for changing the far-end disconnect signal. Figure F-2. Location of Switches for Far-End Disconnect and 3 db Boost 5. Set Switch 1 to the appropriate setting: ...

  • Page 50: Adding A 3 Db Boost

    Changing the Far-End Disconnect Setting and Adding a 3 db Boost Adding a 3 db Boost Switch 2, which is located inside the MERLIN LEGEND MAIL base module, specifies whether a 3 db boost is applied. If Switch 2 is set to OFF, a 3 db boost is not applied.

  • Page 51: Index

    Index LED meanings, 1-5 overview, 1-5 port assignments, 1-5 replacing two-port voice-port card, 3-6 Acceptance tests troubleshooting, 4-3 overview, 4-1, 4-2 upgrading to, 3-2 verifying the Remote Maintenance Device, 4-2 Four-port voice-port expansion card description, 1-6 replacing, 3-6 troubleshooting, 4-3 upgrading to, 3-2 Base module busy out, B-1...
  • Page 52 Index Modem default settings, 1-3 overview, 1-3 Serial port, 1-3 Reset button, 1-3 Six-port system resetting, E-2 LED meanings, 1-7 verifying, 4-2 overview, 1-6 port assignments, 1-6 replacing two-port voice-port card, 3-6 troubleshooting, 4-3 upgrading to, 3-2 Ordering codes, A-1 Specifications, 1-8 System capacities, 1-1 System compatibility, 1-1...
  • Page 53 Index IN-3...
