R/PR
G/Y
DVI
POWER WIRELESS
RECEIVER
10 BASE-T
Image 3-10
Applications of the RS232/422 connection
Remote control:
•
easy adjustment of projector via IBM PC (or compatible) or MAC connection.
•
address range from 0 to 255.
•
allow storage of multiple projector configurations and set ups.
•
wide range of control possibilities.
Data communication: sending data to the projector or copying the data from the projector to the computer.
What can be connected to the RS232/422 OUT connection ?
The output is a loop through output for RS232/422 signal and can be connected to the RS232/422 IN of the next projector.
To set up the baud rate of the projector, see chapter Installation menu, RS baudrate.
3.9.2
Wireless receiver
What can be connected ?
The optional wireless receiver for the optional rugged remote control can be connected to the Power wireless receiver output and
to the RS232/422 IN. With these tools, it is possible to control the projector from a distance without using cables.
R5976816 RLM R6+ PERFORMER 02/06/2006
B/PB
Hs/Cs
ANALOG RGB
(HD)SDI
RS 232/422
OUT
(b)
Vs
VIDEO
S-VIDEO
R.C.
RS 232/422 IN
(HD)SDI OUT
IN
PUSH
2
1
3
TWO WAY
HARDWIRED REMOTE
3. Connections
(a)
31
